Drawer Mounting Brackets
For full-Extension Slides
Our mounting brackets are designed to ease
the process of aligning a full-extension drawer
slide to the drawer box once the slide has
been mounted into the cabinet. Brackets are
designed to work with both face frame and
frameless cabinets.
To use with face frame cabinets...
Install full-extension drawer slides with our
Magnetic Drawer Slide Mounting Tool (NZ03).
This will position the slide ¼" off the bottom of
the face frame.
Place the brackets into the drawer box opening
so that the support tabs of the brackets rest on
the top of the face frame rail and under the slide
as shown. Clamp the bracket to the face frame
to hold it in position.
