- Page 1 Shogun Green Laser Head ORDERCODE 30971...
- Page 2 For more information: iwant@showtec.info You can get some of the best quality, best priced products on the market from Showtec. So next time, turn to Showtec for more great lighting equipment. Always get the best -- with Showtec ! Thank you!
-
Page 3: Table Of Contents
Showtec Showtec Shogun Laser Head Product Guide ™ Warning..…...................………………………………………….. Safety-instructions………………………………………………………………………………………….…. Operating Determinations……………………………………………………………………………………. Rigging…………………………………………………………………………………………………………. Description..…................……….………………………………… Features and Overview ………………………………...….……………….………….………………….…. Backside…………………………………………………...…...….……………….…………………...….…. Set Up and Operation..............……..……………………………….… One Shogun Laser Head.........…..……………………………..………………………..Multiple Shoguns Laser Head..............…………………………….…. DMX-Control…..........…..……………………………………………………………. Control Panel.…………......……………………………………………………………………… Control Mode......………………………………………………………………………………… DMX Addressing………………………..…………………………………………..…………………………. Maintenance...................………..………….…….……………… Replacing the Fuse................…………………….…………………... -
Page 4: Warning
WARNING CAUTION! Keep this device away from rain and moisture! Unplug mains lead before opening the housing! FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY BEFORE YOUR INITIAL START-UP! SAFETY INSTRUCTIONS Every person involved with the installation, operation and maintenance of this device has to: be qualified follow the instructions of this manual CAUTION! Be careful with your operations. -
Page 5: Operating Determinations
The arising condensation water might damage your device. Leave the device switched off until it has reached room temperature. If your Showtec device fails to work properly, discontinue use immediately. Pack the unit securely • (preferably in the original packing material), and return it to your Showtec dealer for service. -
Page 6: Rigging
Rigging Please follow the European and national guidelines concerning rigging, trussing and all other safety issues. Do not attempt the installation yourself ! Always let the installation be carried out by an authorized dealer ! Procedure: If the laser is lowered from the ceiling or high joists, professional trussing systems have to be used. •... -
Page 7: Description
Description of the device Features The Showtec Shogun Laser Head is a laser effect with a high output and great effects. • 3 versions available: 100 mW red laser (30970), 60 mW green laser (30971), 60 mW blue laser (30972) •... -
Page 8: Backside
Backside Fig. 2 DMX signal connector (IN) DMX signal connector (OUT) 7) IEC Power Connector and Fuse 2A / 250V... -
Page 9: Set Up And Operation
Set Up and Operation Follow the directions below, as they pertain to your preferred operation mode. Before plugging the unit in, always make sure that the power supply matches the product specification voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa. The laser will only work between 18-30ºC. -
Page 10: Multiple Shoguns Laser Head
Multiple Shogun Laser Heads 1. Fasten the effect light onto firm trussing (Use a 30-kg rated or stronger C-clamp fastened onto the Shogun Laser Head ). Leave at least 1 meter on all sides for air circulation. 2. Use a 3-p XLR cable to connect the Shoguns and other devices. The pins: Earth Signal -... -
Page 11: Dmx-Control
DMX Protocol Channel 1 –Pan (Horizontal) 0-255 0 - 370º Channel 2 –Tilt (Vertical) 0-255 0 - 265º Channel 3 –Picture 0-255 12 pictures Channel 4 –Picture Roll (Vertical) 0-255 Roll vertical line like mirror image, compress fold Channel 5 – Picture Roll (Horizontal) 0-255 Roll horizontal line like mirror image, compress fold Channel 6 –Picture Roll... -
Page 12: Control Panel
Control Mode The fixtures are individually addressed 0-511 on a data-link and connected to the controller. The fixtures respond to the DMX signal from the controller. (When you select the DMX address and save it, the controller will display the saved DMX address the next time.) DMX Addressing The control panel on the front side of the base allows you to assign the DMX fixture address, which is the first channel from which the Shogun will respond to the controller. -
Page 13: Maintenance
Maintenance The Showtec Shogun Laser Head requires almost no maintenance. However, you should keep the unit clean. Otherwise, the fixture’s light-output will be significantly reduced. Disconnect the mains power supply, and then wipe the cover with a damp cloth. Do not immerse in liquid. Carefully wipe both mirrors clean with glass cleaner and a soft cloth. -
Page 14: Product Specifications
Signal output 3-pin XLR female DMX-control via standard DMX-controller Laser 100 mW red laser (635nm), ordercode 30970) 60 mW green laser (532nm), ordercode 30971 60 mW blue laser (473nm), ordercode 30972 Minimum distance: Minimum distance from flammable surfaces: 0.5m Minimum distance to lighted object: 0.8m... - Page 15 2005 Showtec.
