RESI®
Date:
RESI
Version:
Informatik &
Edited by:
Automation
Reviewed by:
GmbH
Reviewed by:
RESI-KNXGW-ETH
Great care has been taken in the creation of the text, illustrations and
program examples in this manual. The editors and publishers accept
no responsibility for any inadvertent omission of entries or for
typographical or other errors herein. Nor can they be held responsible
or liable for consequences arising from any errors herein.
This manual is subject to copyright law. All rights are reserved.
This manual may not be copied in part or whole in any form including
electronic media without the written consent of RESI. Neither may it be
transferred in any other language suitable for machines or data
processing facilities. Also rights for reproduction through lecture, radio
This documentation and the accompanying software are copyrighted
© Copyright 2005 – 2019 by RESI Informatik & Automation GmbH
09.02.2019
Customer:
03.33
Title:
DI HC Sigl, MSc
DI HC Sigl, MSc
Project:
-
RESI-KNX-GW
or television transmission are reserved.
by RESI.
RESI-KNX-GW,RESI-KNXGW-ETH manual
Pages
41
Advertisement
Table of Contents
Related Manuals for Resi RESI-KNX-GW
Summary of Contents for Resi RESI-KNX-GW
-
Page 1: Resi-Knx-Gw
This manual is subject to copyright law. All rights are reserved. This manual may not be copied in part or whole in any form including electronic media without the written consent of RESI. Neither may it be transferred in any other language suitable for machines or data processing facilities. -
Page 2: History
RESI® 1 History Date Editor Description 13.01.10 DI HC Sigl, MSc Initial release 05.05.15 DI HC Sigl, MSc Correction to the query group function 09.02.19 DI HC Sigl, MSc Adding RESI-KNXGW-ETH module Date Page RESI-KNX-GW,RESI-KNXGW-ETH manual Title: 09.02.2019... -
Page 3: Table Of Contents
1 HISTORY ................................2 2 CONTENT ................................3 3 IMPORTANT SECURITY NOTES ........................5 4 GENERAL INFORMATION..........................7 5 TECHNICAL DATA FOR RESI-KNX-GW ......................8 6 TECHNICAL DATA FOR RESI-KNXGW-ETH ....................9 7 MOUNTING AND CONNECTIONS ........................10 ............................10 SSEMBLING RESI-KNX-GW .................... - Page 4 Data type “DWORD” ........................30 8.3.14 Data type “FLOAT” ........................31 8.3.15 Data type “STRING” ........................31 8.3.16 Data type “GENERIC” ........................ 31 8.3.17 9 RESI-KNXGW-ETH OPERATION MODES ...................... 32 10 RESI-KNXGW-ETH WEB CONFIGURATION ....................33 10.1 HOWTO ......................... 34 SETUP ADDRESS 10.2 HOWTO .......................
-
Page 5: Important Security Notes
Operating our device close to equipment, which do not comply with EMC directives, can influence the functionality of our device, leading to malfunction or in worst case to a breakdown of our device! Date Page RESI-KNX-GW,RESI-KNXGW-ETH manual Title: 09.02.2019... - Page 6 Dimensions of the enclosures or enclosures accessories may show slight tolerances on the specifications provided in these instructions! Modifications of this documentation is not allowed! In case of a complaint, only complete devices returned in original packing will be accepted! Date Page RESI-KNX-GW,RESI-KNXGW-ETH manual Title: 09.02.2019...
-
Page 7: General Information
RESI® 4 General Information With the RESI-KNX-GW or RESI-KNXGW-ETH gateways, a KNX bus system can be integrated in almost every system with a RS232/RS485 or Ethernet interface. The gateway is a serial interface for connection to the KNX with an integrated 2 wire KNX bus-coupler. The time-critical KNX communication is done from the gateway itself, and all telegrams will be transferred in plain ASCII text commands to the connected host system either via serial line or via Ethernet socket. -
Page 8: Technical Data For Resi-Knx-Gw
RESI® 5 Technical data for RESI-KNX-GW Technical data Power supply 12…48 V= +/-10% Supply voltage Storage temperature -20...85 °C Power LED indicator Operation 0...60°C temperature Power consumption <0.5W Humidity 25...90 % rH not condensing Protection class IP20 (EN 60529) Dimensions LxWxH 17.5mm x 90mm x 58mm... -
Page 9: Technical Data For Resi-Knxgw-Eth
RESI® 6 Technical data for RESI-KNXGW-ETH Technical data Power supply 12…48 V= +/-10% Supply voltage Storage temperature -20...85 °C Power LED indicator Operation 0...60°C temperature Power consumption <1.1W Humidity 25...90 % rH not condensing Protection class IP20 (EN 60529) Dimensions LxWxH 35.8mm x 90mm x 58mm... -
Page 10: Mounting And Connections
7 Mounting and Connections Assembling Our RESI-KNX-GW or RESI-KNXGW-ETH gateways are designed for mounting on a 35mm DIN-EN50022 rail. Please note, that there are symbol photos used in the mounting pictures below. At first, put the gateway with the top side on the DIN rail (1). -
Page 11: Clamps And Leds For Resi-Knx-Gw
KNX connection has an error KNX activity LED, this LED is on while the gateway send or receives KNX telegrams HOST HOST-LED, flashes, when host sends/receive ASCII telegrams Table: Description of connectors and LEDs of the RESI-KNX-GW gateway Date Page RESI-KNX-GW,RESI-KNXGW-ETH manual Title: 09.02.2019... -
Page 12: Dip Switch Settings For Resi-Knx-Gw
Select serial interface for ASCII host OFF=RS232 ON=RS485 Function Selects a special function: Definition OFF=The gateway uses a compatibility format (>) ON=The gateway uses the RESI format (#) Table: Description of DIP switch functions Date Page RESI-KNX-GW,RESI-KNXGW-ETH manual Title: 09.02.2019... -
Page 13: Clamps And Leds For Resi-Knxgw-Eth
LINK This LED is on if Ethernet port is connected correctly to network DATA The LED shows the data flow on the Ethernet port Table: Description of connectors and LEDs of the RESI-KNXGW-ETH gateway Date Page RESI-KNX-GW,RESI-KNXGW-ETH manual Title: 09.02.2019... -
Page 14: Dip Switch Settings For Resi-Knxgw-Eth
Selects a special function: MODE OFF=The gateway uses a compatibility format (>) ON=The gateway uses the RESI format (#) Factory config ON: while restarting the module, the module restores the factory defaults for the system. Wait for approx. 30 seconds until the STATE+CFG LED flash very fast. -
Page 15: Wiring Diagram For Resi-Knx-Gw
RESI® Wiring diagram for RESI-KNX-GW Illustration: wiring diagram of gateway Date Page RESI-KNX-GW,RESI-KNXGW-ETH manual Title: 09.02.2019... -
Page 16: Wiring Diagram For Resi-Knxgw-Eth
RESI® Wiring diagram for RESI-KNXGW-ETH Ethernet Power 12-48Vdc Illustration: wiring diagram of gateway Date Page RESI-KNX-GW,RESI-KNXGW-ETH manual Title: 09.02.2019... -
Page 17: Functional Description
ASCII string to the host, due to the fact, that this communication is bidirectional (full duplex). In RS485 mode the RESI-KNX-GW gateway puffers a received KNX telegram internally, until the host polls the internal memory with the command #GET<cr>. The gateway can buffer up to 32 KNX telegrams internally in its queue. -
Page 18: Knx Group Addresses
Summary of the commands and messages Example: ---- 8.1.4 Request gateway version Command: Description: Returns the product description and the version Answer: RESI-KNX-GW Vn.n.n n.n.n .... software version Example: RESI-KNX-GW V3.0.0 8.1.5 Request copyright Command: Description: Returns the copyright. Answer:... -
Page 19: Request Device Setting
Set the physical address of the gateway to 1.1.156, enable output of KNX source address, disable output of KNX address in hexadecimal form and disable full duplex mode (Use #GET<cr> for polling). #SETUP=1.1.156;ON;OFF;OFF same settings but with address as hexadecimal number #SETUP=x119C;ON;OFF;OFF Date Page RESI-KNX-GW,RESI-KNXGW-ETH manual Title: 09.02.2019... -
Page 20: Perform Software Reset
RESI® 8.1.8 Perform software reset Command: #RESET Description: Performs a software RESET Answer: none Example: ---- Date Page RESI-KNX-GW,RESI-KNXGW-ETH manual Title: 09.02.2019... -
Page 21: Activate Direct Mode
Sending KNX group 31.7.0 as 2-byte FLOAT16 data type with float value 3.14 // Sending KNX group 1.0.0 as BIT with value 0 #WDM:09:BCFFFE0800E100802B // Sending KNX group 31.7.0 as VALUE with 3.14 #WDM:0B:BCFFFEFF00E30080013AE5 Date Page RESI-KNX-GW,RESI-KNXGW-ETH manual Title: 09.02.2019... -
Page 22: Deactivate Direct Mode
// Sending KNX group 1.0.0 as BIT with value 0 #WDM:09:BCFFFE0800E100802B // Receiving KNX group 31.7.255 as VALUE with 23.44 #RDM:0B:BCFFFEFFFFE300800C94B9 // Sending KNX group 31.7.0 as VALUE with 3.14 #WDM:0B:BCFFFEFF00E30080013AE5 // Deactivate direct mode #DDM Date Page RESI-KNX-GW,RESI-KNXGW-ETH manual Title: 09.02.2019... -
Page 23: Request Knx Group Address Settings
Answer: Settings were successful Example: Define the addresses 2.1.1 up to 2.1.8 as 1-6 Bit KNX data type and enable transmit and receive of KNX telegrams. #DG2.1.1-2.1.8=BIT;RW with the address in hexadecimal digit #DGx1101-x1108=BIT;RW Date Page RESI-KNX-GW,RESI-KNXGW-ETH manual Title: 09.02.2019... -
Page 24: Request Telegram Forwarding Settings
KNX group. Answer: Settings were successful Example: Enable forward of telegram for address 2.1.1 to 2.1.2, 2.1.3 and 2.1.4 #DF2.1.1->2.1.2;2.1.3;2.1.4 with the address as hexadecimal number #DFx1101->x1102;x1103;x1104 Date Page RESI-KNX-GW,RESI-KNXGW-ETH manual Title: 09.02.2019... -
Page 25: Delete The Entire Group Address Settings
8.1.17 Delete the entire group address settings Command: Description: Clear all settings for all KNX group addresses Answer: All settings cleared Example: 8.1.18 Delete the entire forwarding settings Command: Description: Delete all KNX forwarding settings Answer: All settings cleared Example: Date Page RESI-KNX-GW,RESI-KNXGW-ETH manual Title: 09.02.2019... -
Page 26: Transmit/Send A Knx Telegram
1.1.3>2.1.1=1 Comment: SRC=ON / HEX=OFF 1103>1101=1 Comment: SRC=ON / HEX=ON Receive of a temperature with the KNX group address 3.0.0 >3.0.0=23.45 Receive of an invalid data format with the KNX group address 3.0.1 >3.0.1=? Date Page RESI-KNX-GW,RESI-KNXGW-ETH manual Title: 09.02.2019... -
Page 27: Query The Status Of A Knx Telegram At The Knx
All received KNX telegrams of the internal receive queue of the gateway are transmitted to the host. The receive queue of the gateway can store up to 30 KNX telegrams. Answer: Received telegrams or nothing Example: #GET #RG2.1.1=1 #RG2.1.5=1 #RG2.1.8=1 #RG3.0.0=24.35 #RG3.0.1=18.56 Date Page RESI-KNX-GW,RESI-KNXGW-ETH manual Title: 09.02.2019... -
Page 28: Error Messages
The gateway is not connected to the KNX. If this error occurs, all telegrams will be deleted from the transmit queue. !KNX is connected The gateway is successfully connected to the KNX bus. !KNX busy The transmit queue of the gateway is full. Date Page RESI-KNX-GW,RESI-KNXGW-ETH manual Title: 09.02.2019... -
Page 29: Knx Data Types
1 Byte 8 bit value signed Range: -128...127 decimal / x00...xFF hexadecimal DPT: Note: On transmit: A decimal or a hexadecimal digit can be specified. On receive: The data will be issued in decimal form. Date Page RESI-KNX-GW,RESI-KNXGW-ETH manual Title: 09.02.2019... -
Page 30: Data Type "Uword
4 Byte 32 bit value signed -2147483648…2147483647 decimal / x00000000...xFFFFFFFF hexadecimal Range: DPT: 13.x Note: On transmit: A decimal or a hexadecimal digit can be specified. On receive: The data will be issued in decimal format. Date Page RESI-KNX-GW,RESI-KNXGW-ETH manual Title: 09.02.2019... -
Page 31: Data Type "Float
#WG1.1.1=xFF;xFE;xFC;xAB // 4 Byte Data in hex #RG1.1.1=01 // 1 Byte Data in hex #RG1.1.1=01;02;03;04;05;06 // 6 Byte Data in hex #RG1.1.1=FF;FE;FC // 3 Byte Data in hex #WG1.1.1=FF;FE;FC;AB // 4 Byte Data in hex Date Page RESI-KNX-GW,RESI-KNXGW-ETH manual Title: 09.02.2019... -
Page 32: Resi-Knxgw-Eth Operation Modes
Ethernet socket is directly forwarded to the serial line. All received data from the serial line is directly forwarded to the Ethernet socket. ASCII text socket Ethernet Socket Send KNX group Receive KNX group e.g. #WG1.2.3=23.45 e.g. #RG31.7.255=1 Power 12-48Vdc Illustration: TEXT MODE on RESI-KNXGW-ETH converters Date Page RESI-KNX-GW,RESI-KNXGW-ETH manual Title: 09.02.2019... -
Page 33: Resi-Knxgw-Eth Web Configuration
RESI® 10 RESI-KNXGW-ETH web configuration Our RESI-KNXGW-ETH gateway has a build in web server to configure basic access to the Ethernet interface. Therefore open an Internet explorer and type in the configured IP address of the selected gateway. The standard configuration for STATIC IP (See DIP switch selection of RESI-KNXGW-ETH gateway) is: ... -
Page 34: Howto Setup Ip Address
If you have problems, set the CFG DIP switch to ON and reboot the device. Wait for more than 30 seconds. The gateway will do a factory reset to the standard IP settings defined above. Don’t forget to put the DIP switch to OFF position after successful factory reset. Date Page RESI-KNX-GW,RESI-KNXGW-ETH manual Title: 09.02.2019... -
Page 35: Howto Change Socket Number
Socket number: Here you can select your desired socket number, you want to use for the Ethernet connection. Default for our converters is 1024 Please let the rest of the parameters unchanged. They are for expert usage only! Date Page RESI-KNX-GW,RESI-KNXGW-ETH manual Title: 09.02.2019... -
Page 36: Howto Change User Name And Password
Password: here you can enter a new password for accessing the web configuration. Don’t forget to save the new settings with the button SAVE below! Please let the rest of the parameters unchanged. They are for expert usage only! Date Page RESI-KNX-GW,RESI-KNXGW-ETH manual Title: 09.02.2019... -
Page 37: Howto Restart The Module Via Ethernet
RESI® 10.4 HOWTO restart the module via Ethernet First select page Reboot. Then select button Restart Module to perform a software reboot. Date Page RESI-KNX-GW,RESI-KNXGW-ETH manual Title: 09.02.2019... -
Page 38: Specifications
RESI® 11 Specifications 11.1 Dimensions of the modules RESI-KNX-GW Illustration: dimension illustration in mm Dimensions Enclosure dimensions L x W x H (mm) 17.5 x 90 x 58 Weight 55 g Colour Grey RAL7035 Material PA - UL 94 V0... -
Page 39: Drawing Of The Modules Resi-Knx-Gw
RESI® 11.2 3D Drawing of the modules RESI-KNX-GW Illustration: Dimension illustration in 3D Date Page RESI-KNX-GW,RESI-KNXGW-ETH manual Title: 09.02.2019... -
Page 40: Dimensions Of The Module Resi-Knxgw-Eth
RESI® 11.3 Dimensions of the module RESI-KNXGW-ETH Illustration: dimension illustration in mm Dimensions Enclosure dimensions L x W x H (mm) 35.8 x 90 x 58 Weight 90 g Color Grey RAL7035 Material PA - UL 94 V0 Protection class... -
Page 41: Drawing Of The Module Resi-Knxgw-Eth
RESI® 11.4 3D Drawing of the module RESI-KNXGW-ETH Illustration: 3D drawing of the enclosure Date Page RESI-KNX-GW,RESI-KNXGW-ETH manual Title: 09.02.2019...
