Summary of Contents for PEGAS CRAFTAP SMART
- Page 1 Revolution in beer industry Electronic device for fast and foam-free dispense of beverages in glass and metal growlers. Designed for minibreweries, bars, pubs, and beer restaurants Press one button to dispense...
- Page 2 CRAFTAP SMART Short manual of work beerinnovations.com with the menu Working with the device on standby («0» is displayed) One short button press: "+/-" — setting up a random volume to dispense; MENU PURGE "1", "2" or "3" — start dispense of a pre-set volume.
-
Page 3: Service Menu Access
CraftPad b. insert the bottle Light flow control switch for CrafTap Smart. (ref. to manual of Dispensing, section 1); c. open the gas supply;... - Page 4 CRAFTAP SMART | Service menu Service menu sections If you do not work in service menu (available after accessing menu) for 20 sec., it locks up. Enter your password to unlock. Setting the Volume needed Using the volume setting function you can pre-set required volume for each button "1", "2"...
- Page 5 CRAFTAP SMART Service Manual beerinnovations.com For trouble-free service and fulfilment of the warranty obligations declared by the producer we recommend to service the device regularly. The short service manual provided can be used as a checklist. We recommend to keep it near the device.
- Page 6 CRAFTAP SMART | Service Manual For sanitary-hygienic treatment you need: • gas bottle with carbon dioxide equipped • cleaning cloth; with a gas pressure regulator; • lint-free napkin; • keg for cleansing liquid • soft domestic sponge; recommended volume — not less than 20 liters (5 gal);...
- Page 7 When using CraftPad Light for CrafTap Smart, open the beverage supply tap to which the washing keg is connected. Then start the cleansing process according to section 6. After the end of the time needed for a treatment stage, close the beverage supply tap to which the whashing keg is connected.
-
Page 8: Final Stage
CRAFTAP SMART | Service Manual Washing agent Disconnect the intake cap from the washing Wash flask drainage line by pumping washing keg without disassembling the gas supply liquid appropriate to the a treatment stage and the beverage supply hoses. through current it. - Page 9 CRAFTAP SMART | Service Manual Remove the plate from the drip tray. Twist off the Wash up all the parts with running water sleeve of filling head, disconnect the gasket, remove and wipe them dry with a clean lint-free the seal out of the groove, and the seal out cloth.
- Page 10 CRAFTAP SMART Installation Manual beerinnovations.com 750 mm max 45 mm 400 mm To install the device quickly, you need: • 10, 13, 18, 35...70 mm drills; • flat-head screwdriver; • 13 mm wrench; • plastic hoses for beverage and gas supply, Make sure that installation place matches to the dispensing unit and flask drainage:...
- Page 11 CRAFTAP SMART | Installation Manual Install the device on the countertop Put washers and screw nuts on the pins and fasten in the holes drilled. the device at the countertop by tighting the nuts up. Insert the stem in the central hole under the countertop Twist the drip tray onto the stem end, having so that its threaded end is out of the cam's hole.
- Page 12 npm-group.com | beerinnovations.com...
