Korenix JetWave 2640 Quick Start Manual

JetWave 2640
Outdoor Long Range Dual Band IEEE802.11a + 802.11b/g Wireless AP
802.11
Intel TDMA
a/b/g
40KM WMM
Installation
JetWave 2640 supports one 802.11a and one 802.11b/
g interface, one panel antenna and an external antenna
interface for 802.11b/g band. The optional antenna
allows users to transmit data to clients directly.
JetWave without Dual Band
LAN 1
313
Supports both IEEE 802.11a 5.8GHz and 802.11b/g 2.4GHz band
Up to 54Mbps maximum net data rate
High Gain 23dBi Panel Antenna maximizes transmission distance
up to 40KM
N type external Antenna slot
Wireless QoS (WMM) for video precedence transmission
Supports Base Station, CPE, Point to Point and Point to Multiple
Point Connectivity
Intel TDMA Technology for long distance connectivity
Multiple Data Encryption algorithms, including WEP,WPA,WPA2
Secured Access Control by HTTPS, SSH, 802.1x, MAC
Auto ACK-Time adjustment, Link test for easy installation
Rugged IP67 Protection Housing for outdoor installation
RoHS
Power supply compatible with PoE Source
-30~70
Built-in 23dBi Ext. N type
application
Antenna Antenna
o
IP 67 -30~70 C
LAN 2
www.korenix.com
o
C operating temperature for hazardous environment
With the JetWave 2640, users do not need to purchase
additional 802.11b/g AP since most CPE(clients) are
already embedded with 802.11b/g NIC. The dual band
design is suitable for the first or last AP of the long
distance transmission.
JetWave 2640 Dual Band
802.11 a
5.8GHz band
LAN 1
A Beijer Electronics Group Company
802.11 b/g
2.4GHz
Coverage
LAN 2
