3–4 Test Selection Sequence
After the Trip Unit type has been selected, the Test Kit
verifies that a Trip Unit is connected through the
communication link. If no Trip Unit is connected, the
following message appears:
Digital Link Open; Check Connection
|– MORE –|
Display indicating that Trip Unit is not connected.
A Trip Unit must be properly connected before the test
sequence can continue. When this has been done, press
( F1 ) to return to the main Trip Unit selection menu.
MORE
If the Trip Unit is properly connected, the Test Kit displays
the main test-selection menu:
Press F1,F2, or F3 for test selection
|FUNCTION |HICURRENT|
. . .. . . . . . . . . . . . . . ..... .
Main test-selection menu.
If the following message appears while any test is being
run, press ( ) to restart the test.
F1
MORE
Program interrupted; restart test
|- MORE -|
. . . . .
Message indicating that test should be restarted.
If a TS-type (RMS-9, Power+, or Epic) Trip Unit is to be
tested, see Chapter 4 for detailed instructions.
If a TT-, A-, B-, or C-type (MicroVersaTrip Plus or
MicroVersaTrip PM) or Spectra (MicroVersaTrip Plus or
MicroVersaTrip PM in a Spectra RMS molded-case circuit
breaker) Trip Unit is to be tested, see Chapter 5 for
detailed instructions.
QUICK |
TVRMS2 Digital Test Kit
Chapter 3. Initialization and Setup
7
