  • Page 1 SMART ECO WÄRMEPUMPE BESCHREIBUNG HEATPUMP MANUAL Danke, dass Sie sich für eine Peraqua Wärmepumpe entschieden haben. Diese Anleitung enthält alle Informationen zur Installation und optimalen Nutzung. Bitte lesen Sie die Anleitung sorgfältig durch und bewahren Sie diese für später auf.
  • Page 2: Table Of Contents

    Übersicht Ⅰ . Einführung ..................1 Sicherheitshinweise ..................1 Wichtige Eigenschaften ................1 Technische Details ..................2 Ⅱ . Installationsanleitung ..............3 Wärmepumpentransport................3 Optimale Standort ..................4 Wasseranschluss ..................5 Elektrischer Anschluss ................6 Erste Inbetriebnahme ................. 7 III Bedienungsanleitung ..............8 LED Controller ..................
  • Page 3: Ⅰ . Einführung

    Ⅰ . Einführung Sicherheitshinweise Achtung: Elektroschock Gefahr Immer den Strom und Wasserkreislauf der Wärmepumpe auuuschalten, bevor an der Wärmepumpe gearbeitet wird ! - Ein konzessionierter Elektriker muss die Wärmepumpe elektrisch anschließen. - Die Wärmepumpe muss mit einem 30 mA Fehlerstromschutzschalter abgesichert werden. - Ein Hauptschalter zur Unterbrechung des Stromkreislaufs der Wärmepumpe ist für Wartungsarbeiten vorzusehen - Die Stromversorgung muss im Falle unnatürlichen Verhaltens der Wärmepumpe...
  • Page 4: Technische Details

    1.Die Wärmepumpen sind zur Erwärmung des Schwimmbeckens gedacht. ℃ ; . Außerhalb dieser Temperaturen kannkeine 2.74543~74545arbeitet bei Lufttemperaturen von+0 bis 43℃ Gewährleistung übernommen werden. 3.Oben genannte Details können durch technische Weiterentwicklung eventuell abweichen. Auf jeder Wärmepumpe sind die technischen Details zu finden...
  • Page 5: Installationsanleitung

    Abmessungen: Name Size(mm) Model Model 74543 74544 74545 1000 Oben genannte Daten können durch Weiterentwicklung eventuell abweichen. Ⅱ . Installationsanleitung Achtung! Die Wärmepumpe muss von einem Fachmann angeschlossen werden! Wärmepumpentransport 1. Die Wärmepumpe wird am besten in der Originalverpackung transportiert.
  • Page 6: Optimale Standort

    Optimale Standort Der Standort der Wärmepumpe ist für die Effektivität der Pumpe von enormer Bedeutung. Bedenken Sie bitte folgende Faktoren zum Aufstellort. Die Wärmepumpe muss unbedingt im Freien aufgestellt werden! Aufstellen im Freien und Beachten der unten angeführten Abstände Nicht mehr als 10 Meter Abstand zwischen Schwimmbad und Wärmepumpe Gute Zugänglichkeit zur Montage und Wartung Drainage für Kondenswasser Bitte folgendes Beachten:...
  • Page 7: Wasseranschluss

    At least 300mm Warnung! Die Wärmepumpe darf nicht mit flexiblem Schlauch verroht werden, da ansonsten der Wärmetauscher At least 300mm beschädigt werden könnte! Die Wärmepumpe muss immer mit At least 300mm starrem PVC – Rohr verrohrt werden! At least 300mm 3....
  • Page 8: Elektrischer Anschluss

    Diese Skizze stellt lediglich ein Schema bezüglich des Anschluss dar. Elektrischer Anschluss - Der elektrische Anschluss muss von einem konzessionerten Elektriker anhand des unten abgebildeten Anschlussplans durchgeführt werden. - Die Wärmepumpe muss mit der passenden Spannung betrieben werden, die am Gerät zu finden ist.
  • Page 9: Erste Inbetriebnahme

    Schutz- und Kabelspezifikationen MODELL 74543 74544 74545 Nennstrom A Trennschalter Fehlerstrom-Schutzschalter mA Sicherung (mm ) Netzkabel 3×1.5 3×2.5 3×2.5 (mm ) 3×0.5 3×0.5 3×0.5 Datenkabel ※ Oben angegebene Daten können ohne Angabe geändert werden. Achtung: Die oben angegebenen Daten sind für ein Netzkabel bis 10 Meter Länge ausgelegt. Bei längeren Kabeln muss der Durchmesser erhöht werden!
  • Page 10: Bedienungsanleitung

    am Controller aus. Wenn die Spannung wiederhergestellt wird, schalten Sie am Controller die Wärmepumpe wieder ein. Überprüfen Sie die Parameter und ändern Sie diese, falls nötig. - Während stürmischem Wetter ist es notwendig die Wärmepumpe auszuschalten. III Bedienungsanleitung LED Controller Water Temp And Time Setting Heat...
  • Page 11: Permanente Anzeige

    Permanente Anzeige Die LED Anzeige zeigt die aktuelle Zeit an, wann die Wärmepumpe ausgeschaltet ist. Die LED Anzeige zeigt die aktuelle Wassertemperatur an, wann die Wärmepumpe eingeschaltet ist. Controller Einstellungen 1. Gewünschte Poolwassertemperatur Dies kann bei ein- oder ausgeschalteter Wärmepumpe eingestellt werden. Drücken Sie UP-ARROW oder DOWN-ARROW um die gewünschte...
  • Page 12: Ⅳ . Wartung

    Drücken Sie wieder um die Stunde einzustellen. Drücken Sie oder zum Einstellen. Bevor die Zeit zum Blinken aufhört, drücken Sie wieder um die Minute einzustellen. Drücken Sie oder zum Einstellen. Nach dem Einstellen, drücken Sie und die Wassertemperatur wird angezeigt. 30 Sekunden später wird die Wärmepumpe in den normalen Modus zurückwechseln.
  • Page 13: Ⅴ . Problembehandlung

    Händler kontaktieren PP 5 Air temp Sensor Fehler Händler kontaktieren PP 6 Compressor exhaust Überlast Schutz Händler kontaktieren 74543~74545: Bei Temperaturen <0℃, stoppt PP 7 Automatischer Schutz die:Wärmepumpe automatisch (Kein Fehler) 888/EE8/Ande Problem der Kommunikation zwischen dem Händler kontaktieren re Fehlercodes...
  • Page 14 INSTALLATION AND USER MANUAL Thank you for choosing our product and trusting our company. This manual is to provide you with necessary information for optimal use and maintenance, please read it carefully and keep it for subsequent use.
  • Page 15 Content Ⅰ . Introduction ................14 Safety precaution ..................14 Important features of this product ............14 Parameters of product range ..............15 Ⅱ . Installation Guide ............... 16 Transport it in proper manner ..............16 Determining Optimum installation position ..........17 Water pipe connection ................
  • Page 16: Ⅰ . Introduction

    Ⅰ . Introduction Safety precaution Caution: Danger of electric shock Always switch off power supply before working on the heat pump and stop the hydraulic circuit. - The swimming pool heat pump must be installed by a qualified electrician. - Always install a differential protective device with a sensitivity of 30 mA on the distribution unit before the electrical box.
  • Page 17: Parameters Of Product Range

    *C.O.P: Coefficient of performance Note: ℃ 74543~74545 can work well under air temp +0 ~43℃; performance cannot be guaranteed outside the operating ranges and must take account the exterior conditions of use identified to select suitable mode (such as location, area of swimming pool, and numbers of swimmer.) Above parameters are subjected to adjustment periodically for technical improvement with further notice.
  • Page 18: Installation Guide

    Dimension: Name Size(mm) Model 74543 74544 74545 1000  Above data is subject to modification without notice Ⅱ . Installation Guide Attention! This swimming pool heat pump must be installed by a skilled team. Transport it in proper manner 1. Transport it in original package.
  • Page 19: Determining Optimum Installation Position

    Determining Optimum installation position The location of the swimming pool heat pump is very important for efficient operation, think about the following factors when choose the proper place:  Avoidance of air recirculation  Easy for wire and pipe connection and Water pipe line of long water lines (not longer than 10m.) from heater to pool.
  • Page 20: Water Pipe Connection

    At least 300mm !!Warning: The machine must not be hung onto the wall with soft pipe since the inlet/outlet At least 300mm union on the machine can’t hold weight. At least 300mm At least 300mm The machine must always be connected with hard pipe! 3....
  • Page 21: Electric Connection

    Note: The installation diagram and layout of the pipes are for reference only. Electric connection - Wiring must be handled by a professional technician according to the circuit diagram as following. - Connect the heat pump to appropriate power supply and the voltage should comply with the rated voltage of each model stated on the specification.
  • Page 22: Trial After First Installation

    Recommendation for protecting devices and cable specificatio MODEL 74543 74544 74545 Rated Current A Breaker Residual Action Current mA Fuse Power Cord (mm2) 3×1.5 3×2.5 3×2.5 Signal cable ( mm2 ) 3×0.5 3×0.5 3×0.5 Above data is subject to modification without notice.
  • Page 23: Operation Instruction

    III Operation instruction Water Temp And Time Setting Heat Timer Indicator Light Power On/Off Time Setting Timer On Time Setting Time Setting Power on/off CLOCK Set local time. TIME OFF Set the time required machine auto-stop. Light Shows the auto-stop time being set. TIME ON Set the time required machine auto-work.
  • Page 24: Automatic On/Off

    It can be adjusted both when the machine is on or off. A. Press UP-ALLOW key or DOWN-ALLOW key to set to your required pool water temperature. B. The numbers in the LED screen will flash during your operation. C. After five seconds, it will stop flashing and be saved, the LED screen will return to the permanent display.
  • Page 25: Maintenance

    Ⅳ . Maintenance Caution: Danger of electric shock “Cut off” power supply of the heater before cleaning, examination and repairing In winter season when you don’t swim: A. Cut off power supply to prevent any machine damage Drain water clear of the machine. !!Important: Unscrew the water nozzle of inlet pipe to let the water flow out.
  • Page 26: Ⅴ . Trouble Shooting

    Ⅴ . Trouble shooting Common faults Phenomenon Possible reason A. The fan motor stops automatically for defrost. B. There will be sound from the solenoid valve when A.Noticeable White vaporous machine starts or ends to defrost. cold air or water. C.
  • Page 27: Failure Code

    Failure code Failure Failure description Action code EE 1 High pressure protection Contact your dealer. EE 2 Low pressure protection Contact your dealer. Check if there is no water EE 3 Low water pressure protection through the machine; make sure the pump is on. Failure connection due to loose wire terminal of EE 4 Contact your dealer.
