Table of Contents
Safety Notice
Assembly Instruction
Parts List
Warranty
Ordering Parts
Model
STB-0130
Retain This
Manual for
Reference
150501
ASSEMBLY
MANUAL
WEIGHT PLATE RACK
STB-0130
IMPEX INC.
2801 S. Towne Ave, Pomona, CA 91766
Tel: (800) 999-8899 Fax: (626) 961-9966
www.impex-fitness.com
info@impex-fitness.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Impex Steelbody STB-0130
Summary of Contents for Impex Steelbody STB-0130
- Page 1 Table of Contents STB-0130 Safety Notice Assembly Instruction Parts List Warranty Ordering Parts Model STB-0130 Retain This Manual for Reference 150501 ASSEMBLY IMPEX INC. MANUAL 2801 S. Towne Ave, Pomona, CA 91766 Tel: (800) 999-8899 Fax: (626) 961-9966 www.impex-fitness.com info@impex-fitness.com...
-
Page 2: Table Of Contents
ORDERING PARTS………………………………………………………. 7 BEFORE YOU BEGIN Thank you for selecting the STEELBODY Weight Plate Rack STB-0130 by IMPEX INC. For your safety and benefit, read this manual carefully before using the equipment. As a manufacturer, we are committed to provide you complete customer satisfaction. If you have... - Page 3 DOCTOR BEFORE BEGINNING EXERCISE PROGRAM. READ INSTRUCTIONS BEFORE USING ANY FITNESS EQUIPMENT. NOT FOR USE BY CHILDREN UNDER AGE 14. INSPECT FOR DAMAGE BEFORE EACH USE. DO NOT USE IF DAMAGED OR MISSING PARTS. SAVE THESE INSTRUCTIONS. Impex Inc www.impex-fitness.com...
-
Page 4: Warning Labelplacement
WARNING LABEL PLACEMENT The Warning Label shown here has been placed on the Rack Storage Frame. If the label is missing or illegible, please call customer service at 1-800-999-8899 for replacement. Apply the label in location shown. Impex Inc www.impex-fitness.com... -
Page 5: Hardware Pack
HARDWARE PACK NOTE: The following parts are not drawn to scale. Please use your own ruler to measure the size. Impex Inc www.impex-fitness.com... -
Page 6: Assembly Instructions
Storage Rack Frame with two M10 x 2 ⅛” Hex Bolts (#10), one Bracket (#5), four Ø ¾” Washers (#17), and two M10 Aircraft Nuts (#13). B.) Push Handle Grip (#4) onto the Handle. Plug the Handle End Cap (#6) onto the Handle. DIAGRAM-1 Impex Inc www.impex-fitness.com... -
Page 7: Exploded Diagram
1 ½” x 1 ½” Ø 1 ½” x ⅝” Rubber Bumper M10 x 2 ⅛” Hex Bolt Philips Screw M6 x 2” Ø ⅝” Lock Ring Aircraft Nut Aircraft Nut Ø 1 ⅛” Washer Washer Ø ½” Washer Ø ¾” Impex Inc www.impex-fitness.com... -
Page 8: Warranty
IMPEX Customer Service Department at 1-800-999-8899. All freights on products returned to IMPEX must be prepaid by the customer. This warranty does not extend to any product or damage to a product caused by or attributable to freight damage, abuse, misuse, improper or abnormal usage.
