- Page 1 MONTAGEANLEITUNG MOUNTING INSTRUCTIONS MSA 720 Gekapseltes Längenmessgerät Sealed linear encoder Ausgabe 09/2019 Art.Nr. 727461-02 Dok.Nr. D806689-03-A-01 ...
- Page 2 2,5 Nm Transportschutz entfernen! Bearbeitungsebene! Schrauben Remove mounting bracket! abwechselnd gleichmäßig anziehen! Mount as close as possible to the working plane! Tighten the screws equally! RSF Elektronik Ges.m.b.H. A-5121 Tarsdorf +43 (0)6278 / 8192-0 +43 (0)6278 / 8192-79 e-mail: info@rsf.at Internet: www.rsf.at ...
- Page 3 Störquellen Noise sources ƒ A minimum spacing of 200 mm to inductors in switch-mode power supplies is required. RSF Elektronik Ges.m.b.H. A-5121 Tarsdorf +43 (0)6278 / 8192-0 +43 (0)6278 / 8192-79 e-mail: info@rsf.at Internet: www.rsf.at ...
- Page 4 Abmessungen - Montagetoleranzen / Dimensions - mounting tolerances: MSA 720 Anbaumöglichkeiten / Mounting possibilities: RSF Elektronik Ges.m.b.H. A-5121 Tarsdorf +43 (0)6278 / 8192-0 +43 (0)6278 / 8192-79 e-mail: info@rsf.at Internet: www.rsf.at ...
- Page 5 Connect RSF Elektronik encoders only to subsequent electronics whose power supply is generated from PELV systems (EN 50 178). RSF Elektronik encoders fulfill the requirements of standard IEC 61010-1 only if the power is supplied from a secondary circuit with current limitation as per IEC 61010 3rd Ed.
- Page 6 * Nur bei 15-pol. Sub-D (view on pins) ƒ Schirm ist mit dem Steckergehäuse verbunden. * Only with 15-pin D-sub The shield is connected with the chassis. RSF Elektronik Ges.m.b.H. A-5121 Tarsdorf +43 (0)6278 / 8192-0 +43 (0)6278 / 8192-79 e-mail: info@rsf.at Internet: www.rsf.at ...
