Evermount EM-AVSB Instructions

PLEASE READ THESE INSTRUCTIONS CAREFULLY AND KEEP FOR FUTURE REFERENCE! IF YOU
DO NOT UNDERSTAND THE INSTRUCTIONS, OR DO NOT FEEL THAT YOU CAN FOLLOW THEM
SAFELY, CONTACT A QUALIFIED CONTRACTOR. THE WARRANTY WILL BE HONOURED IF
ACCOMPANIED BY AN ORIGINAL SALES RECEIPT, AND ONLY IF THE INSTRUCTIONS HAVE BEEN
FOLLOWED EXACTLY. To acquire missing parts please visit www.everik.com/parts.html or call
1-866-604-6966.
Attention!
• Maximum shelf load: 10kg / 22lbs.
• Do not install onto steel studs.
• Everik International will not be held liable for personal injury or damage resulting from mishandling,
incorrect mounting, incorrect assembly or product misuse.
Description
Wall Bracket
1
Shelf Bracket
2
End Cap
3
Mounting Bolts
4
5 Wall Anchor
Socket Head Bolt
6
Set Screw
7
Plastic Pad
8
2.5mm Allen Key
9
3mm Allen Key
10
5mm Allen Key
11
Glass Shelf
12
Screw
13

Step 1: Install the Plastic Shelf Pads

Slide the plastic pads onto the shelf brackets. Once in position securely fasten the pads using set screws. Do
not over tighten. See figure 1.

Step 2: Install Shelf Bracket

Securely fasten the shelf bracket to the wall bracket using socket head bolts. Do not over tighten. See figure 2.
072009
INSTRUCTIONS
Qty
1
1
2
2
2
2
4
4
1
1
1
1
1
EM-AVSB
1
