- Page 1 WATER UV STERILIZERS Made in Poland WATER UV STERILIZERS AP-POOL-X SERIES MANUAL Patent No. 204935 - December 2019 -...
-
Page 2: Table Of Contents
MANUAL – AP-POOL-X SERIES TABLE OF CONTENTS 1. GENERAL INFORMATION ....................4 2. APPLICATIONS ........................5 3. TECHNICAL SPECIFICATIONS ..................6 4. TECHNICAL DESCRIPTION ....................8 4.1. LEADING OUT THE ALARM SIGNAL IN AP-POOL-X1 MODEL ........8 4.2. CONNECTION OF SOLENOID VALVE IN AP-POOL-X1 MODEL ........ 9 4.3. - Page 3 TMA devices are equipped with lamps that emit UV radiation, light sources that contain mercury. The owners of waste lamps containing mercury are obliged to collect them separately for further re-use and disposal.
-
Page 4: General Information
Thank you and congratulations on your purchase of TMA manufactured UV sterilization product. Sterilizers made by TMA are made from highest quality stainless steel. The thickness of the chamber wall guarantees high factor of safety in operation. All the raw materials and components are of best quality and were processed or manufactured in the EU countries. -
Page 5: Applications
MANUAL – AP-POOL-X SERIES 2. APPLICATIONS Disinfection with UV radiation is a reliable, simple and inexpensive method of sterilization. The use of this method is warranted every time microbiological risk exists. Following applications might be listed, among many others: Water in swimming pools... -
Page 6: Technical Specifications
MANUAL – AP-POOL-X SERIES 3. TECHNICAL SPECIFICATIONS WORKING HOURS COUNTER SYSTEM INDICATOR LAMP ALARM INDICATOR LIGHTS /RED/ UV METER POWER SWITCH / INDICATOR LIGHT SOLENOID VALVE CORD POWER CORD UV LAMP CORDS DRAIN PLUG MODEL AP-POOL-X 3 TECHNICAL SPECIFICATIONS: AP-POOL-X 1... - Page 7 MANUAL – AP-POOL-X SERIES WORKING HOURS COUNTER SYSTEM INDICATOR LAMP /GREEN/ ALARM INDICATOR LIGHTS /RED/ UV METER POWER SWITCH / INDICATOR LIGHT SOLENOID DRAIN PLUG VALVE CORD POWER CORD UV LAMP CORDS MODEL AP-POOL-X 16 TECHNICAL SPECIFICATIONS: AP-POOL-X 6 AP-POOL-X 8 AP-POOL-X 10 AP-POOL-X 12 AP-POOL-X 16...
-
Page 8: Technical Description
MANUAL – AP-POOL-X SERIES Standard features: Sterilizer chamber made from stainless steel (AISI 316/316L), Electrical enclosure, with control system, Set of quartz sleeves Set of UV lamps Set of O-rings + backup set of O-rings ... -
Page 9: Connection Of Solenoid Valve In Ap-Pool-X1 Model
MANUAL – AP-POOL-X SERIES 4.2. CONNECTION OF SOLENOID VALVE IN AP-POOL-X1 MODEL There is possible to connect solenoid valve [max. 2A] to the terminals 1 & 2 /neutral/ on the electronic plate in electrical enclosure. The contacts 1 and 2 operate with a preset delay of about 2-3 minutes - this is the time to reach the full efficiency of the device. -
Page 10: Leading Out The Alarm Signal In Ap-Pool-X2-Ap-Pool-X16 Models
MANUAL – AP-POOL-X SERIES 4.4. LEADING OUT THE ALARM SIGNAL IN AP-POOL-X2-AP-POOL-X16 MODELS Connect the alarm signal wires to the terminals 1 & 2 /neutral/ on the terminal blocks in electrical enclosure /in the right bottom corner/. The contacts 1 and 2 operate with a preset delay of about 2-3 minutes - this is the time to reach the full efficiency of the device. -
Page 11: Instruction For Installation And Operation
MANUAL – AP-POOL-X SERIES ELECTRICAL ENCLOSURE POWER LINE REMOVE DOORS OF THE ELECTRICAL ENCLOSURE SOLENOID VALVE OUTLET CORD SOLENOID VALVE 12 3 4 5 6 7 8 PE UV STERILIZER To the terminals 1 & 2 /neutral/ on the terminal blocks in electrical enclosure/ solenoid valve type NZ (normally closed) max. - Page 12 MANUAL – AP-POOL-X SERIES Vertical Forbidden Horizontal Supports Horizontal Supports Supports Horizontal Forbidden Białostoczek 26,gm.Zabłudów,15-592 Białystok; Poland ; Tel. +48 857431246; VAT EU PL5420008413...
-
Page 13: Quartz Sleeves Assembly
MANUAL – AP-POOL-X SERIES 5.2. QUARTZ SLEEVES ASSEMBLY GRAFICAL MOUNTING INSTRUCTION ON PAGE 27-29) QUARTZ SLEEVE Slide in gently through the nipple the quartz sleeves; continue through sleeve guides onto nests at the bottom. WARNING!! Place the O-ring over quartz sleeve and against QUARTZ SLEEVE IS WERY the lip of the nipple. -
Page 14: Uv Lamps And Electrical Enclosure Assembly
MANUAL – AP-POOL-X SERIES 5.3. UV LAMPS AND ELECTRICAL ENCLOSURE ASSEMBLY (GRAPHICAL INSTRUCTIONS AT PAGE 27-29) a) Mount electrical enclosure on wall, at least 60 cm from the floor. b) Place the socket on the end of UV lamp with four pins. Gently slide the fully connected lamp into the quartz sleeve. -
Page 15: Mounting Temperature Sensor (Models Ap-Pool-X2-Ap-Pool-X16)
MANUAL – AP-POOL-X SERIES ATTENTION! 1. Any fault of UV lamp, including burn out, is signalized by lighting up of red indicator lamp and tripping of audible alarm. 2. Incidental powering of the electrical enclosure without connected UV lamps may cause damage to electronic ballast driving UV lamps. -
Page 16: Description Of Alarms In Electrical Cabinet / Ap-Pool-X1
MANUAL – AP-POOL-X SERIES 6. DESCRIPTION OF ALARMS IN ELECTRICAL CABINET / AP-POOL-X1 / Display indications Cause Solving the problem HOLD 3 s. PRZYTRZYMAĆ 3 s. - 7 days left to the end of life time of UV lamp - change UV lamp after 7 - Blinking digit 7 on the display. -
Page 17: Resseting Counter In Alarm System / Only Model Ap-Pool-X1
MANUAL – AP-POOL-X SERIES 7. RESSETING COUNTER IN ALARM SYSTEM / ONLY MODEL AP-POOL-X1/ COUNTER IN THE ALARM SYSTEM SHOULD BE RESSETED EACH TIME THE UV LAMP IS REPLACED a) Disconnect from power supply /neutral and life/. b) Replace UV Lamp – see p. 9. INSTRUCTION FOR REPLACEMENT OF UV LAMP c) Connect device to Power supply (power switch should be turned off) d) Hold the right button under display. -
Page 18: Maintenance
MANUAL – AP-POOL-X SERIES 9. MAINTENANCE a) UV radiation is harmful to eyes and skin. It is forbidden to directly observe UV lamp (radiator) during operation. b) It is recommended to check cleanness of the quartz sleeve whenever the UV lamp is replaced. -
Page 19: Instruction For Replacement Of Uv Lamp
MANUAL – AP-POOL-X SERIES t) Using faulty or post end of life UV lamps / operating time above their durability period / can lead to damage to electronic ballast located in the electrical enclosure. When replacing the UV lamp, protective gloves should be worn. -
Page 20: Replacement And Clearing Of The Quartz Sleeve
MANUAL – AP-POOL-X SERIES ATTENTION! In model AP-POOL-X sterilizers UV lamps must have special centering ring at both ends. When the UV lamps are shipped from the manufacturer, the centering rings are provided with every lamp. 11. REPLACEMENT AND CLEARING OF THE QUARTZ SLEEVE... -
Page 21: Troubleshooting
MANUAL – AP-POOL-X SERIES 12. TROUBLESHOOTING Problem Cause Action Take quartz sleeve out, dry interior, Burned out UV Lamp change O-ring, and assemble back. Muff not tightened Water inside the quartz Tighten muff. If device does not sufficiently. sleeve - . short circuit –... -
Page 22: Transport
MANUAL – AP-POOL-X SERIES Repeat steps a - b. g. Disconnect the previously checked UV radiator and plug in another radiator that is known to be working properly. h. Put the lamp hoods on all muffs. Reboot the unit and check the UV radiator. Wait 2-3 minutes for UV radiator to warm up. -
Page 23: Diagram - Dimensions
MANUAL – AP-POOL-X SERIES 14. DIAGRAM – DIMENSIONS UV WATER STERILIZER AP-POOL-X SERIES DWG# AP-POOL-X SERIES – GENERAL DIAGRAM - TITLE DIMENSIONS LICZNIK CZASU PRACY KONTROLA PRACY SYSTEMU WSKAŹNIKI ALARMU /CZERWONE/ Czujnik UV WZIERNIK CZUJNIKA UV WYŁĄCZNIK GŁÓWNY WYJŚCIE NA KOREK SPUSTOWY ELEKTROZAWÓR... -
Page 24: Diagram - Spare Parts List
MANUAL – AP-POOL-X SERIES 15. DIAGRAM – SPARE PARTS LIST UV WATER STERILIZER AP-POOL-X SERIES DWG# AP-POOL-X SERIES – SPARE PARTS LIST TITLE APP- APP- APP- APP- APP- APP- APP- APP- APP- APP- PART SYMBOL STRAIN RELIEF 02.01 1 pcs. -
Page 25: Hygienic Certificate
MANUAL – AP-POOL-X SERIES 16.HYGIENIC CERTIFICATE Białostoczek 26,gm.Zabłudów,15-592 Białystok; Poland ; Tel. +48 857431246; VAT EU PL5420008413... -
Page 26: Declaration Of Conformity
MANUAL – AP-POOL-X SERIES 17.DECLARATION OF CONFORMITY Białostoczek 26,gm.Zabłudów,15-592 Białystok; Poland ; Tel. +48 857431246; VAT EU PL5420008413... -
Page 27: Grafical Mounting Instruction
MANUAL – AP-POOL-X SERIES 18. GRAFICAL MOUNTING INSTRUCTION Białostoczek 26,gm.Zabłudów,15-592 Białystok; Poland ; Tel. +48 857431246; VAT EU PL5420008413... - Page 28 MANUAL – AP-POOL-X SERIES Assemble of AP-POOL-X sterilizer Białostoczek 26,gm.Zabłudów,15-592 Białystok; Poland ; Tel. +48 857431246; VAT EU PL5420008413...
- Page 29 MANUAL – AP-POOL-X SERIES Assemble of UV lamps in AP-POOL-X chamber Białostoczek 26,gm.Zabłudów,15-592 Białystok; Poland ; Tel. +48 857431246; VAT EU PL5420008413...
-
Page 30: Warranty
19. WARRANTY UV sterilizers are exclusively for treatment of water/liquids which content is known. The manufacturer of the UV sterilizers - the TMA company guarantees efficient operation of the equipment covered by this warranty card. In order to obtain warranty service during the warranty period it is essential to: ... - Page 31 Warranty claims may relate only to the replacement or repair of defective parts of UV sterilizers THE WARRANTY SHALL NOT COVER DEVICES NOT BEARING THE TMA LOGO. Białostoczek 26,gm.Zabłudów,15-592 Białystok; Poland ; Tel. +48 857431246; VAT EU PL5420008413...
- Page 32 MANUAL – AP-POOL-X SERIES Warranty and post warranty repairs Receive date Type of failure and repair procedure End date of repair Białostoczek 26,gm.Zabłudów,15-592 Białystok; Poland ; Tel. +48 857431246; VAT EU PL5420008413...
