- Page 1 minCord...
-
Page 3: Table Of Contents
..... . . 23 c minCam GmbH, Gruben 1, 87561 Oberstdorf, info@mincam.de revision January 2018, according to technical standard at printing, changes remain reserved... - Page 4 4.5 declaration of conformity ..... 31 c minCam GmbH, Gruben 1, 87561 Oberstdorf, info@mincam.de revision January 2018, according to technical standard at printing, changes remain reserved...
-
Page 5: Product Description
KK13 or KK18 camera head 3.5 display and control unit (MPR) for recording incl. SD-card transport case AV-cable power supply 5.5V c minCam GmbH, Gruben 1, 87561 Oberstdorf, info@mincam.de revision January 2018, according to technical standard at printing, changes remain reserved... -
Page 6: Product Features
1.1.4 protection of the copyright This manual and all photos, illustrations and information contained are intel- lectual property of the minCam GmbH. For any usage beyond the application of the unit a written allowance from the minCam GmbH is required. -
Page 7: Safety
Check the unit if there is any visual damage or deviation before putting into operation. The inspection unit contains an internal battery. This can be charged by the power supply enclosed. The minCord can be operated without restriction while charging the battery. Make sure to take care of all safety precautions in both cases. -
Page 8: Intended Use
, take it out of the transport case and press the on-/off-button for about 5 seconds. The minCord is immediately ready to use. c minCam GmbH, Gruben 1, 87561 Oberstdorf, info@mincam.de revision January 2018, according to technical standard at printing, changes remain reserved... -
Page 9: Functional Specification
DOWN selection down OK/MENU confirm selection/open menu menu back start recording (video) SNAP save picture POWER switch unit on/off c minCam GmbH, Gruben 1, 87561 Oberstdorf, info@mincam.de revision January 2018, according to technical standard at printing, changes remain reserved... -
Page 10: Power Supply
Date settings can manually be adjusted now. To keep the settings when switching off again, the backup c minCam GmbH, Gruben 1, 87561 Oberstdorf, info@mincam.de revision January 2018, according to technical standard at printing, changes remain reserved... -
Page 11: Reel
2.1.4 camera The minCord is available with KK13 or KK18. The cameera is permanently connected to the push-pull-cable each. c minCam GmbH, Gruben 1, 87561 Oberstdorf, info@mincam.de revision January 2018, according to technical standard at printing, changes remain reserved... -
Page 12: Focus
To do so, the the receiver (adjusted to 512Hz) has to be switched to the according mode: pinpointing for the camera head and locating a pipe for the cable. c minCam GmbH, Gruben 1, 87561 Oberstdorf, info@mincam.de revision January 2018, according to technical standard at printing, changes remain reserved... -
Page 13: Recording
MPR, the live view from the camera is displayed. Pictures and videos can be recorded and saved at this mode. c minCam GmbH, Gruben 1, 87561 Oberstdorf, info@mincam.de revision January 2018, according to technical standard at printing, changes remain reserved... - Page 14 MPR to the menu mode. At this mode various settings (s. 2.2.2) can be chosen. c minCam GmbH, Gruben 1, 87561 Oberstdorf, info@mincam.de revision January 2018, according to technical standard at printing, changes remain reserved...
-
Page 15: Settings Mpr
At the submenu DELETE ALL/SD CARD FORMAT the SD card can be formatted. All data on the SD-card will be deleted. c minCam GmbH, Gruben 1, 87561 Oberstdorf, info@mincam.de revision January 2018, according to technical standard at printing, changes remain reserved... - Page 16 Date and time are set on delivery. If there’s the need to change the settings, it can be done at the menu DATE/TIME SETUP. c minCam GmbH, Gruben 1, 87561 Oberstdorf, info@mincam.de revision January 2018, according to technical standard at printing, changes remain reserved...
- Page 17 OK auto power off AUTO POWER OFF is to choose the duration of inactivity until the MPR switches off automatically. c minCam GmbH, Gruben 1, 87561 Oberstdorf, info@mincam.de revision January 2018, according to technical standard at printing, changes remain reserved...
-
Page 18: Video
At delivery condition the microphone is deactivated. Selection by UP /DOWN for confirmation push OK 2.2.3 video To record and save a video, proceed as follows: c minCam GmbH, Gruben 1, 87561 Oberstdorf, info@mincam.de revision January 2018, according to technical standard at printing, changes remain reserved... - Page 19 To stop recording, push again the rec key . The red video camera symbol at the right bottom corner disappears. c minCam GmbH, Gruben 1, 87561 Oberstdorf, info@mincam.de revision January 2018, according to technical standard at printing, changes remain reserved...
-
Page 20: Picture
The start screen displays the free memory on the SC-card (in the mid- dle on the top) and (right top) the battery’s state of charge. c minCam GmbH, Gruben 1, 87561 Oberstdorf, info@mincam.de revision January 2018, according to technical standard at printing, changes remain reserved... -
Page 21: Review Recorded Data
, to continue the review, push OK . To inter- rupt the review and return to the list of data recorded, push ESC c minCam GmbH, Gruben 1, 87561 Oberstdorf, info@mincam.de revision January 2018, according to technical standard at printing, changes remain reserved... -
Page 22: Deleting Single Files
/DOWN Pushing the SNAP key , the delete menu pops up. Select YES by UP /DOWN and confirm pushing OK c minCam GmbH, Gruben 1, 87561 Oberstdorf, info@mincam.de revision January 2018, according to technical standard at printing, changes remain reserved... -
Page 23: Accessory
KK13 from DN24 KK18 from DN29 To mount this two-piece plastic skid, it is screwed on the camera. Unscrew the skid. c minCam GmbH, Gruben 1, 87561 Oberstdorf, info@mincam.de revision January 2018, according to technical standard at printing, changes remain reserved... - Page 24 Add the skid’s front part. Screw together the skid by hand. The camera with skid can be used now. c minCam GmbH, Gruben 1, 87561 Oberstdorf, info@mincam.de revision January 2018, according to technical standard at printing, changes remain reserved...
- Page 25 To remove the skid from the camera after use, it has to be cleaned first. When it’s cleaned, it can be unscrewed by hand. c minCam GmbH, Gruben 1, 87561 Oberstdorf, info@mincam.de revision January 2018, according to technical standard at printing, changes remain reserved...
-
Page 27: Maintenance
3.1.3 maintenance If there’s the need for repair, contact minCam GmbH or an authorized distrib- utor. c minCam GmbH, Gruben 1, 87561 Oberstdorf, info@mincam.de... -
Page 28: Disposal
If a unit has - after consultation - to be send to minCam GmbH, the delivery address is: minCam GmbH Bundesstr. 9 D-87538 Langenwang 3.2 disposal At the end of lifetime, the unit has to be recycled. c minCam GmbH, Gruben 1, 87561 Oberstdorf, info@mincam.de... -
Page 29: Technical Data
3.5 TFT LCD display 320x240 pixel pictures *.jpg 704x528 pixel videos *.avi 768x576 pixel MPEG4 simple profile codec c minCam GmbH, Gruben 1, 87561 Oberstdorf, info@mincam.de revision January 2018, according to technical standard at printing, changes remain reserved... -
Page 30: Data Storage
Ambient temperature while charging: 0 C bis 40 C 4.4 data storage To save the files, a SDHC-card (classe 6 or more) up to 8GB can be used. c minCam GmbH, Gruben 1, 87561 Oberstdorf, info@mincam.de revision January 2018, according to technical standard at printing, changes remain reserved... -
Page 31: Declaration Of Conformity
4.5 declaration of conformity c minCam GmbH, Gruben 1, 87561 Oberstdorf, info@mincam.de revision January 2018, according to technical standard at printing, changes remain reserved...
