- Page 1 WATER AND AIR UV STERILIZERS WATER STERILIZERS MODELS: V20;V20LA;V40;V80;V120 MANUAL Patent nr 204935 - 2012 -...
-
Page 2: User Safety
Noncompliance with the precautions listed hereon might expose personnel to serious bodily harm (damage to human skin from UV radiation), or damage to the device alone. The manufacturer, TMA, is not responsible for damage to the device caused by improper installation, maintenance and operation. - Page 3 Plastics used in production of the muffs (models V20-V80) withstand 110°C working temperatures. Devices completed successfully 30 Atm pressure trials. In the models V20-V120 we introduced additional guides for the quartz sleeves easing the assembly and disassembly. This solution allows the same ease of assembly for device working horizontally, vertically or at any angle.
- Page 4 Working Hours Counter Solenoid Cut-Off Valve Terminals Terminals for Remote Alarm Indicator Fuse on Power Supply Weight with Enclosure 8.0kg 10.0kg 11.0kg 12.0kg UV Intensity Measurement By Order /Optional System TMA | Białostoczek 26,gm.Zabłudów,15-592 Białystok; Poland ; Tel. +48 857431246; VAT PL5420008413...
- Page 5 2) Upstream of the intake install potable water filter. Minimum rating 0.1 mm, recommended 0.05 3) Install manual cut-off valves, upstream of intake and downstream of outlet. /pic. 1/ TMA | Białostoczek 26,gm.Zabłudów,15-592 Białystok; Poland ; Tel. +48 857431246; VAT PL5420008413...
- Page 6 10) Power the unit by turning switch on the side of the electrical enclosure – green indicator light shall turn on. 11) Replace the lamp after work time of 8,000 hours for V20, 9,000 hours for V40-V80 and 12,000 hours for V120.
- Page 7 Replacement of the UV lamp does not require the stop of fluid flow through the chamber, d) With V120 models wear protective gloves /made of cotton/, e) Loosen the strain relief grip on cable (model V20-V80), or take off lamp hood (model V120), f) Remove sockets from connectors of the UV Lamp,...
-
Page 8: Troubleshooting
– replace – contact dealer UV lamp goes off End of life of lamp caused by Replace UV lamp. number of working hours and number of on-off cycles. TMA | Białostoczek 26,gm.Zabłudów,15-592 Białystok; Poland ; Tel. +48 857431246; VAT PL5420008413... - Page 9 TITLE OUTLET DISINFECTED WATER WATER SAMPLE INLET TAKEUP VALVE CONTAMINATED WATER ELECTRICAL ENCLOSURE ALARM POWER Filter min. 0,1 mm POWER DISTANCE EQUAL TO THE LENGTH OF THE STERILIZER TMA | Białostoczek 26,gm.Zabłudów,15-592 Białystok; Poland ; Tel. +48 857431246; VAT PL5420008413...
- Page 10 ON/OFF ELECTRONIC PLATE /caution: voltage 230V!/. IN MODELS V120 · Contacts closed - sterilizer on · Contacts open - sterilizer off ~230V BALLAST COUNT ON/OFF SWITCH TMA | Białostoczek 26,gm.Zabłudów,15-592 Białystok; Poland ; Tel. +48 857431246; VAT PL5420008413...
-
Page 11: Mounting Arrangements
VERTICALLY OR AT AN ANGLE, THE OUTLET HAS TO BE LOCATED AT THE TOP OF THE CHAMBER INLET M - DISTANCE NEEDED FOR THE REPLACEMENT UV THE LAMP TMA | Białostoczek 26,gm.Zabłudów,15-592 Białystok; Poland ; Tel. +48 857431246; VAT PL5420008413... -
Page 12: Overall Dimensions
NIPPLES: INLET AND OUTLET ELECTRICAL ENCLOSURE POWER L1 – ADJUSTABLE DISTANCE MODEL V20, V20LA V120 L/mm L1/mm S/mm H/mm R 1“ R 1 ½“ R 1 ½“ R 2“ E/mm E1/mm TMA | Białostoczek 26,gm.Zabłudów,15-592 Białystok; Poland ; Tel. +48 857431246; VAT PL5420008413... -
Page 13: Quartz Sleeve
IN THE CASE OF HORIZONTAL MOUNTING ARRANGEMENT SLEEVE IS INSERTED IN THE CHAMBER END GUIDED INTO THE NEST. CHAMBER NEST QUARTZ SLEEVE 2. PLACE O-RING ON THE QUARTZ SLEEVE. CHAMBER QUARTZ SLEEVE TMA | Białostoczek 26,gm.Zabłudów,15-592 Białystok; Poland ; Tel. +48 857431246; VAT PL5420008413... - Page 14 SLEEVE IS THE LARGEST. O-RING IS VISIBLE THROUGH THE SLEEVE. CHAMBER O-RING BEFORE TIGHTENING MUFF /SMALL SURFACE OF CONTACT/ MUFF WASHER O-RING AFTER TIGHTENING /LARGE SURFACE OF CONTACT/ O-RING QUARTZ SLEEVE TMA | Białostoczek 26,gm.Zabłudów,15-592 Białystok; Poland ; Tel. +48 857431246; VAT PL5420008413...
- Page 15 SLEEVE IS THE LARGEST. O-RING IS VISIBLE THROUGH THE SLEEVE. CHAMBER O-RING BEFORE TIGHTENING MUFF /SMALL SURFACE OF CONTACT/ MUFF O-RING AFTER TIGHTENING /LARGE SURFACE OF CONTACT/ WASHER O-RING QUARTZ SLEEVE TMA | Białostoczek 26,gm.Zabłudów,15-592 Białystok; Poland ; Tel. +48 857431246; VAT PL5420008413...
- Page 16 V20-V80 - ASSEMBLY OF the UV LAMP TITLE BEFORE REPLACING THE UV LAMP LOOSEN THE STRAIN RELIEF NUT STRAIN RELIEF NUT OF STRAIN RELIEF SOCKET PLACE SOCKET ON LAMP END UV LAMP TMA | Białostoczek 26,gm.Zabłudów,15-592 Białystok; Poland ; Tel. +48 857431246; VAT PL5420008413...
- Page 17 NUT OF STRAIN RELIEF 2. TIGHTEN STRAIN RELIEF 1. INSERT THE UV LAMP THROUGH THE OPENING IN THE MUFF MUFF WASHER O-RING SOCKET CHAMBER UV LAMP QUARTZ SLEEVE TMA | Białostoczek 26,gm.Zabłudów,15-592 Białystok; Poland ; Tel. +48 857431246; VAT PL5420008413...
- Page 18 STRAIN RELIEF LAMP HOOD PLACE LAMP HOOD ON MUFF MUFF WASHER SOCKET O-RING CENTERING RING SLIDE UV LAMP INSIDE QUARTZ SLEEVE. STERILIZER CHAMBER UV LAMP QUARTZ SLEEVE CENTERING RING TMA | Białostoczek 26,gm.Zabłudów,15-592 Białystok; Poland ; Tel. +48 857431246; VAT PL5420008413...
- Page 19 TERMINAL /normally closed, connection contacts 1 & 2, max. 2A/ MODELS V20LA-V120 ELECTRICAL ENCLOSURE /contact 3 & 4/ contacts closed - switch on contacts open - switch off TMA | Białostoczek 26,gm.Zabłudów,15-592 Białystok; Poland ; Tel. +48 857431246; VAT PL5420008413...
- Page 20 12.09 --------- ------ ------- 10 CENTERING RING ------- -------- -------- 01.15 2 pcs 11 DRAIN VALVE 01.12 1 pcs 01.12 1 pcs 01.12 1 pcs 01.12 1 pcs TMA | Białostoczek 26,gm.Zabłudów,15-592 Białystok; Poland ; Tel. +48 857431246; VAT PL5420008413...
- Page 21 V20-V120 TMA | Białostoczek 26,gm.Zabłudów,15-592 Białystok; Poland ; Tel. +48 857431246; VAT PL5420008413...
- Page 22 V20-V120 TMA | Białostoczek 26,gm.Zabłudów,15-592 Białystok; Poland ; Tel. +48 857431246; VAT PL5420008413...
