- Page 1 METROLOGIC INSTRUMENTS, INC. MX001 Industrial Control Interface Installation and User’s Guide...
- Page 2 Copyright © 2007 by Metrologic Instruments, Inc. All rights reserved. No part of this work may be reproduced, transmitted, or stored in any form or by any means without prior written consent, except by reviewer, who may quote brief passages in a review, or provided for in the Copyright Act of 1976.
-
Page 3: Table Of Contents
ONTENTS Introduction....................1 Opening the MX001 Industrial Control Box..........2 Internal Components.................3 LED Status Indicators ................4 Configuring the MX001 for 115 or 230 Volt Operation USA: 115V Operation ................5 USA: 230V Operation ................6 Europe/Asia:230V Operation..............7 Europe/Asia: 115V Operation..............8 Locating the Three Strain Reliefs and the Signal Connector....9 Connecting External Wiring to the MX001 ..........9... - Page 4 Universal Self-contained Sensors That Provide Single Pole/Double Throw (SPDT) Relay Outputs for Both Object Sensing and Sensor Alarm ............27 Closing the MX001 Industrial Control Box ..........29 Connecting the MX001 to the Scanner ...........29 Cable Pin Outs for the 8-Pin and 19-Pin Connectors ......30 Specifications ..................31...
-
Page 5: Introduction
The MX001 can be configured to support any object sensor that can supply a 12V, 5V or 10mA output signal. It will also support switch closure (relay) type sensor output. -
Page 6: Opening The Mx001 Industrial Control Box
PENING THE NDUSTRIAL ONTROL To open the MX001 box for wiring and configuration, proceed as follows: Loosen the lid clamp screw with a flat blade screwdriver. Disengage the clamp by pushing the lid down, then move the clamp to the left, and rotate it outward in a counterclockwise direction. -
Page 7: Internal Components
NTERNAL OMPONENTS The following illustration and list explain the parts that pertain to the installation and operation of the MX001. Control TRIAC Triac S IN A IN Figure 1 1. Power Transformer Supplies a stepped down and isolated voltage that produces the 12V DC power for the industrial control box and external sensor. -
Page 8: Led Status Indicators
From these visual indications, it can be determined if the MX001 box is active and what action the scanner and sensor are performing in your system. The following list explains the function of each indicator. They appear inside the box in the order illustrated in Figure 2. -
Page 9: Usa: 115V Operation
ONFIGURING THE PERATION Before applying power to the MX001, it must first be configured for either 115 or 230 volt operation as required. This is accomplished by using the voltage selector switch and the installation of the proper fuses. Refer to one of the procedures on the following pages that apply to your voltage requirement to learn which fuses should be inserted into the F1 and F2 fuse holders. -
Page 10: Usa: 230V Operation
MX001 230 V ONFIGURING THE PERATION USA: 115V Operation (continued) Press the end of the 1/8 Amp fuse into the other gray fuse holder cap unitl it seats. Insert the fuse and cap into the F2 control fuse holder with the screwdriver slot pointing toward the power transformer. -
Page 11: Europe/Asia:230V Operation
MX001 230 V ONFIGURING THE PERATION Europe/Asia: 230V Operation Move the voltage selector to the left with a small screwdriver so that the 230V legend shows in the window. Open the fuse kit and remove the following: • (2) Black Fuse Holder Caps •... -
Page 12: Europe/Asia: 115V Operation
MX001 230 V ONFIGURING THE PERATION Europe/Asia: 115V Operation Move the voltage selector to the right with a small screwdriver so that the 115V legend shows in the window. Open the fuse kit and remove the following: • (2) Black Fuse Holder Caps •... -
Page 13: Locating The Three Strain Reliefs And The Signal Connector
There are three strain reliefs and one 8-pin signal connector located on the bottom of the MX001 box. The two large strain reliefs on the left side allow the use of flexible cordage for MX001 power input and controlled power (TRIAC) output in that order. -
Page 14: Connecting The Ac Power Input Cable
Connect each wire to the appropriate locations noted in the table below and secure the wires in the terminal block and protective earthing terminal by turning each screw clockwise. (Refer to the MX001 box or to Figure 4 for the order of the terminals for the power wires.) Secure the cable by turning the strain relief’s domed sealing nut clockwise... -
Page 15: Connecting The Triac Controlled Power Output Cable
Connect each wire to the appropriate locations noted in the table below and secure the wires in the terminal block and protective earthing terminal by turning each screw clockwise. (Refer to the MX001 box or to figure 5 for the order of the terminals for the TRIAC wires.) -
Page 16: Temporarily Disabling The Triac Output
If, during set up or maintenance, there is a need to disable the TRIAC output of the MX001, simply remove the F1 TRIAC fuse. This disconnects the AC line voltage from the TRIAC circuitry and output terminal block, but leaves the TRIAC LED indicator active allowing checks to be made for TRIAC circuit activity without activating the TRIAC controlled device. -
Page 17: Sensor Support
In all cases, the sensor’s output signal or switch closure is expected to become active when an object has been sensed. The easiest sensor to use with the MX001 is a low voltage (a 10-30 volt) DC, self contained, sensor. The industrial control box can power this type of sensor with 12V DC at 200 mA maximum and will interface to either a (PNP) current sourcing, or (NPN) current sinking output. -
Page 18: Connecting The Sensor
2 and 3 of its header. • To disable the sensor alarm, position the J2 (A SETUP) jumper on pins 2 and 3 of its header. These procedures disconnect the sensor’s output signals from the MX001’s input circuitry without physically disconnecting any sensor wiring. -
Page 19: Sensors Powered Independently That Provide Either 12V, 5V Or A 10Ma Dc Output Signal
Insert the sensor’s DC common (or negative) output wire into the S IN- terminal block and secure the wire by turning the terminal’s screw clockwise.(Refer to the MX001 box or Figure 6 for the order of the terminals for the sensor wires) Insert and secure the sensor’s positive output wire to the... - Page 20 Current limiting can be accomplished by using an external limiting resistor of the appropriate value (which is dependent upon the sensor’s DC signal output voltage level). This resistor is connected between the S IN+ input of the MX001 box and the sensor.
-
Page 21: Sensors That Provide Switch Closures Or Relay Type Output
Insert one of the sensors signal output wires into the COMMON terminal and secure the wire by turning the terminal’s screw clockwise. (Refer to the MX001 box or to Figure 8 for the order of the terminals for the sensor wires.) Insert and secure the sensor’s other signal output wire into the S IN-... -
Page 22: Low Voltage Self-Contained Dc Sensors With A Current Sinking Output
Inserts the sensor’s DC common wire into the COMMON terminal and secure the wire by turning the terminals’s screw clockwise. (Refer to the MX001 box or to Figure 10 for the order of the terminals for the sensor wires.) Insert and secure the sensor’s +DC power input wire into the +12V OUT terminal. -
Page 23: Low Voltage Self-Contained Dc Sensors With A Current Sourcing Output
Connect a small jumper wire between the COMMON and the S IN- terminals. Secure the jumper wire in the S IN- terminal by turning the terminal’s screw clockwise. (Refer to the MX001 box or to Figure 12 for the order of the terminals for the sensor wires. -
Page 24: Universal Self-Contained Sensors That Provide A Single Pole/Double Throw (Spdt) Relay Output
Insert the sensor’s +DC power input wire into the +12V OUT terminal and secure the wire by turning the terminal’s screw clockwise. (Refer to the MX001 box or to Figure 14 for the order of the terminals for the sensor wires.) Insert the sensor’s –DC or common power input wire and the relay output... - Page 25 ENSOR UPPORT “Universal” Self-Contained Sensors that Provide a Single Pole/Double Throw (SPDT) Relay Output Position the jumper on pins 5 and 6 of the J1 (S SET UP) header. (Refer to Figure 15). Figure 14 S SET UP Figure 15...
-
Page 26: Sensors Powered Independently That Provide Either
Insert the sensor’s DC common (or negative) output wire into the S IN- terminal block and secure the wire by turning the terminal’s screw clockwise. (Refer to the MX001 box or to Figure 16 for the order of the terminals for the sensor wires.) Insert and secure the sensor’s positive output wire into the S IN+ terminal. - Page 27 One resistor is connected between the S IN+ input of the MX001 box and the sensor. The other resistor is connected between the A IN+ input of the MX001 box and the sensor (for the sensor alarm circuit). Sensor Output Voltage – 3V...
-
Page 28: Sensors That Provide Switch Closures Or Relay Type Output With A Sensor Alarm
Insert one of the sensor’s signal output wires and one of the sensor’s alarm output wires into the COMMON terminal and secure the wires by turning the terminal’s screw clockwise. (Refer to the MX001 box or to Figure 18 for the order of the terminals for the sensor wires.) Insert and secure the sensor’s remaining signal output wire into the S IN-... -
Page 29: Low Voltage Self-Contained Dc Sensors With Current Sinking Outputs And Sensor Alarm
Insert the sensor’s DC common wire into the COMMON terminal and secure the wire by turning the terminal’s screw clockwise. (Refer to the MX001 box or to Figure 20 for the order of the terminals for the sensor wires.) Insert and secure the sensor’s +DC power input wire into the +12V OUT terminal. - Page 30 Connect a small jumper wire between the COMMON and the S IN- terminals and secure the jumper in the S IN- terminal by turning the terminal’s screw clockwise. (Refer to the MX001 box or to Figure 22 for the order of the terminals for the sensor wires.) Connect a small jumper wire between the COMMON and the A IN- terminal and secure the jumper in the A IN- terminal.
-
Page 31: Universal Self-Contained Sensors That Provide Single Pole/Double Throw (Spdt) Relay Outputs For Both Object Sensing And Sensor Alarm
Insert the sensor’s +DC power input wire into the +12V OUT terminal and secure the wire by turning the terminal’s screw clockwise. (Refer to the MX001 box or to figure 24 for the order of the terminals for the sensor wires.) Insert the sensor’s -DC or common power input wire and both the object... - Page 32 {NO] output) makes contact with the COMMON terminal when the sensor indicates that its alarm output is active. Remove any power applied to the MX001 box (in Step 13) and connect and secure the “alarm” relay output wire previously determined to the A IN- terminal.
-
Page 33: Closing The Mx001 Industrial Control Box
TO THE CANNER The supplied, scanner link cable is used to connect the MX001 box to a TECH series scanner. This one meter cable carries the MX001’s control signals and is terminated with an 8 and a 19 pin connector. (Other cable lengths are available, contact Metrologic for details.) -
Page 34: Cable Pin Outs For The 8-Pin And 19-Pin Connectors
ONNECTORS The standard scanner link cable length is 3 feet – 1 meter. Other scanner link cable lengths are available upon request. Contact Metrologic Customer Service for additional details. If there is a need to lengthen the scanner link cable, use a cable with #26 wire. -
Page 35: Specifications
PECIFICATIONS MX001 Specifications Application: Industrial Control Interface L-bracket with TECH scanner or independently Orientation: mounted Dimensions: 152mm L x 102mm W x 76mm D (6” x 4” x 3”) Weight: 1.36 Kg (93 lbs.) Case Material: Oil Tight J1C box... -
Page 36: Troubleshooting
F2 Control fuse for correct rating. (Depends upon line voltage in use.) If a low voltage DC type sensor is connected to the MX001 and is using the MX001 as its power source (+12V OUT in use), make sure this sensor does not draw more than 200mA of current from the MX001 or that the sensor is incorrectly connected or shorted. - Page 37 LED TRIAC indicator off, then MX001 TRIAC circuit damage is indicated. The Mx001 can be damaged if the TRIAC output is accidentally shorted. NOTE: TRIAC load refers to the device that is connected by the MX001 TRIAC.
- Page 38 This is due to the TRIAC snubber circuit in the MX001 that protects the TRIAC from surge damage due to inductive loads. This circuit produces a small amount of AC output (5mA) at the TRIAC terminal block that can be measured when no load is connected there but is of no consequence otherwise.
- Page 39 Having the sensor set up to produce an output when it does not sense an object will result in reversed sensing conditions. The MX001 expects to receive an active output signal from the sensor (source voltage/current or switch closure) when the object to be scanned is being sensed.
- Page 40 Check for proper connection of the sensor alarm output to the MX001 sensor terminal block plus proper positioning of the A Set Up jumper at J2. The MX001 expects to receive an active alarm output signal from the sensor (source voltage/current or switch closure) when sensing conditions have become marginal.
- Page 41 If the scanner has been programmed for sensor support, the scanner will not scan any label including the HoloSet label unless a sensor is connected to the MX001 box and activated. If the scanner has been programmed to support DTR, the scanner will not scan any label including the HoloSet label unless the DTR input is active.
- Page 42 These steps are not required for proper installation and application programming of the MX001 box. Do not connect a sensor to the MX001 at this time. Tighten each sensor terminal block screw by turning each screw clockwise.
- Page 43 ROUBLESHOOTING 10. Short the A IN- terminal screw to the COMMON terminal screw with a short piece of wire. The red A IN LED should light and the scanner should emit a repetitive warning tone as long as this connection is maintained.
-
Page 44: Limited Warranty
The MX001 interface is manufactured by Metrologic at its Blackwood, New Jersey, USA facility. The MX001 interface has a two (2) year limited warranty from the date of manufacture. Metrologic warrants and represents that all MX001 interface is free of all... -
Page 45: Notices
OTICES Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Class A Devices This equipment has been tested and found to comply with limits for a Class A digital device, pursuant to part 15 of the FCC Rules. - Page 48 March 2004, Version 01 Printed in the USA 0 0 - 0 2 1 7 3...
