Rec 】 Call saving mode selection key, can call saving
user mode, range for:
kinds of call saving mode.
Save 】 Saving modes selection key, can save all
current switching channels and current states, range for:
1 】 ~
24 】 , a total of 24 kinds of saving modes.
If power fails suddenly, the device will
NOTE
automatically save to the current using mode,
and do not need reset when power on again.
Esc 】 The button exits the current state to the top
level state.
How to switch between input and output way
DXP A1616 can rapidly switch any way signals by front
panel buttons, specific operations are as follows:
1. Press front panel number button, select the input way,
such as choosing
3 】 for input way;
2. Press again front panel number button, select the
output way, such as choosing
3. After selection, press
Input way: currently connect way for
NOTE
switching signal;
Output way: the connect way of peripheral display
device.
1 】 ~ 9 】 button on the panel means way1 to way9.
Way above 10 can be selected combined
0 】 ~ 6 】 button.
How to switch from one input to all outputs
1. Press button on front panel, for example, choose 2 】 ;
2. Press
ALL 】 , and finish switching input2 to all
outputs.
Also, you can get the same operation effect by the
following ways:
1. Press button on front panel, for example, choose
ALL 】 ;
2. Choose input way, for example, button
3. Press
Enter 】 to confirm.
How to close one output way
1. Press button
0 】 on front panel;
2 .Choose output way, for example, button
3. Press
Enter 】 to confirm.
How to close all output ways
1. Press button
0 】 on front panel;
2. Press button
ALL 】 on front panel.
Also, you can get the same operation effect by the
following way:
1. Press button
ALL 】 on front panel;
2. Press button
0 】 on front panel;
3. Press
Enter 】 to confirm.
Address: S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone, Xiamen, Fujian Province, P.R.C
Tel: 00865925771197
Email: sales@rgblink.com
0 】 ~ 24 】】 , a total of 25
5 】 for output way;
Enter 】 to confirm.
10+ 】 with
2 】 ;
8 】 ;
Fax:00865925771202
http://www.rgblink.cn
How to set one-to-one correspondence for
input and output way
1. Press button
Rec 】 on front panel;
2. Press button
0 】 on front panel;
3. Press
Enter 】 to confirm.
How to save pre-set input and output way
1. Press button
Save 】 on front panel;
2. Can select 24 modes from button
for example, choose button
3. Press
Enter 】 to confirm.
How to call pre-set input and output way
saving mode
1. Press button
Rec 】 on front panel;
2. Can select 25 modes from button
for example, choose button
3. Press
Enter 】 to confirm.
O 】 is default for one-to-one correspondence
NOTE
for input and output way. That is input 1 】 is
corresponding to output 1 】 , input 2 】 is
corresponding to output 2 】 ...
How to factory reset
1. Press button
Menu 】 on front panel;
2. Press button
30+ 】 ( 30+ 】 reuse for DOWN
arrow key, button
key ) , make RESET option for selected state;
3. Press
Enter 】 to confirm and enter the
initialization interface;
4. Press any key according to the LCD hint and
complete factory reset.
How to read device related information
1. Press button
Menu 】 on front panel;
2. It is default for STATUS option, if it is not selected,
press
30+ 】 or
for DOWN arrow key, button
UP arrow key ) and select STATUS;
3. Press
Enter 】 to confirm, read the information
by button
30+ 】 DOWN arrow key or button
20+ 】 UP arrow key.
How to set LOGO display when power on
1. Press button
Menu 】 on front panel;
2. Press
30+ 】 or
for DOWN arrow key, button
UP arrow key ) and select LOGO;
3. Press
Enter 】 to confirm, and enter LOGO
switch setting, LOGO ON or OFF at boot can be
set.
1 】 ~ 24 】 ,
2 】 ;
0 】 ~ 24 】 ,
7 】 ;
20+ 】 reuse for UP arrow
20+ 】 ( Now
30+ 】 reuse
20+ 】 reuse for
20+ 】 ( Now
30+ 】 reuse
20+ 】 reuse for
DXP A1616 Quick Start
Rev 1.0
Page 2 of 3
