RGBlink DXP A1616 Quick Start

DXP A1616 –
For full installation, configuration, and operation details, please refer to
NOTE
the DXP A1616 user manual, which is available at www.rgblink.com.
This guide provides quick start instructions for an experienced installer
to set up and operate the DXP A1616.
Installation and cabling features
Rear Panel
Connections
1
CVBS Input
2 CVBS Output
3
RS232 IN
Step 1-Mounting
Turn off or disconnect all equipment power sources.
Step 2-CVBS Input
Can receive standard video signal from player,
camera and so on. Standard BNC connector,
support resolution 480i and 576i (PAL, NTSC
and SECAM compatible).
Step 3-CVBS Output
Composite output can be gone to composite
monitor or device which can be compatible
with PAL and NTSC standard.
Step 4-RS232 In
Connecting serial communication interface of RS232
control protocol, can connect central control device,
such as CP 2048.
Step 5-RS232 Out
Serial communication interface of multiple devices
cascading control, can connect many sets of DXP
devices.
Step 6-Power
Plug in power cord which has IEC connector, DXP
A1616 supports AC power from 85 to 264V, 50-60Hz,
which means world wide compatible.
Power On
Push power switch to ON position. LCD module on the
front panel will show RGBLINK and DXP A1616
model information, and go into self verification. For the
first setup, it is default for factory setting. User can
operate DXP A1616 through the menus on LCD panel.
Address: S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone, Xiamen, Fujian Province, P.R.C
Tel: 00865925771197
Email: sales@rgblink.com
VIEW SIZE THE WORLD
Quick Start
4 Power Switch
RS232 OUT
5
6 Power IEC-3 port
Fax:00865925771202
http://www.rgblink.cn
Local Control Front Panel Operation
Function Button
0 】 ~ 9 】 Digital button: selection button for
input and output channel, used to set video signal
input and output channel, also, can be used to number
choice of save or call saving modes.
0 】 button can also be used to shut down
NOTE
the channel output.
10+ 】 , 20+ 】 ,
means decimal.
20+ 】 , 30+ 】 function reuse button:
Push Menu 】 to enter the menu, press
arrow keys, 30+ 】 DOWN arrow keys, and select
the menu option.
20+ 】 can be used as UP arrow keys;
NOTE
30+ 】 can be used as DOWN arrow keys.
ALL 】 Used as distributor selection, can set a
certain input to all outputs.
F1 】 Fast call user save mode 1;
F2 】 Fast call user save mode 2;
Menu 】 Related menu includes: STATUS, RESET,
MATRIX, LOGO.
Mode 】 Audio and video switching key, used to
select 3 modes, such as "Audio and video sync
switching AV", "Audio switching A", "Video
switching V", it is default for "Audio and video sync
switching AV".
Enter 】 confirm button, when functional input is
confirm button, and press
menu, it displays the current input/output state, "/"
means empty, and not choose input signal source.
30+ 】 +system function button,
20+ 】 UP
Enter 】 before enter
DXP A1616 Quick Start
Page 1 of 3
Rev 1.0
