Summary of Contents for King Tony 9TY513-12
- Page 1 HYDRAULIC SHOP PRESS OPERATION MANUAL 9TY513-12 Enjoy your work...
-
Page 2: Operating Instructions
Capacity (T) Stroke (mm) Work range (mm) KT NO. 9TY513-12 0-610 OPERATING INSTRUCTIONS • Place the heel block on bed frame, then insert workpiece onto the heel block. • Connect the air inlet fitting into the shop air supply hose lock fitting, turn on the valve to let the pump work until serrated saddle nears workpiece, then turn off the air valve. -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS • If detect anything that may indicate imminent structural failure, stop using the press immediately and inspect it thoroughly. • Do not use press to compress springs or any other item that could disengage and cause a potential hazard. -
Page 4: Parts List
PARTS LIST Part Description Part Description Hex head bolt M12x110mm Support pin Upper bolster Posts Washer Ø12 Hex head bolt M10x30mm Spring washer Ø12 Base Nut M12 Washer Ø10 Return spring Spring washer Ø10 Bottle jack Nut M10 Hook Handle assembly Jack base Steel ball bearing Ø6 Nut M6...
