Protection class IP 44 Leaf max length (m) The STEP automated system was designed and built for controlling Leaf max weight (Kg) vehicle access. Do not use for any other purpose. Operator overall dimensions LxHxD (mm) see fig.
Page 4
ENGLISH 3. ELECTRONIC EQUIPMENT (standard system) 2x1,5 mm + (230Vac) Fig. 4 Step operator with equipment. Photocells Key operated push-button Flashing lamp Radio receiver 90 ° Notes: 1) To lay electric cables, use adequate rigid and/or flexible tubes. 0 ÷ 50...
Page 5
ENGLISH 4.4. INSTALLING THE RACK 4.3. MECHANICAL INSTALLATION • Position the operator on the plate, using the supplied screws 4.4.1. STEEL RACK TO BE WELDED (Fig. 11) as shown in figure 8. Place the three threaded pawls on the rack element, positioning them at the top of the slot.
Page 6
4.5. POSITION THE TRAVEL LIMIT MAGNETS The Step operator is supplied with a sensor which, by detecting the transit of two magnets secured to the top of the rack, commands gate movement to stop. Procedure for correct positioning of the two supplied magnets: •...
ENGLISH CONTROL BOARD WARNINGS Important: Before attempting any job on the control board (connections, maintenance), cut out power supply and the battery. - Install, upstream of the system, a differential thermal breaker with adequate tripping threshold. - Always separate 230VAC power cable from control and safety cables (push-buttons receiver, photocells, etc.). To avoid any electrical noise, use separate sheaths or a shielded cable (with earthed shield).
ENGLISH CONTROL BOARD TECHNICAL SPECIFICATIONS Power supply 12Vac Batteries Hermetic Pb 12Vdc 1.2Ah - dimensions 96x46x50 Transformer characteristics Primary 230 Vac - Secondary 12 Vac - 16VA Absorbed power 16 VA Motor max current Operating ambient temperature -20° +55° Protection fuses N°...
Page 9
ENGLISH 8.1. Connection of photocells and safety devices Opening safety devices: they operate only during the gate opening movement and, therefore, are suitable for protecting the zone between the gate as it opens and fixed obstacles (walls, etc) against the risk of impact and crushing.
Page 10
ENGLISH OPEN A - "TOTAL OPENING" (terminal 1) OPEN command: any Connection of 2 pairs of closing photocells and 1 pair of device (e.g.: push-button) which, by closing a contact, opening photocells. supplies an opening or closing pulse to the gate. To install several opening pulse generators, connect the N.O.
Page 11
ENGLISH 8.4. J3 Terminal board - Motor Connection This terminal board is used for connecting the motor (see fig. 22) . For the colour of the wires, refer to fig.32 (right closing) and to fig. 33 (left closing). 8.5. J4 Connector - Battery connection Connect the operator battery (Fig.
Page 12
ENGLISH Push-button P1 is used to select the function to be programmed. Push-button P2 is used to modify the value of the selected function. -If you press push-button P1, LED A lights up; use push- button P2 to select the required logic as shown in table 5. -If you press push-button P1 again, LED B lights up;...
ENGLISH AUTOMATION TEST When installation has been completed, run a careful functional check of the automated system and all accessories connected to it, especially the safety devices. Hand the "User's guide" page to the Customer, and explain correct operation and use of the gearmotor. MANUAL OPERATION If the gate has to be moved manually due to a fault of the automated system, use the release device as follows:...
Page 15
Les descriptions et les illustrations du présent manuel sont fournies à titre indicatif. GENIUS se réserve le droit d’apporter à tout moment les modifications qu’elle jugera utiles sur ce produit tout en conservant les caractéristiques essentielles, sans devoir pour autant mettre à...
