KAESER ASK 28 Operating Manual page 124

model
machine power supply
Motor -M1 -M1
Motor -M4 -M4
supply terminals -X0:U1/V1/W1 -X0:U1/V1/W1
Siemens Siemens
Torque Torque
Stripped length Stripped length
-X0:PE -X0:PE
Wieland Wieland
Torque Torque
Stripped length Stripped length
supply connection connection
Terminal strip -X0 -X0
Terminal strip -X11 -X11
Handling Handling
Contactor -Q1 -Q1
Auxiliary switch
Interference suppressor
Siemens Siemens
Contactor -Q2 -Q2
Interference suppressor
Siemens Siemens
Contactor -Q3 -Q3
Interference suppressor
Siemens Siemens
Overload relay -B25 -B25
Siemens Siemens
Overload protection switch -F4 -F4
Auxiliary switch
Siemens Siemens
Overload protection switch -F11 -F11
Siemens Siemens
Transformer -T11 -T11
Power supply -T21 -T21
Prodrive Prodrive
connection -W13 -W13
Siemens Siemens
connection -W14 -W14
Siemens Siemens
cables -W19.1/.2 -W19.1/.2
Compressor control -K20 -K20
Prodrive Prodrive
EMERGENCY STOP pushbutton -S1 -S1
Switching element Schlegel Schlegel
Control cabinet ventilator -M7 -M7
Outlet filter Rübsamen&Herr Rübsamen&Herr
114
13 Annex
13.4 Electrical Diagram
Equipment parts list
ASK 34
200 V ±10 %, 50 Hz 200 V ±10 %, 50 Hz 230 V ±10 %, 50 Hz 230 V ±10 %, 50 Hz
200 V ±10 %, 60 Hz 200 V ±10 %, 60 Hz 230 V ±10 %, 60 Hz 230 V ±10 %, 60 Hz
18,5 kW 18,5 kW
diagram 2, Sht. 1 diagram 1, Sht. 1 (50 Hz)
diagram 2, Sht. 1 (60 Hz)
0,55 kW 0,55 kW
7.3140.05060 7.3140.05060
3RV2935-5A 3RV2935-5A
6 Nm 6 Nm
25 mm 25 mm
7.3149.01660 7.3149.01660
WKN70SL/U WKN70SL/U
6 Nm 6 Nm
24 mm 24 mm
fig. 10, Sht. 10 fig. 10, Sht. 10
7.7676.00030 Wieland 7.7676.00030 Wieland
7.6836.00390 Wieland 7.6836.00390 Wieland
fig. 1, Sht. 10 fig. 1, Sht. 10
7.8740.00130 7.8740.00130
3RT2038-1AL20 3RT2038-1AL20
7.8740.05010 7.8740.05010
3RH2911-1HA11 3RH2911-1HA11
7.8740.05120 7.8740.05120
3RT2936-1CD00 3RT2936-1CD00
7.8740.00130 7.8740.00130
3RT2038-1AL20 3RT2038-1AL20
7.8740.05120 7.8740.05120
3RT2936-1CD00 3RT2936-1CD00
7.8740.00100 7.8740.00100
3RT2035-1AL20 3RT2035-1AL20
7.8740.05120 7.8740.05120
3RT2936-1CD00 3RT2936-1CD00
7.8741.00100 7.8741.00100
3RB3036-1WB0 3RB3036-1WB0
20-80 A 20-80 A
setting: 49 A (50 Hz) setting: 43 A (50 Hz)
setting: 43 A (60 Hz)
7.8742.01150 7.8742.01150
3RV2021-1EA10 3RV2021-1EA10
2,8-4 A 2,8-4 A
setting: 3,6 A (50 Hz) setting: 3,1 A (50 Hz)
setting: 3,3 A (60 Hz)
7.8742.05000 7.8742.05000
3RV2901-1E 3RV2901-1E
7.8742.01110 7.8742.01110
3RV2021-1AA10 3RV2021-1AA10
1,1-1,6 A 1,1-1,6 A
setting: 1,3 A setting: 1,2 A
7.0776.1 7.2239.20080
UTT 0,25 EMB USTE250 Block
250 VA 250 VA
diagram 3, Sht. 9 diagram 2, Sht. 9
7.7605P0 7.7605P0
PSDC24/2.5 PSDC24/2.5
7.3140.05270 7.3140.05270
3RA2933-3FA00 3RA2933-3FA00
7.3140.05270 7.3140.05270
3RA2933-3FA00 3RA2933-3FA00
1x16 mm² 1x16 mm²
500 V, 90°C 500 V, 90°C
7.9700.0 7.9700.0
SIGMA CONTROL 2 MCSIO SIGMA CONTROL 2 MCSIO
7.3217.0 / QRUV 7.3217.0 / QRUV
7.3218.0 / MHTOO 7.3218.0 / MHTOO
7.2751.00031 / LV200 7.2751.00031 / LV200
7.2752.00020 / GV200 7.2752.00020 / GV200
Operating Manual Screw Compressor
ASK
380 V ±10 %, 60 Hz 380 V ±10 %, 60 Hz 400 V ±10 %, 50 Hz 400 V ±10 %, 50 Hz
18,5 kW 18,5 kW
diagram 1, Sht. 1 diagram 1, Sht. 1
0,55 kW 0,55 kW
7.3140.05060 7.3140.05060
3RV2935-5A 3RV2935-5A
6 Nm 6 Nm
25 mm 25 mm
7.3291.00010 7.3291.00010
WKN35SL/U WKN35SL/U
3 Nm 3 Nm
20 mm 20 mm
fig. 10, Sht. 10 fig. 10, Sht. 10
7.7676.00020 Wieland 7.7676.00020 Wieland
7.6836.00390 Wieland 7.6836.00390 Wieland
fig. 1, Sht. 10 fig. 1, Sht. 10
7.8740.00100 7.8740.00100
3RT2035-1AL20 3RT2035-1AL20
7.8740.05010 7.8740.05010
3RH2911-1HA11 3RH2911-1HA11
7.8740.05120 7.8740.05120
3RT2936-1CD00 3RT2936-1CD00
7.8740.00100 7.8740.00100
3RT2035-1AL20 3RT2035-1AL20
7.8740.05120 7.8740.05120
3RT2936-1CD00 3RT2936-1CD00
7.8740.00070 7.8740.00070
3RT2026-1AL20 3RT2026-1AL20
7.8740.05110 7.8740.05110
3RT2926-1CD00 3RT2926-1CD00
7.8741.00090 7.8741.00090
3RB3036-1UB0 3RB3036-1UB0
12-50 A 12-50 A
setting: 26 A setting: 25 A
7.8742.01130 7.8742.01120
3RV2021-1CA10 3RV2021-1BA10
1,8-2,5 A 1,4-2 A
setting: 1,9 A setting: 1,8 A
7.8742.05000 7.8742.05000
3RV2901-1E 3RV2901-1E
7.8742.01110 7.8742.01110
3RV2021-1AA10 3RV2021-1AA10
1,1-1,6 A 1,1-1,6 A
setting: 1,1 A setting: 1,1 A
7.0772.2 7.0772.2
B0001090 Block B0001090 Block
250 VA 250 VA
diagram 1, Sht. 9 diagram 1, Sht. 9
7.7605P0 7.7605P0
PSDC24/2.5 PSDC24/2.5
7.3140.05270 7.3140.05270
3RA2933-3FA00 3RA2933-3FA00
1x6 mm² black 1x6 mm² black
500 V, 70°C 500 V, 70°C
1x10 mm² 1x6 mm²
500 V, 90°C 500 V, 90°C
7.9700.0 7.9700.0
SIGMA CONTROL 2 MCSIO SIGMA CONTROL 2 MCSIO
7.3217.0 / QRUV 7.3217.0 / QRUV
7.3218.0 / MHTOO 7.3218.0 / MHTOO
7.2751.00031 / LV200 7.2751.00031 / LV200
7.2752.00020 / GV200 7.2752.00020 / GV200
440 V ±10 %, 60 Hz 440 V ±10 %, 60 Hz
460 V ±10 %, 60 Hz 460 V ±10 %, 60 Hz
18,5 kW
diagram 1, Sht. 1
0,55 kW
7.3140.05060
3RV2935-5A
6 Nm
25 mm
7.3291.00010
WKN35SL/U
3 Nm
20 mm
fig. 10, Sht. 10
7.7676.00020 Wieland
7.6836.00390 Wieland
fig. 1, Sht. 10
7.8740.00100
3RT2035-1AL20
7.8740.05010
3RH2911-1HA11
7.8740.05120
3RT2936-1CD00
7.8740.00100
3RT2035-1AL20
7.8740.05120
3RT2936-1CD00
7.8740.00070
3RT2026-1AL20
7.8740.05110
3RT2926-1CD00
7.8741.00090
3RB3036-1UB0
12-50 A
setting: 22 A (440 V)
setting: 22 A (460 V)
7.8742.01120
3RV2021-1BA10
1,4-2 A
setting: 1,7 A (440 V)
setting: 1,6 A (460 V)
7.8742.05000
3RV2901-1E
7.8742.01110
3RV2021-1AA10
1,1-1,6 A
setting: 1,1 A
7.2239.20080
USTE250 Block
250 VA
diagram 2, Sht. 9
7.7605P0
PSDC24/2.5
7.3140.05270
3RA2933-3FA00
1x6 mm² black
500 V, 70°C
1x6 mm²
500 V, 90°C
7.9700.0
SIGMA CONTROL 2 MCSIO
7.3217.0 / QRUV
7.3218.0 / MHTOO
7.2751.00031 / LV200
7.2752.00020 / GV200
