CAUTIONS:
●Before using the Meter, read this INSTRUCTION MANUAL
thoroughly and use the Meter correctly.
●Keep this INSTRUCTION MANUAL carefully and refer to this
when necessary.
●Connect/disconnect the probe after surely confirming the
power OFF.
●In the event of any doubt arising, the original INSTRUCTION
MANUAL in Japanese is to be final authority.
Office: Jl. Radin Inten II No. 62 Duren Sawit, Jakarta 13440 - Indonesia
Workshop: Jl. Pahlawan Revolusi No. 22B, Jakarta 13430 - Indonesia
Phone: 021-8690 6777 (Hunting)
ＭＯＩＳＴＵＲＥ
ＭＲ−２００
ＥＬＥＣＴＲＩＣ
ＭＯＩＳＴＵＲＥ
ＩＮＳＴＲＵＣＴＩＯＮ
It causes out of order.
ＭＥＴＥＲ
ＭＥＴＥＲ
ＭＡＮＵＡＬ
Mobile: +62 816 1740 8925
Fax: 021-8690 6777
Advertisement
Table of Contents
Related Manuals for ALAT UJI MR-200
Summary of Contents for ALAT UJI MR-200
- Page 1 ＭＯＩＳＴＵＲＥ ＭＥＴＥＲ ＭＲ−２００ ＥＬＥＣＴＲＩＣ ＭＯＩＳＴＵＲＥ ＭＥＴＥＲ ＩＮＳＴＲＵＣＴＩＯＮ ＭＡＮＵＡＬ CAUTIONS: ●Before using the Meter, read this INSTRUCTION MANUAL thoroughly and use the Meter correctly. ●Keep this INSTRUCTION MANUAL carefully and refer to this when necessary. ●Connect/disconnect the probe after surely confirming the power OFF.
-
Page 2: Table Of Contents
CONTENTS ITEM PAGE １．FEATURES & APPLICATIONS ２．SPECIFICATIONS ３．NAME OF PARTS 3‑1 Main body 3‑2 Standard probe ４．OPERATING INSTRUCTIONS 4‑1 Connecting(Disconnecting) the probe 4‑2 Power ON・OFF 4‑3 Converting the measurement mode 4‑4 Converting the hold mode 4‑5 Setting upper & lower limit values 4‑6 Converting the key lock mode ５．MEASUREMENT ６．MEASUREMENT IN THE MOISTURE CONTENT (MC) MODE... -
Page 3: １．Features & Applications
１．FEATURES & APPLICATIONS ● The moisture contents for various materials/products can be measured with the probe connecting to the main body. Kinds of the probe: probe for wood, probe for paper, probe for mortar & plaster ● The moisture contents of all kinds of objects can be compared in the MC mode. Measurement can be carried out by converting the mode of the main body keeping on each probe connecting. -
Page 4: ２．Specifications
0 to 40 ℃ (except dew condensing condition) Dimensions & weight 80(W) × 35(H) × 150(D)mm, 245g Accessories Carrying bag Option Moisture reading checker ■ MR-200 Connecting probe Probe for wood ■ Type TG-PA(Standard probe for wood) Measuring range 3.5 to 50.0%... -
Page 5: ３．Name Of Parts
３．NAME OF PARTS 3‑1 Main body Receptacle for the probe connector Probe connector Mobile: +62 816 1740 8925 Office: Jl. Radin Inten II No. 62 Duren Sawit, Jakarta 13440 - Indonesia Workshop: Jl. Pahlawan Revolusi No. 22B, Jakarta 13430 - Indonesia Fax: 021-8690 6777 Phone: 021-8690 6777 (Hunting) - Page 6 ① Power switch key (POWER) Switch for power ON or OFF. When the probe is not connected to the main body, [PE] probe error is indicated on the display and the power OFF. Power switch ON after surely connecting the using probe to the main body. ②...
-
Page 7: Standard Probe
3‑2 Standard probe Probe for Wood (TG-PA) ⑬ ⑫ ⑪ Probe for Paper & cardboard (KG-PA) ⑬ ⑫ ⑪ Probe for Mortar & Plaster (PM-PA) ⑬ ⑫ ⑪ ⑪ Probe connector ⑫ Probe cord ⑬ Electrode Probe for Wood (needle electrode) Probe for Paper &... -
Page 8: ４．Operating Instructions
４．OPERATING INSTRUCTIONS Receptacle for the probe connector 4‑1 Connecting(Disconnecting) the probe (Be sure to confirm the power OFF.) To connect the probe: ■ Carefully insert the probe connector ⑪ of the using probe to the bottom into the receptacle for the probe connector ⑧. To disconnect the probe: ■... -
Page 9: Converting The Measurement Mode
4‑3 Converting the measurement mode Normally the initial measurement mode of the selected probe is indicated on the LCD display. ■ The measurement mode is converted each press of the mode key ③ [G] as shown in the following ■ charts. -
Page 10: Setting Upper & Lower Limit Values
4‑5 Setting upper & lower limit values Upper limit value & lower limit value can be set as per following procedures. Operation Indication Press the [H/L] key ⑥. [H] showing the upper limit value is blinking with a beeping sound of the buzzer. Values in the column of the upper limit value increase Keep on the [▲] key ④... -
Page 11: ５．Measurement
５．MEASUREMENT 1. Connect the probe suitable for an object (wood, paper, cardboard, mortar & plaster) to be measured. 2. Power switch ① ON and confirm the indications on the LCD display ⑦. For wood ＝[TG-H] For paper ＝[KG] For mortar ＝[MORTAR] TG‑H Example: In case of connection of the probe for wood... -
Page 12: ７．Temperature Compensation
７．TEMPERATURE COMPENSATION The automatic temperature compensating function is set ON at the initial setting condition and the indicating value is automatically temperature compensated based on 20 ℃. When an object to be measured is high temperature due to dry treatment by heating etc., measure it after turning the automatic temperature compensating function OFF. -
Page 13: ８．Notes For Measurement
８．NOTES FOR MEASUREMENT The electric resistance type Moisture meter utilizes the characteristics that the electric characteristics of an object to be measured reacts specially sensitively on its moisture contents, but the relation is not perfectly related in one-to-one ratio. When its composition and proportion are different or change in quality and contamination exist or special processing and chemical treatment are performed even though the same object, it is necessary to avoid the measurement at these places or to use the measured values after compensating. -
Page 14: Miscellaneous
１１．Miscellaneous ‑ How to use the Moisture reading checker(option) Press the electrode against the checker as shown in the following sketch in power ON condition. When the reading of the Meter matches the figure on the checker, the Meter's reading is acceptable. When the reading deviates from the checker's, please request our agent or the nearest our branch to calibrate the Meter.
