ECS 945PL-A Manual

ECS 945PL-A Manual

Hide thumbs Also See for 945PL-A:
Table of Contents
  • Canadian Department of Communications
  • Declaration of Conformity
  • Table of Contents

  • Chapter 1 Introducing the Motherboard
    • Introduction
    • Feature
    • Motherboard Components

  • Chapter 2 Installing the Motherboard
    • Safety Precautions
    • Choosing a Computer Case
    • Installing the Motherboard in a Case
    • Checking Jumper Settings
      • Setting Jumpers
      • Checking Jumper Settings
      • Jumper Settings
    • Connecting Case Components
      • Front Panel Connector
    • Installing Hardware
      • Installing the Processor
      • Cpu Installation Procedure
      • Installing Memory Modules
      • Installing a Hard Disk Drive/CD-ROM/SATA Hard Drive
      • Installing a Floppy Diskette Drive
      • Installing Add-On Cards
      • Connecting Optional Devices
    • Connecting I/O Devices

  • Chapter 3 Using BIOS
    • About the Setup Utility
      • The Standard Configuration
      • Entering the Setup Utility
      • Bios Navigation Keys
      • Updating the BIOS
    • Using BIOS
      • Standard BIOS Features
        • System Memory
        • Time and Date
        • Boot Configuration Features
      • Advanced BIOS Features
      • Advanced Chipset Features
    • Power Management Features
    • Hardware Health Features
    • BIOS Security Features
    • Load Optimal Defaults
    • Load Performance Defaults
    • Save Changes and Exit
    • Discard Changes and Exit

  • Chapter 4 Using the Motherboard Software
    • About the Software CD-ROM
    • Auto-Installing under Windows 2000/XP
      • Running Setup
    • Manual Installation
    • Utility Software Reference
    • Onboard Lan

Advertisement

Available languages
  • EN

Available languages

  • ENGLISH, page 67

Quick Links

Download this manual

Advertisement

Table of Contents
loading

Related Manuals for ECS 945PL-A

Summary of Contents for ECS 945PL-A

  • Page 3 Preface Copyright This publication, including all photographs, illustrations and software, is protected under international copyright laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may be reproduced without written consent of the author. Version 1.0 Disclaimer The information in this document is subject to change without notice.

  • Page 4: Declaration Of Conformity

    Declaration of Conformity This device complies with part 15 of the FCC rules. Operation is subject to the following conditions: • This device may not cause harmful interference, and • This device must accept any interference received, including interference that may cause undesired operation Canadian Department of Communications This class B digital apparatus meets all requirements of the Canadian Interference-causing Equipment Regulations.

  • Page 5: Table Of Contents

    T T T T T ABLE OF CONTENTS ABLE OF CONTENTS ABLE OF CONTENTS ABLE OF CONTENTS ABLE OF CONTENTS Preface Chapter 1 Introducing the Motherboard Introduction....................1 Feature......................2 Motherboard Components................4 7 7 7 7 7 Chapter 2 Installing the Motherboard Safety Precautions..................7 Choosing a Computer Case...............7 Installing the Motherboard in a Case............7...
  • Page 6 Power Management Features............35 Hardware Health Features............37 BIOS Security Features..............39 Load Optimal Defaults..............40 Load Performance Defaults............40 Save Changes and Exit..............40 Discard Changes and Exit............40 Chapter 4 41 41 41 41 41 Using the Motherboard Software About the Software CD-ROM..............41 Auto-installing under Windows 2000/XP..........41 Running Setup................42 Manual Installation..................44 Utility Software Reference...............44...

  • Page 7: Introducing The Motherboard

    SATA II compliant, supporting four SATA ports with maximum transfer rate up to 3.0Gb/s each. The 945PL-A motherboard is equipped with advanced full set of I/O ports in the rear panel, including PS/2 mouse and keyboard connectors, COM1, LPT2, four USB ports, one op- tional LAN port,one optional 1394a port and audio jacks for microphone, line-in and line out.

  • Page 8: Feature

    Feature Processor The 945PL-A uses an LGA775 type of Pentium 4/Celeron D/Pentium D that carries the following features: • Accommodates Intel Pentium 4/Celeron D/ Pentium D processors • Supports a system bus (FSB) of 800/533MHz • Supports “Hyper-Threading” technology CPU “Hyper-Threading”...
  • Page 9 One 40-pin IDE low profile connector that support two IDE devices • One floppy disk drive connector • Four 7-pin SATA connectors The 945PL-A motherboard supports UltraDMA bus mastering with transfer rates of 100/66/33 MB/s. Integrated I/O The motherboard has a full set of I/O ports and connectors: •...

  • Page 10: Motherboard Components

    Motherboard Components Introducing the Motherboard...
  • Page 11 Table of Motherboard Components LABEL COMPONENT 1 CPU Socket LGA775 socket for Pentium 4 CPUs 2 DIMM1~2 240-pin DDR2 SDRAM slots 3 ATX1 Standard 24-pin ATX power connector 4 IDE1 Primary IDE channel 5 SATA1~4 Serial ATA connectors 6 JP1 Clear CMOS jumper 7 SYSFAN3 System cooling fan connector...
  • Page 12 Memo Introducing the Motherboard...

  • Page 13: Installing The Motherboard

    Chapter 2 Installing the Motherboard Safety Precautions • Follow these safety precautions when installing the motherboard • Wear a grounding strap attached to a grounded device to avoid damage from static electricity • Discharge static electricity by touching the metal case of a safely grounded object before working on the motherboard •...

  • Page 14: Checking Jumper Settings

    Do not over-tighten the screws as this can stress the motherboard. Checking Jumper Settings This section explains how to set jumpers for correct configuration of the motherboard. Setting Jumpers Use the motherboard jumpers to set system configuration options. Jumpers with more than one pin are numbered.

  • Page 15: Checking Jumper Settings

    Checking Jumper Settings The following illustration shows the location of the motherboard jumpers. Pin 1 is labeled. Jumper Settings Type Jumper Description Setting (default) 1-2: CLEAR CMOS 3-pin CLEAR CMOS 2-3: NORMAL Before clearing the CMOS, make sure to turn off the system. To avoid the system unstability after clearing CMOS, we recommend users to enter the main BIOS setting page to “Load Optimal De- faults”...

  • Page 16: Connecting Case Components

    Connecting Case Components After you have installed the motherboard into a case, you can begin con- necting the motherboard components. Refer to the following: Connect the CPU cooling fan cable to CPUFAN1. Connect the system cooling fan connectors to SYSFAN2/3. Connect the connector for graphics interface to ATX4P1.
  • Page 17 CPUFAN1: CPU Cooling FAN Power Connector Signal Name Function System Ground Power +12V +12V Sense Sensor CPU FAN control Users please note that the fan connector supports the CPU cooling fan of 1.1A~2.2A (26.4W max.) at +12V. SYSFAN2 : System Cooling FAN Power Connectors Signal Name Function System Ground...

  • Page 18: Front Panel Connector

    ATX4P1: Auxliary Power Connector for Graphics Interface Signal Name Make sure to connect a 4-pin ATX power cable to ATX4P1; otherwise, the system will be un- stable. +12V SPK1: Internal speaker Signal Name Signal Front Panel Connector The front panel connector (PANEL1) provides a standard set of switch and LED connec- tors commonly found on ATX or micro-ATX cases.

  • Page 19: Installing Hardware

    Power Switch Supporting the power on/off function requires connecting pins 6 and 8 to a momentary- contact switch that is normally open. The switch should maintain contact for at least 50 ms to signal the power supply to switch on or off. The time requirement is due to internal de- bounce circuitry.

  • Page 20: Cpu Installation Procedure

    CPU Installation Procedure The following illustration shows CPU installation components. A. Unload the cap · Use thumb & forefinger to hold the lifting tab of the cap. · Lift the cap up and remove the cap completely from the socket. B.

  • Page 21: Installing Memory Modules

    Installing Memory Modules This motherboard accomodates two memory modules. It can support two 240-pin 1.8V DDR2 533/400 DDR SDRAM. The total memory capacity is 2 GB. DDR2 SDRAM memory module table Memory module Memory Bus DDR2 400 200MHz DDR2 533 266MHz You must install at least one module in any of the two slots.
  • Page 22 Table A: DDR2 QVL (Qualified Vender List) The following DDR2 memory modules have been tested and qualified for use with this motherboard. Type Size Vendor Model Name Micron MT8HTF3264AG-40EB3 CL3 SS 256MB Hynix HYMP532U646-E3 AA Nanya NT256T64UH4A0F-5A CL3 DDR2 400 Hynix HYMP564U648-E3 AA 512MB...

  • Page 23: Installing A Hard Disk Drive/Cd-Rom/Sata Hard Drive

    Installing a Hard Dish Drive/CD-ROM/SATA Hard Drive This section describes how to install IDE devices such as a hard disk drive and a CD-ROM drive. About IDE Devices Your motherboard has one IDE channel interface. An IDE ribbon cable supporting two IDE devices is bundled with the motherboard.

  • Page 24: Installing A Floppy Diskette Drive

    Refer to the illustration below for proper installation: Attach either cable end to the connector on the motherboard. Attach the other cable end to the SATA hard drive. Attach the SATA power cable to the SATA hard drive and connect the other end to the power supply.

  • Page 25: Installing Add-On Cards

    Installing Add-on Cards The slots on this motherboard are designed to hold expansion cards and connect them to the system bus. Expansion slots are a means of adding or enhancing the motherboard’s features and capabilities. With these efficient facilities, you can increase the motherboard’s capabili- ties by adding hardware that performs tasks that are not part of the basic system.
  • Page 26 Follow these instructions to install add-on cards: 1. Open the chassis and then remove the slot bracket from the case where you will be installing the expansion cards. 2. Install your graphics card in the proper slot by pressing the card firmly into the slot.

  • Page 27: Connecting Optional Devices

    Connecting Optional Devices Refer to the following for information on connecting the motherboard’s optional devices: AUDIO1: Front Panel Audio header This header allows the user to install auxiliary front-oriented microphone and line-out ports for easier access. Signal Name Signal Name Function Front Panel Microphone input signal Ground used by Analog Audio Circuits...
  • Page 28 USB1/2: Front Panel USB header The motherboard has four USB ports installed on the rear edge I/O port array. Additionally, some computer cases have USB ports at the front of the case. If you have this kind of case, use auxiliary USB connector to connect the front-mounted ports to the motherboard. Signal Name Function USBPWR...

  • Page 29: Connecting I/O Devices

    Connecting I/O Devices The backplane of the motherboard has the following I/O ports: PS2 Mouse Use the upper PS/2 port to connect a PS/2 pointing device. PS2 Keyboard Use the lower PS/2 port to connect a PS/2 keyboard. Parallel Port (LPT2) Use LPT2 to connect printers or other parallel communications devices.
  • Page 30 Memo Installing the Motherboard...

  • Page 31: Using Bios

    Chapter 3 Using BIOS About the Setup Utility The computer uses the latest American Megatrends BIOS with support for Windows Plug and Play. The CMOS chip on the motherboard contains the ROM setup instructions for configuring the motherboard BIOS. The BIOS (Basic Input and Output System) Setup Utility displays the system’s configura- tion status and provides you with options to set system parameters.

  • Page 32: Bios Navigation Keys

    Press DEL/F1 to enter SETUP Press the delete key or F1 to access the BIOS Setup Utility. CMOS Setup Utility - Copyright (c) 1985-2004, American Megatrends, Inc. Standard BIOS Features BIOS Security Features Boot Configuration Features Load Optimal Defaults Advanced BIOS Features Load Best Performance Settings Advanced Chipset Features Save Changes and Exit...

  • Page 33: Updating The Bios

    Updating the BIOS You can download and install updated BIOS for this motherboard from the manufacturer’s Web site. New BIOS provides support for new peripherals, improvements in performance, or fixes for known bugs. Install new BIOS as follows: If your motherboard has a BIOS protection jumper, change the setting to allow BIOS flashing.

  • Page 34: Standard Bios Features

    Standard BIOS Features This option displays basic information about your system. CMOS Setup Utility - Copyright (c) 1985-2004, American Megatrends, Inc. Standard BIOS Features Help Item System Overview AMIBIOS Use [ENTER], [TAB] Version : 08.00.12 or [SHIFT-TAB] TO Build Date : 03/23/05 select a field.
  • Page 35 Hard Disk (Press Enter) Scroll to this item and press <Enter> to view the following screen: CMOS Setup Utility - Copyright (c) 1985-2004, American Megatrends, Inc. Hard Disk Drives Help Item Hard Disk Drives 1st Drive [HDD:SM-QUANTUM FIR] Specifies the boot sequence from the available devices.

  • Page 36: Advanced Bios Features

    Quick Boot (Enabled) If you enable this item, the system starts up more quickly be elimination some of the power on test routines. Quiet Boot(Disabled) If enabled,BIOS will show a full screen logo at boot; if disabled, BIOS will set the initial display mode to BIOS and show the diagnostic POST screen at boot.
  • Page 37 Cache L1/L2 These items show the actual CPU interal level 1/2 cache size. Hyper Threading Technology (Enabled) This item is only available when the chipset supports Hyper-Threading and you are using a Hyper- Threading CPU. Max CPUID Value Limit (Disabled) Use this item to enable or disable the Max CPU ID value limit.
  • Page 38 IDE Configuration (Press Enter) Scroll to this item and press <Enter> to view the following screen: CMOS Setup Utility - Copyright (c) 1985-2004, American Megatrends, Inc. IDE Configuration IDE Configuration Help Item ATA/IDE Configuration [Compatible] Options Legacy IDE Channels [SATA Pri, PATA Sec] Disabled Primary IDE Master [Not Detected]...
  • Page 39 SuperIO Configuration (Press Enter) Scroll to this item and press <Enter> to view the following screen: CMOS Setup Utility - Copyright (c) 1985-2004, American Megatrends, Inc. SuperIO Configuration IDE Configuration Help Item OnBoard Floppy Controller [Enabled] Allows BIOS to Serial Port1 Address [3F8/IRQ4] Enable or Disable Serial Port2 Address...

  • Page 40: Advanced Chipset Features

    Voltage Adjustment Scroll to this item and press <Enter> to view the following screen: CMOS Setup Utility - Copyright (c) 1985-2004, American Megatrends, Inc. Voltage Adjustment Help Item CPU Vcore Voltage [Auto] Options DIMM Voltage [NORMAL] Auto NB Vcore Voltage [NORMAL] 1.6000V 1.5875V...

  • Page 41: Power Management Features

    Boots Graphic Adapter Priori (PEG/PCI) This item allows you to choose which graphics controller to use as the primary boot device. Auto Detect PCI Clk (Enabled) This item allows you to enable or disable the function of detecting the PCI clock automatically. Spread Spectrum (Enabled) If you enable this function, it can significantly reduce the EMI (Electro-Magnetic Interference) generated by the system.
  • Page 42 Suspend Time Out (Disabled) This sets the timeout for Suspend mode in minutes. If the time selected passes without any system activity, the computer will enter power-saving Suspend mode. Power Button Mode (On/Off) This item lets you install a software power down controlled by the normal power button on your system.

  • Page 43: Hardware Health Features

    Hardware Health Features This option displays basic information about your system. CMOS Setup Utility - Copyright (c) 1985-2004, American Megatrends, Inc. Hardware Health Features Help Item Hardware Healthy Configure Case Open Warning [Disabled] Shutdown Temperature [Disabled] Hardware Health Configure SMART FAN Control [Enabled] SMART CPU Temperature [70]...
  • Page 44 System/CPU Temperature These items display System/CPU temperatures. CPU Fan Speed These items display CPU Fan speed. System Component Characteristics These fields provide you with information about the systems current operating status. You cannot make changes to these fields. • SYSFan2 Speed •...

  • Page 45: Bios Security Features

    BIOS Security Features This option displays basic information about your system. CMOS Setup Utility - Copyright (c) 1985-2004, American Megatrends, Inc. BIOS Security Features Security Settings Help Item Supervisor Password : Not Installed Install or Change User Password : Not Installed the password.

  • Page 46: Load Optimal Defaults

    Load Optimal Defaults This option opens a dialog box that lets you install optimized defaults for all appropriate items in the Setup Utility. Press <Y> and then <Enter> to install the defaults. Press <N> and then <Enter> to not install the defaults. The optimized defaults place de- mands on the system that may be greater than the performance level of the components, such as the CPU and the memory.

  • Page 47: Using The Motherboard Software

    Chapter 4 Using the Motherboard Software About the Software CD-ROM The support software CD-ROM that is included in the motherboard package contains all the drivers and utility programs needed to properly run the bundled products. Below you can find a brief description of each software program, and the location for your motherboard version.

  • Page 48: Running Setup

    Setup Tab Setup Click the Setup button to run the software installation program. Select from the menu which software you want to install. Browse CD The Browse CD button is the standard Windows command that allows you to open Windows Explorer and show the contents of the support Before installing the software from Windows Explorer, look for a file named README.TXT, INSTALL.TXT or something similar.
  • Page 49 Click Next. The following screen appears: Check the box next to the items you want to install. The default options are recommended. Click Next run the Installation Wizard. An item installation screen appears: Follow the instructions on the screen to install the items. Drivers and software are automatically installed in sequence.

  • Page 50: Manual Installation

    Manual Installation Insert the CD in the CD-ROM drive and locate the PATH.DOC file in the root directory. This file contains the information needed to locate the drivers for your motherboard. Look for the chipset and motherboard model; then browse to the directory and path to begin installing the drivers.
  • Page 51 Caractéristiques Processeur La 945PL-A utilise un type LGA775 de Pentium 4/Celeron D/Pentium D présentant les fonctionnalités suivantes: • Peut recevoir les processeurs Intel Pentium 4/Celeron D/Pentium D • Support un bus système (FSB) de 800/533 MHz • Supporte le CPU de technologie “Hyper-Threading”...
  • Page 52 Une interface lecteur de disquettes • Quatre connecteurs SATA à 7 broches La 945PL-A carte mère prenant en charge la maîtrise de bus UltraDMA avec vitesses de transfert de 100/66/33 Mo/s. E/S intégrées La carte mère comporte un ensemble complet de connecteurs et de ports E/S : •...
  • Page 53 Features Prozessor Der 945PL-A benutzt einen Pentium 4/Celeron D/Pentium D des Typs LGA775 und besitzt folgende Eigenschaften: • Nimmt Intel Pentium 4/Celeron D/Pentium D Prozessoren auf • Unterstützt einen Systembus (FSB) mit 800/533 MHz. • Unterstützt CPU mit “Hyper-Threading”-Technologie. “Hyper-Threading”-Technologie läßt das Betriebssystem glauben, es sei an zwei Prozessoren angeschlossen, was zwei parallele Threads auf separaten ‘logischen’...
  • Page 54 Einen 40-Pin IDE low profile-Stecker, die zwei IDE-Kanäle unterstützen • Ein Diskettenlaufwerkanschluss • Vier 7-Pin SATA Anschlüsse Die 945PL-A-Motherboard unterstützt UltraDMA Bus Mastering mit einer Übertragungsrate von 100/66/33 MB/Sek. Integrierte I/O-Schnittstellen Das Motherboard verfügt über einen kompletten Satz von I/O-Schnittstellen und Anschlüssen: •...
  • Page 55 Caratteristiche Processore Il 945PL-A sfrutta un Pentium 4/Celeron D/Pentium D di tipo LGA775 che dispone delle seguenti caratteristiche: • Compatibile con processori Intel Pentium 4/Celeron D/Pentium D • Supporta un bus di sistema (FSB) fino a 800/533 Mhz • Supporta CPU con tecnologia “Hyper Threading”...
  • Page 56 Un’interfaccia per unità disco floppy • Quattro connettori SATA a 7 pin. La scheda madre 945PL-A supporta bus master UltraDMA con tasso di trasferimento di 100/66/33 MB/s. I/O integrati La scheda madre è dotata di un set completo di connettori e porte I/O: •...
  • Page 57 Características Procesador La 945PL-A usa un tipo LGA775 de Pentium 4/Celeron D/Pentium D que lleva las sigtes. características:: • Acomoda procesadores Intel Pentium 4/Celeron D/Pentium D • Soporta un sistema de bus (FSB) de 800/533 MHz • Soporta CPU de tecnología “Hyper-Threading”...
  • Page 58 Una interfaz para unidad de disquete • Cuatro conectores 7-pin SATA La placa principal 945PL-A soporta el mastering de bus UltraDMA con índices de transferencia de 100/66/33 MB/s. I/O integrado La placa base tiene un conjunto completo de puertos I/O y conectores: •...
  • Page 59 Características Processador O 945PL-A usa um tipo LGA775 de Pentium 4/Celeron D/Pentium D que possui as seguintes características: • Acomoda processadores Intel Pentium 4/Celeron D/Pentium D • Suporta um bus sistema (FSB) de 800/533 MHz • Suporta CPU de tecnologia “Hyper-Threading”...
  • Page 60 Uma interface para unidade de disquete • Quatro conectores SATA de 7 pinos A 945PL-A motherboard suporta um domínio bus UltraDMA bus com taxas de Transferência de 100/66/33 MB/s. I/O Integrado A motherboard possui um conjunto completo de portas I/O e conectores: •...
  • Page 61 機能 プロセッサ 945PL-AはLGA775タイプのPentium 4/Celeron D/Pentium Dに対応したもので、 その特徴は次の通り： • Intel Pentium 4/Celeron D/Pentium D プロセッサが搭載可能 • 800/533MHzのシステムバス(FSB)をサポート • “ハイパースレッド技術対応のCPUを取り付け可能 ハイパースレッド（HT） 技術というのは、オペレーションシステムに2つのプロセッサが存在すると認 識させることで、実際には2つのスレッドを1つのプロセッサで同時に執行させ、平行利用を可能とす る技術です。 チップセット 945PL Northbridge (NB)とICH7 Southbridge (SB)チップセットは、実証された信頼 性と性能を持つ革新的で拡張性のあるアーキテクチャに基づいています。 945PL(NB) • 32ビットホストバスアドレシング機能対応、これでCPUが2 GBのメモリアドレス空間すべてをアクセス可能 • メモリ帯域幅は、デュアルチャネルのインターリーブモードで 最大8.5GB/秒まで可能 • 2 GB/秒 point-to-point Direct Media Interface (DMI) で...
  • Page 62 1394a FireWire (オプション) • IEEE Std 1394-1995 standard for High Performance”基準に準拠 • 搭載済みの2つの1394a ポートで、Serial Bus 1.0 とIEEE Std 1394a- 2000とに準拠した 400/200/100 Mbit/秒の転送率が可能 オーディオ(オプション) • 6チャネルをサポートするAC’97 v2.3仕様に準拠 • 48MHzサンプリングレートの16ビットステレオ全二重CODEC • DVD音声再生のダブルサンプリングレート(96KHz)に対応 • Direct Sound 3D に対応 • Intel High Definition Audio規格に準拠することで、95dB S/N率の8チャ ネル...
  • Page 63 특징 프로세서 945PL-A 는 다음과 같은 특징을 지닌 팬티엄 4/셀러론 D /팬티엄 D 의 GA775 타입을 사용한다: • 인텔 팬티엄 4/셀러론 D /팬티엄 D 프로세서 사용 • 800/533 MHz시스템 버스(FSB) 지원 • ”Hyper-Threading”기술 CPU 지원 ”Hyper-Threading”기술은 운영체제를 두 개의 프로세서에 연결한 것처럼 두개의...
  • Page 64 2 개의 IDE 채널을 지원하는 40핀 IDE 로우 프로파일 해더 1 개 • 플로피 디스크 드라이브 인터페이스 1 개 • 7 핀 SATA 커넥터 4개 945PL-A 마더보드는 전송 속도 100/66/33 MB/s의 UltraDMA 버스 마스터링을 지원 한다. 통합 I/O 이 메인보드에는 풀 세트의 I/O 포트와 커넥터가 있다 •...
  • Page 65 功能 處理器 945PL-A 採用LGA775型的Pentium 4/Celeron D/Pentium D，具有如下特徵： • 可搭配Intel Pentium 4/Celeron D/Pentium D 處理器 • 支援高達 800/533MHz之系統匯流排(FSB) • 支援使用超執行緒(Hyper-Threading)技術之CPU 利用“超執行緒(HT)”技術，可使作業系統在相當於裝上了兩具處理器的狀態下運 作：利用一個”實體”處理器模擬出兩個獨立的”邏輯”處理器，同時執行兩個工作 緒。 晶片組 945PL北橋(NB)及ICH7南橋(SB)晶片組在研發設計上採用了創新且具擴充性之架構，具 備優良的可靠性及性能。 945PL (NB) • 支援32位元主事匯流排定址，藉此CPU 存取整個2 GB的記憶 位址空間 • 支援的記憶體頻寬在雙通道交錯模式下高達8.5GB/秒 • 提供對ICH7的2 GB/秒點對點Direct Media Interface (DMI)，雙向1 GB/秒...
  • Page 66 1394a FireWire (選項) • 支援「IEEE Std 1394-1995 standard for High Performance」 規格 • 提供2個1394a 相容埠，提供400/200/100 Mbit/秒之傳輸速度，並符合Se- rial Bus 1.0 及 IEEE Std 1394a-2000 音效(選項) • 相容於AC'97 2.3 規格並且支援6聲道 • 16位元立體聲全雙工CODEC，取樣率48MHz • 支援DVD音訊播放的雙取樣率(96KHz) • Direct Sound 3D 相容 • 相容於Intel High Definition Audio規格，可支援95dB S/N 比的 8聲道 •...

  • Page 67: Onboard Lan

    功能 处理器 945PL-A 使用 LGA775 型 Pentium 4//Celeron D/Pentium D CPU，具备以下特点： • 支持 Intel Pentium 4/Celeron D/Pentium D 处理器 • 支持 800/533 MHz 系统总线 (FSB) • 支持“多线程”技术 CPU “多线程”技术可以让操作系统认为自己连接了两个处理器，允许两个线程并行运行， 每个线程位于同一处理器中的单独“逻辑”处理器中。 芯片组 945PL北桥 (NB) 和 ICH7 南桥 (SB) 芯片组是基于一种新型的、可扩展的架构，能提 供已经证明的可靠性和高性能。 •...
  • Page 68 3 个 32 位 PCI 扩展插槽 • 1 个 40-pin IDE 紧凑型接口，支持 2 个 IDE 通道 • 1 个软驱接口 • 4 个 7-pin SATA 接口 主板945PL-A支持 Ultra DMA 总线控制，传输速率可达 100/66/33 MB/sec。 集成 I/O 此主板具有完整的 I/O 端口和插孔： • 2 个用于连接鼠标和键盘的 PS/2 端口 • 1 个串口...
  • Page 69 Характеристики Процессор Плата 945PL-A построена на базе процессора Pentium 4/Celeron D/Pentium D LGA775 и обладает следующими характеристиками: • Размещает процессоры Intel Pentium 4/Celeron D/Pentium D • Поддерживает системные шины (FSB) с частотой 800/533MHz • Поддерживает технологию CPU “Hyper-Threading” Технология “Hyper-Threading” «убеждает» операционную систему в том, что в машине...
  • Page 70 • Один разъем для накопителя на гибких дисках • Четыре 7-штырьковых разъема SATA Плата 945PL-A поддерживает технологию захвата управления шиной UltraDMA bus mastering со скоростью передачи данных 100/66/33 МБ/сек. Интегрированный вход/выход Плата снабжена полным набором портов входа/выхода и разъемов: •...
  • Page 71 Cechy Procesor Płyta główna 945PL-A zaopatrzona jest w procesor Pentium 4/Celeron D/Pentium D typu LGA775 i charakteryzuje się następującymi cechami: • Obsługuje procesory Pentium 4/Celeron D/Pentium D firmy Intel • Obsługuje szynę systemowa (FSB) 800/533MHz • Zabezpiecza technologię CPU “Hyper-Threading”...
  • Page 72 • Jedno złącze obsługujące stacje dyskietek • Cztery 7-nóżkowe złącza SATA Płyta główna 945PL-A obsługuje szynę UltraDMA z szybkością transferu 100/66/33 MB/s. Zintegrowane We/Wy Płyta głwna wyposażona jest w pełny zestaw gniazd i złączy We/Wy: • Dwa gniazda PS/2 dla myszy i klawiatury •...
  • Page 73 Vlastnosti Procesor Základní deska 945PL-A je urèena pro procesory Pentium 4/Celeron D/Pentium D LGA775 a mùže nabídnout následující vlastnosti: • Určeno pro procesory Intel Pentium 4/Celeron D/Pentium D • Podporuje taktování systémové sběrnice (FSB) na frekvenci 800/533 MHz • Podporuje technologii CPU „Hyper-Threading“...
  • Page 74 • Jedno rozhraní pro disketovou mechaniku • Čtyři 7kolíkové konektory SATA Základní deska 945PL-A podporuje sběrnici Ultra DMA s přenosovými rychlostmi 100/66/33 MB/ Integrovaný vstup/výstup Základní deska je vybavena kompletní sadou vstupních portů a konektorů I/O: • Dva porty PS/2 pro myš a klávesnici •...
  • Page 75 Caracteristici Procesorul 945PL-A utilizează Pentium 4/Celeron D/Pentium D de tipul LGA775, având următoarele caracteristici: • Funcţionează cu procesoare Intel Pentium 4/Celeron D/Pentium D • Funcţionează cu bus sistem (FSB) de 800/533 MHz • Este compatibilă cu unităţi centrale dotate cu tehnologia „Hyper- Threading”...
  • Page 76 O interfaţă pentru unitate floppy • Patru conectoare SATA 7 Placa de bază 945PL-A suportă bus mastering UltraDMA cu viteze de transfer de 100/66/33 MB/s I/O integrată Placa de bază este dotată cu un set complet de porturi şi conectoare I/O: •...
  • Page 77 Спецификация Процесор Дънната платка 945PL-A поддържа Pentium 4/Celeron D/Pentium D тип LGA775 със следните спецификации: • поддръжка на процесори Intel Pentium 4/Celeron D/Pentium D • поддръжка на системна шина със скорост 800/533MHz • поддръжка на процесори с технология “Hyper-Threading" Технологията “Hyper-Threading" позволява да се “излъже” операционната система, че работи...
  • Page 78 • един конектор за флопидисково устройство • четири 7-pin SATA конектора Дънната платка 945PL-A поддържа UltraDMA директно управление на шината със скорост на обмен 100/66/33 MB/s Интегриран Вход/Изход контролер Дънната платка има пълен набор от I/O портове и конектори: •...
  • Page 79 Jellemző Processzor A 945PL-A LGA775 típusú Pentium 4/Celeron D/Pentium D számára készült, és a következő jellemzőkkel bír: • Intel Pentium 4/Celeron D/Pentium D processzorokkal működik • 800/533 MHz sebességű rendszerbuszt (FSB) támogat • Támogatja a „Hyper-Threading” technológiát használó központi egységeket A „Hyper-Threading”...
  • Page 80 Egy 40 tűs lapos IDE foglalat, amely két IDE eszközt képes kiszolgálni • Egy hajlékonylemez meghajtó interfész • Négy 7 tűs SATA csatlakozó A 945PL-A alaplap támogatja az UltraDMA bus mastering megoldást, 100/66/33 MB/s sebességen Beépített I/O Az alaplapot az I/O portok és csatlakozók teljes készletével szerelték fel: •...
