AOK LED Light Company Limited
iM LED Mini Street Light Installation Manual
iM LED Mini Street Light Installation Manual
iM LED Mini Street Light Installation Manual
Rated
No.
Model Name
Power
1
AOK-20WiM
20W
2
AOK-30WiM
30W
3
AOK-40WiM
40W
4
AOK-50WiM
50W
iM LED Mini Street Light Installation Manual
Outer Dimension: (mm)
iM LED Mini Street Light Installation Manual
Cable Connecting:
iM LED Mini Street Light Installation Manual
Operating Voltage
3000/4000/5000/5700/6500K
AC90-305V 50/60Hz
3000/4000/5000/5700/6500K
AC90-305V 50/60Hz
3000/4000/5000/5700/6500K
AC90-305V 50/60Hz
3000/4000/5000/5700/6500K
AC90-305V 50/60Hz
Color Temperature
Net Weight
CRI
Lifespan
Ra≥70
50000h
Ra≥70
50000h
Ra≥70
50000h
Ra≥70
50000h
2.5Kg
2.5Kg
2.55Kg
2.55Kg
Advertisement
Table of Contents
Related Manuals for AOK iM LED Mini Series
Summary of Contents for AOK iM LED Mini Series
- Page 1 AOK LED Light Company Limited iM LED Mini Street Light Installation Manual iM LED Mini Street Light Installation Manual iM LED Mini Street Light Installation Manual Rated Color Temperature Net Weight Model Name Operating Voltage Lifespan Power 3000/4000/5000/5700/6500K 2.5Kg AOK-20WiM AC90-305V 50/60Hz Ra≥70...
- Page 2 Mouting the Fixture: iM LED Mini Street Light Installation Manual Maintenance: 1. The periodically cleanning can maintain the performance of the luminaire. Only clean the fixture with soft cloth; 2. Cut-off the power supply before proceeding mataintenance; 3. Only the professional personel can proceed the maintenance; 4.
