INSTALLATION MANUAL
CameraView
Document ID: IM-xx-xx
Last Updated: February 5, 2020
Pedigree Technologies recommends using a professional installer for optimal
results. Please let your Pedigree Technologies representative suggest a provider if
you need help with your hardware installations.
PedigreeTechnologies.com | Support: (701)-499-0022

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OneView CameraView and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pedigree Technologies OneView CameraView

Summary of Contents for Pedigree Technologies OneView CameraView

  • Page 1 CameraView Document ID: IM-xx-xx Last Updated: February 5, 2020 Pedigree Technologies recommends using a professional installer for optimal results. Please let your Pedigree Technologies representative suggest a provider if you need help with your hardware installations. PedigreeTechnologies.com | Support: (701)-499-0022...
  • Page 2 • The field of view should not have too much “sky”. • Split windows may have to adjust mounting location other than what is recommended in this document. Consult with your implementation manager at Pedigree Technologies. PedigreeTechnologies.com | Support: (701)-499-0022...

  • Page 3: Installation

    CameraView Installation Steps, Continued Installation STEP ONE Determine proper placement of camera on the front windshield. • Center of the windshield behind the rearview mirror area • Highest possible placement within the wiper blade path • Avoid any overhanging exterior sun visor or other materials on glass including rock chips or cracks.
  • Page 4 CameraView Installation Steps, Continued Install Power Cable STEP ONE Micro USB to Camera Connect the micro USB cable to the camera. STEP TWO Route the cable inside the headliner to the power box. Cables and wiring should not be visible after installation is complete.

  • Page 5: Install Sd Card

    CameraView Installation Steps, Continued Install Power Cable Continued STEP FOUR Red - Power Connect the power (red) wire to ignition (or other 12V power source that is powered on when the ignition is on). Black - Ground Power to Fuse Tap It may be necessary to connect the power wire to a blade fuse adapter.
  • Page 6 CameraView Test Camera Functionality STEP ONE Start the truck’s engine. STEP TWO Make sure that the camera has power (indicated by the blue LED next to the camera lens, may take 30-45 seconds to receive power). Blue LED next to camera lens STEP THREE On the tablet, open POV, but stay logged out.

  • Page 7: Secure The Camera

    CameraView Testing GOOD MOUNTING • The hood should barely be visible at the bottom of the screen. • No lighted accessories inside the vehicle should interfere with the camera, including at night. • Horizon line is level • There is nothing hindering the view of the camera •...
  • Page 8 CameraView APMM Power Module Installation (Cab-Mate One only) STEP ONE Identify and record the ESN of the Cab-Mate One before proceeding. The following steps will cover the serial number and you will need it for activating the device later, or servicing the device in the future. STEP TWO For new intalls of the Cab-Mate One, install the diagnostic data cable as per the Cab-Mate...
  • Page 9 CameraView APMM Power Module Installation (Cab-Mate One only) continued STEP FIVE Secure the APMM bracket to the Cab-Mate One by sandwiching it between the Cab-Mate One and the ball mount using the supplied screw and washer pack. (Use the longer machine screws provided, paired with star washers.) Ball Mount APMM Bracket...
  • Page 10 CameraView APMM Power Module Installation (Cab-Mate One only) continued STEP EIGHT Connect the APMM harness to the AUX1 and LMU DIAG ports on the top of the APMM module. Top view STEP NINE Mount the Cab-Mate One/APMM assembly to the dash using the Panavise ball mount (not pictured).

  • Page 11: Start Vehicle

    CameraView Testing / Confirmation TIE LOOSE CABLES Cable tie all loose cables together as best as possible to prevent snags or cable movement during operation. (Not pictured.) START VEHICLE Start vehicle outdoors and let run for 3-5 minutes before calling Pedigre support to verify installation (new Cab-Mate One install only).
