The TAP DIV function sub-divides the tempo tapped in via the TAP/LOOP

footswitch to create shorter or longer delay times in sync with your tap

time. It assumes that what is tapped is a quarter note. TAP DIV then

divides the quarter note to produce delay times rhythmically in time with

the tap tempo.

The current DELAY knob setting can also be divided by the TAP DIV

button. When you turn the DELAY knob, the range is always based on a

quarter note length. After you set the DELAY knob, pressing the TAP DIV

button selects the divide ratio of the delay time for each TAP DIV setting.

The TAP DIV button cycles through the nine available Tap Divide settings.

There are three main divisions: quarter note - , eighth note -

sixteenth note - . Each division can be further broken down into its triplet

and dotted versions. The TAP DIV LEDs will light to show the current tap

divide setting, and once set will blink at the current delay time.

The following table provides an example of how each Tap Divide changes

your delay time whether the delay time is set by the TAP/LOOP footswitch

or DELAY knob. The tapped time in this example is 600ms.

TAP DIV Mode

Quarter Note

Quarter Note Triplet

Dotted Quarter Note

Eighth Note

Eighth Note Triplet

Dotted Eighth Note

Sixteenth Note

Sixteenth Note Triplet

Dotted Sixteenth Note
