- Page 1 Parts List Warranty Ordering Parts Model SB-228C Retain This Manual for Reference IMPORTANT: Please read this manual before commencing 180430 assembly of this product. ® IMPEX INC. OWNER'S 2801 S. Towne Ave, Pomona, CA 91766 Tel: 800- 999-8899 MANUAL www.marcypro.com support@impex-fitness.com...
-
Page 2: Table Of Contents
EXPLODED DIAGRAM PARTS LIST WARRANTY ORDERING PARTS BEFORE YOU BEGIN Thank you for selecting the MARCY SB-228C Multi-Purpose Bench by ® IMPEX INC. For your safety and benefit, read this manual carefully before using the machine. As a manufacturer, we are committed to provide you complete customer satisfaction. -
Page 3: Important Safety Notices
PHYSICIAN. THIS IS ESPECIALLY IMPORTANT FOR INDIVIDUALS OVER THE AGE OF 35 OR PERSONS WITH PRE-EXISTING HEALTH PROBLEMS. READ ALL INSTRUCTIONS BEFORE USING ANY FITNESS EQUIPMENT. IMPEX INC. ASSUMES NO RESPONSIBILITY FOR PERSONAL INJURY OR PROPERTY DAMAGE SUSTAINED BY OR THROUGH THE USE OF THIS PRODUCT. -
Page 4: Exercise Guidelines
Muscle soreness is common, especially when you first start exercising. If you are painfully sore for a long time, it may be time to change your program. Eventually, your muscle system will become accustomed to the stress and strain placed on it. ©IMPEX INC. www.marcypro.com... - Page 5 Although you may not feel like doing it, taking a rest day at least once a week is important because it gives your body a chance to heal it self. Continuously working your muscles will result in over- training, which will not benefit you in the long run. ©IMPEX INC. www.marcypro.com...
-
Page 6: Warning Label Placement
WARNING LABEL PLACEMENT The Warning Label shown here has been placed on the Rear Base. If the label is missing or illegible, please call customer service at 1-800-999-8899 for replacement. Apply the label in the location shown. ©IMPEX INC. www.marcypro.com... -
Page 7: Free And Training Area
FREE AND TRAINING AREA (free area) (free area) (free area) (training area) (free area) ©IMPEX INC. www.marcypro.com... -
Page 8: Important Assembly Information
NOTE: Do not over-tighten any component with pivoting function. Make sure all pivoting components are able to move freely. Do not tighten all nuts and bolts in this step. ©IMPEX INC. www.marcypro.com... -
Page 9: Weight Capacity And Dimension
4. Examine the equipment regularly for signs of damage or wear. 5. Replace any defective components immediately and/or keep the equipment out of use until repair. 6. Failure to examine regularly may affect the safety level of the equipment. ©IMPEX INC. www.marcypro.com... -
Page 10: Hardware Identifier
HARDWARE PACK NOTE: The following parts are not drawn to scale. Please use your own ruler to measure the size. ©IMPEX INC. www.marcypro.com... -
Page 11: Assembly Instructions
A.) Attach the Main Frame (#3) to the Lower Main Frame (#1). Secure it with three M8 x 3/4” Allen Bolts (#25), six Ø 5/8” Washers (#30) and three M8 Aircraft Nuts (#28). DIAGRAM 1 25 30 30 28 ©IMPEX INC. www.marcypro.com... - Page 12 M10 x 3 3/4” Allen Bolt (#22), two Ø 3/4” Washers (#29), and one M10 Aircraft Nut (#32). Insert a L-shaped Lock Pin (#20) through the upper hole to lock the Front Vertical Frame (#4) in position. Remove the Pin when folding the bench for storage. DIAGRAM 2 ©IMPEX INC. www.marcypro.com...
- Page 13 M12 x 6 7/8” Hex Bolt (#21) and M12 Aircraft Nut (#31). C. Attach two L-shaped Brackets (#9) to the Main Frame (#3). Secure them with one M8 x 3 3/8” Allen Bolt (#23), two Ø 5/8” Washers (#30), and one M8 Aircraft Nut (#28). DIAGRAM 3 ©IMPEX INC. www.marcypro.com...
- Page 14 Frame with one M8 x 1 3/4” Allen Bolt (#24) and Ø 5/8” Washer (#30). B. Place the Backrest Board (#11) onto the Backrest Supports (#5). Secure it with four M8x 3/4” Allen Bolts (#24) and Ø 5/8” Washers (#30). DIAGRAM 4 ©IMPEX INC. www.marcypro.com...
- Page 15 B. Insert the Foam Tube (#8) halfway through the hole on the Front Vertical Frame (#4). Push four Vinyl Foam Rolls (#14) onto the Tubes. C. Lubricate the inside of the Foam Grips (#15) with dish soap. Slide the Foam Grips onto the Foam Tube (#8) from both sides. DIAGRAM 5 ©IMPEX INC. www.marcypro.com...
-
Page 16: Exploded Diagram
SB-228C EXPLODED DIAGRAM ©IMPEX INC. www.marcypro.com... -
Page 17: Parts List
M8 x 3 3/8” Allen Bolt M8 x 1 3/4” Allen Bolt M8 x 3/4” Allen Bolt M6 x 5/8” Philips Screw Ø 3/4” xR1” Washer M8 Aircraft Nut Ø 3/4” Washer Ø 5/8” Washer M12 Aircraft Nut M10 Aircraft Nut ©IMPEX INC. www.marcypro.com... -
Page 18: Warranty
IMPEX. IMPEX is not responsible or liable for indirect, special or consequential damages arising out of or in connection with the use or performance of the product or other damages with respect to any economic loss, loss of property, loss of revenues or profits, loss of enjoyments or use, costs of removal, installation or other consequential damages of whatsoever natures.
