Rennline RS Manual

RS Door Pulls
The use of any Rennline product is the sole responsibility of the end user. Rennline Inc. accepts no responsibility for
warranty voids or damage resulting from the use of these products. Due to the varying location of wiring harnesses and
other components, carefully inspect any area prior to drilling. All Rennline products are intended for off road use only and
Check to make sure you have all parts listed prior to installation.
If anything is missing contact us immediately.
(1) Strap Assembly (left)
(1) 4.25" Strap
(1) Strap Lever
(1) Strap Assembly (Right)
(1) 4.25" Strap
(1) Strap Lever
(1) Facia Plate (left)
(1) Facia Plate (Right)
(6) #8 - 3/8" S/S Truss Head Screws - C93406A192
(8) #8 Washers - MC92141A009
(4) #8 - 5/8" Truss Head Screws - MC93406A196
(4) #8 - 3/4" Truss Head Screws - MC93406A197
(4) #12 Fender Washers - MC90313A508
(4) #12 - 1/2" Truss Head Screws - MC93406A290
1. Remove the door card from the car door.
2. Remove the handle assembly retaining frame from the door card by using a 3/8" drill bit to drill the heads o of the rivets circled in red in picture 1.
3. Carefully release the handle assembly from the door trim strip. There are two small clips behind the trim that hold it to the handle assembly. It may be
necessary to drill out the trim rivets circled in green to be able to get to these clips. Replacement hardware is provided for all (6) rivets.
4. Pry the lever retaining pin out of the plastic handle assembly from the bottom ry lever will not be needed.
See next page.
P/N - DH22 - 08/17

READ BEFORE INSTALLATION

should be installed by a qualified automotive technician.
2.
1.
VW - MK6
1.
1.
3.
pg 1 of 3
