- Page 1 Jones Platinum Full Body Training Attachment OWNERS MANUAL MA9052A Recreation Supply Inc. JB-FBT 7699 Green Meadows Drive Model No. BODYCRAFT Lewis Center, OH 43035 is a division of Recreation Supply Rev. 2018-B...
-
Page 2: Before You Begin
Before beginning this or any other exercise program consult your physician. This is especially important for individuals over the age of 35 or persons with pre-existing health problems. Recreation Supply, Inc. assumes no responsibility for personal injury or property damage sustained by or through use of this product. - Page 3 OVERVIEW 251 229 267 229 247 238 211 218 246 257 221 258 205R 252 239 239 210R 203L 264 240 217R 203R 257 229 267 229 210L 217L 260 254 205L 253 258...
-
Page 4: Preassembled In Left Upright
PARTS LIST DESCRIPTION QTY. BASE FRAME TOP FRAME 203R RIGHT FRAME UPRIGHT 203L LEFT FRAME UPRIGHT CHROME UPRIGHT 205R RIGHT HEIGHT TRACK (preassembled in Right Upright) 205L LEFT HEIGHT TRACK (preassembled in Left Upright) 205R GUIDE ROD FRONT WEIGHT SHROUD REAR WEIGHT SHROUD MIDDLE MESH PANEL 210R... -
Page 5: Parts List
PARTS LIST NO. DESCRIPTION QTY. 5 D-RING SINGLE HANDLE SHAFT SPRING ADJUSTER (preassembled) SELECTOR PIN 114mm PULLEY 90mm PULLEY 50 X 100mm OVAL PLUG (preassembled) 50 X 100mm END CAP 25 X 25mm SQ. END CAP RUBBER CUSHION 1" ID GUIDE ROD HOLDER 60mm ID BUSHING (preassembled) ALUMINUM END CAP (preassembled) 1-1/4"... - Page 6 STEP 1 Base Frame Assembly To ease the assembly process, DO NOT tighten bolts until instructed. We recommend two people to assemble the Jones Full Body Trainer attachment. 1. If needed, remove the rear BASE FRAME END PLATES (11) from your Jones Platinum Strength Training System.
- Page 7 STEP 2 Weight Stack Assembly Note: The Jones Full Body Trainer attachment comes standard with two 160- pound weight stacks consisting of 15 each weight plates and one each Top Plate w/ selector rod. 1. Attach four 50 X 100mm END CAPS (231) to the BASE FRAME (201) as shown. 2.
- Page 8 STEP 2 Weight Stack Assembly 1" 1" 2" 3" 4" 5" 6" (inch)
- Page 9 STEP 3 Top Frame Assembly 1. Attach the RIGHT FRAME UPRIGHT (203R) to the threaded bolts welded on the BASE FRAME (201) as shown, and secure using four 3/8" WASHERS (261) and four 3/8" NYLON NUTS (267). Repeat this procedure for the LEFT FRAME UPRIGHT (203L).
- Page 10 STEP 4 Right and Left Chrome Upright Assembly 1. Slide the RIGHT CABLE ADJUSTER (210R) onto one CHROME UPRIGHT (204). Make sure the REVOLVING CABLE BRACKET (211) is oriented to the front. Insert the CHROME UPRIGHT (204) into the receivers on the BASE FRAME (201) and the TOP FRAME (202). Secure the CHROME UPRIGHT (204) to the BASE FRAME (201) using one 3/8"...
- Page 11 STEP 5 Cable and Pulley Assembly When attaching pulleys, make certain the Flat Bolts are completely through both holes in the pulley bracket. Failure to do so will result in improper alignment and the pulley will rub on steel. Assemble pulleys and cables simultaneously. 1.
- Page 12 STEP 5 Cable and Pulley Assembly CABLE (241) Ball End Steel Head End P3 P4 P1,P2 P5,P9...
- Page 13 STEP 6 Weight Shrouds Assembly 1. Attach the LONGER WEIGHT SHROUD (207) to the BASE FRAME (201) using two 5/16" WASHERS (262) and two 5/16" X 1/2" ROUND HEAD SCREWS (250). Attach the LONGER WEIGHT SHROUD (207) to the TOP FRAME (202) using two 5/16" WASHERS (262) and two 5/16"...
- Page 14 STEP 7 Attach Accessories 1. Attach two 5 D-RING SINGLE HANDLES (225) to the LEFT FRAME UPRIGHT (203L). 2. Attach ANKLE STRAP (242), 1230mm LONG BAR ATTACHMENT (270) to the RIGHT FRAME UPRIGHT (203R). 203R 203L 1" 2" 3" 4" 5"...
- Page 15 Assembly is complete! Please take the following steps before, and while using the JONES PLATINUM FULL BODY TRAINER: 1. Be certain all bolts are tightened securely. Check and tighten all bolts before every use. 2. Ensure that Cables are seated into pulley grooves before every use. A cable that is not seated in pulley grooves will be stripped of its nylon coating and require replacement.
