Summary of Contents for GTD GTD-LM1506
- Page 1 LED Non‐polar Beam GTD‐LM1506 User’s Manual Guangzhou GTD Lighting Technology Co., Ltd. Tel: +86‐20‐61808296 Fax: +86‐20‐61812282 www.gtd‐lighting.com http:// ...
- Page 2 All non‐GTD brands and product names are trademarks or registered trademarks of their respective companies. GTD and all affiliated companies hereby disclaim any and all liabilities for property, equipment, building, and electrical damages, injuries to any persons, and direct or indirect economic loss associated with the use or reliance of any ...
-
Page 3: Table Of Contents
GTD‐LM1506 User Manual Contents Safety instructions ................................... 3 General guidelines ................................... 4 Packing and shipping ................................ 5 Unpacking ....................................... 5 Packing after use ..................................... 5 Accessories ..................................... 5 Product introduction ................................ 6 Installation .................................... 6 Clamps installation.................................. 6 Device installation .................................. 6 Power / Control connection .............................. 7 ... -
Page 4: Safety Instructions
GTD‐L LM1506 User M Manual Saf fety instru uctions WARNING G! Before usi ing the fixtur e, read the la atest version of the produ ct user manu ual, paying pa articular atte ntion to the safe ety instructio ons. Please ch heck www.gtd d‐lighting.com m for the late est revision/u update of the e user manual. T The manufact ture of this fix xture, are not t responsible e for damages s, resulting fr rom misuse o of this fixture, du ue to the disr egard of the ... -
Page 5: General Guidelines
The fixture is only intended for installation, operation and maintenance by qualified professional. Instructions stated in the manual must be complied. The fixture must be kept in a well‐ventilated place at least 50 cm away from any wall surface. Check if the fans or ventilation openings are unblocked. Broken or damaged cables can only be fixed or changed by certified technicians, certified local distributors or the manufacturer to ensure operational safety. Do not stick filters or other materials onto the lens. Do not modify the fixture or install other than GTD manufactured parts. For questions regarding safety operation, please contact our technical personnel or call the service hotline +8620 61808296. 4 ... -
Page 6: Packing And Shipping
GTD‐L LM1506 User M Manual cking and shipping packing Notes All p products are quality cont rolled and ch hecked for a ny faults bef fore they are e dispatched to customer s. If the fixtu ure is maged during delivery, th e ... -
Page 7: Product Introduction
GTD‐L LM1506 User M Manual oduct intro oduction 1 Lens 2 older 3 Base 4 D Menu Func ction Display Inst tallation Clam mps installa ation The fixture can b be placed on the stage or r mounted on n the truss fa acing any dire ection. Attac h the clamps s to the mou nting posit tion on the b base of the fix xture. Warning Use ... -
Page 8: Power / Control Connection
GTD‐L LM1506 User M Manual wer/ Cont trol conne ection wer connect tion Conn nection meth hod: L (Live) Br own wire E (Earth) Y Yellow / Gree en bi‐color wi re N (Neutra l) Blue wire The voltag ge and frequ ency of the power source e must be in n compliance with the one es marked o n the fixture . It is strongly re ecommended d that each f fixture are to o be connecte ed to the po wer source s separately so o that they ca an be ... -
Page 9: Control Panel
GTD‐LM1506 User Manual Control panel The control panel features touch‐sensitive buttons and LCD digital display for quick and easy setup of address code and functions menu. Press UP or DOWN to view or select the function menu. Press ENTER to choose a function and enter into corresponding sub menu. Each menu represents a specific function of the fixture. Press ENTER to select the specific function and save the changes or enter into the submenu, then press UP or ... -
Page 10: Menu Structure
GTD‐LM1506 User Manual Menu structure LM1506 – Menu Structure Revision: A Valid from firmware version: 1.0 Level 1 Level 2 Level 3 Level 4 Info Run setting Address Setting Address: 001~ XXX Setting the DMX address Value Display Pan ……, All, Off Display the channel value Slave Address Slave 1,2,3 Choose the slave address Auto‐Program Master /Slave Run auto program in master or slave Device Info Temperature Body Temperature XXX ’C/’F Body temperature Software Version X.X The software version System Setting Status Setting Console Set Addr Enable /Disable Address can be changed by console ... - Page 11 GTD‐L LM1506 User M Manual vel 1 Level 2 Level 3 Leve el 4 Info to Program Select Prog g. Program Unit 1 Prog gram 1 ~ 10 Choos se build‐in prog gram for slave 1 1 Program Unit 2 Prog gram 1 ~ 10 Choos se build‐in prog gram for slave 2 2 Program Unit 3 Prog gram 1 ~ 10 Choos se build‐in prog gram for slave 3 3 Program E dit Auto‐Program 1 1 ...
-
Page 12: Dmx Protocol
GTD‐LM1506 User Manual DMX protocol LM1506‐ DMX Protocol Revision: B Valid from firmware version: 1.0 DMX mode Default Name DMX value DMX percentage Function DMX Standard / Extended Basic (33ch) (13ch) Value 0 31 0.0% 12.2% Closed 32 63 12.5% 24.7% Open Synchronous strobe from slow to 64 127 25.1% 49.8% fast 1 1 Strobe/Shutter 0(0%) ... - Page 13 GTD‐L LM1506 User M Manual DMX m mode Defa ault Name DMX value X percentage Function MX andard / Exten nded Basic (33ch) (13ch) Valu ue 0 127 0.0% % 49.8% No function Pan continou us rotation CW from 187 50.2 73.3% slow to fast 27 7 Pan rotati on 0(0% %) ...
-
Page 14: Technical Specification
GTD‐LM1506 User Manual Technical specification Optical Light source: 15W (RGBW 4‐in‐1), quantity: 6pcs Expected average lifetime: 50000 hours Beam angle (fixed): 4°(50% peak angle), 7°(10% peak angle) Photometric Total Output (Lumen): 1900 lumens Electrical Power input, nominal: AC 100‐240V, 50/60Hz Max. Power consumption: 149W, max current: 1.5A, PF≥ 0.9 Power supply unit: Auto‐ranging electronic SMPS Main fuse: 250V/3.15A Control and programming Control channels (DMX): 33/13/33 Protocol: DMX‐512 Display: Graphic LCD backlit 16‐bit control: Dimmer, pan/tilt Physical / Installation Weight: 6 kg (13.2 lbs.) IP rating: IP20 Material: Aluminum, steel, plastic Mounting points: Two quarter‐turn locking points + attachment points for safety wire Minimum distance to combustible materials: 1.64ft. (0.5m) Minimum distance to illuminated surfaces: 3.28ft. (1m) Dynamic effects Pan/Tilt movement: Continuous rotation on pan/tilt Strobe: 1‐25Hz, synchronized, pulse effects Dimmer: 0‐100%, 16‐bit, electronic linear dimming Thermal Operating range: 14˚F to 113˚F (‐10˚C to +45˚C) Startup range: 5˚F to 113˚F (‐15˚C to +45˚C) Storage range: ‐40˚F to 140˚F (‐40˚C to +60˚C) Cooling: Active fan Humidity: ≤85% 13 ... - Page 15 GTD‐LM1506 User Manual Connections AC power: Neutrik powerCon DMX data input/output: Chassis 5‐pin Neutrik XLR (in/out) Certification and Safety EMC: EN 55103‐1:2009, EN 55103‐2:2009, EN 61000‐3‐2:2006+A2:2009, EN 61000‐3‐3:2013 Safety: EN 60598‐2‐17:1989/A2:1991 Photometric 14 ...
-
Page 16: Cleaning And Maintenance
GTD‐L LM1506 User M Manual aning and d mainten nance It is required that t the fixture s should be ke pt clean and well maintai ned to ensur re its reliabilit ty. Its lifespa n mainly dep pends on t he working e environment and proper o operation. Sh hould you hav ve any questi ions, please c consult a tech hnical engine eer of Lighting. Notes mage resulted d from dust, s smoke, oil or improper use e is not cover red by warran nty. ... -
Page 17: Troubleshooting
GTD‐LM1506 User Manual Troubleshooting Possible Cause Suggested Correction Problem Power switch not turned on. Turn on power switch. Locate the blown fuse. Remove the broken fuse. Insert a Take out the fuse and check if it is blown. replacement fuse of the correct amperage. No response after connected Abnormal A/C input (A/C power socket, Replace AC power socket and power cables, and then adjust power to A/C power power cables, luminaire power socket). socket for proper connection. No DC voltage from switching power Check if the switching power supply has DC voltage output. Replace supply. ... -
Page 18: System Wiring Diagram
GTD‐LM1506 User Manual System wiring diagram 17 ... -
Page 19: Spare Parts List
GTD‐LM1506 User Manual Spare parts list Item P/N Notes Display board 5809210034B 1 LM1506‐101E20 SDI2002D Scanning board 5809210211B 1 LM1506‐201B20 SCR2005A Drive board 5809210512B 1 LM1506‐301I20 LCR2005C Aluminum substrate 5802010028A 1 LJB2003C Switching Power Supply 1412050027A 1 EDS160‐1228P Appendix 1 ... - Page 20 GTD‐LM1506 User Manual Notes: P/N: 1502011058A Time: March 13 , 2017 ...
