CAUTIONS:
●Before using the Meter, read this INSTRUCTION MANUAL thoroughly and use
the Meter correctly.
●Keep this INSTRUCTION MANUAL with care and refer to it when necessary.
●In the event of any discrepancies, the original INSTRUCTION MANUAL
in Japanese is to be of final authority.
Office: Jl. Radin Inten II No. 62 Duren Sawit, Jakarta 13440 - Indonesia
Workshop: Jl. Pahlawan Revolusi No. 22B, Jakarta 13430 - Indonesia
Phone: 021-8690 6777 (Hunting)
Wood moisture meter
ＴＧ−１０１
- Electric moisture meter -
Operating Instruction MANUALS
Mobile: +62 816 1740 8925
Fax: 021-8690 6777
Advertisement
Table of Contents
Related Manuals for ALAT UJI TG-101
Summary of Contents for ALAT UJI TG-101
- Page 1 Wood moisture meter ＴＧ−１０１ - Electric moisture meter - Operating Instruction MANUALS CAUTIONS: ●Before using the Meter, read this INSTRUCTION MANUAL thoroughly and use the Meter correctly. ●Keep this INSTRUCTION MANUAL with care and refer to it when necessary. ●In the event of any discrepancies, the original INSTRUCTION MANUAL in Japanese is to be of final authority.
-
Page 2: Characteristics ・ Applications
（MC-6) were considered difficult to perform. 2． Specifications Model AQUA SEARCH SERIES TG-101 Method DC electric resistance type Dry weighted standard moisture% Range 6.0 to 50.0% , 1 to 100(MC mode) Resolution 0.1% , 1(MC mode) - Page 3 3． Names 3-1 Main body Probe connector receptacle Probe connector ① Power SW (POWER) Switch ON or OFF. Switch ON after a probe has been hooked up to a main body. A display turns automatically to Error [E01] and Power-OFF because of Self Analysis Function when any abnormality is detected in the inner circuitry of a body.
- Page 4 ⑤ Lock key (LOCK) A push of a Lock key locks all the keys except POWER SW ① which prevents erroneous operations. Switch OFF to release the lock. ⑥ Upper Limit Value Key (H) Switch on Upper Limit Value Mode. Set to an optional numerical value with a numerical value setting key ④.
-
Page 5: Power On/Off
Probe connector receptacle 4． How to use 4-1 Connection or disconnection of probe ( ensure that Power Source of a main body is OFF). ・ Hook up the Probe connector ⑪ to a main body to meet the Arrow Mark of the Probe Connector ⑪ with the Mark of Probe Probe connector Connector Receptacle ⑧... - Page 6 4-4 Changes of Hold Mode A press of Hold･Average Key ② turns to the Hold Mode with a「peep」sound. Each press of the key changes the Hold Mode alternately to ON or OFF and 「Hold」is displayed on LC Display ⑦ when ON is in process. The displayed measuring value is on hold until a next measuring value has been input.
- Page 7 ・At a real time measuring, it sounds a buzzer “ Peep, Peep, Peep “ when a measuring value exceeds a setting value, and the upper limit value and the measuring value alternately blinks on the display while being probed to contact.
- Page 8 5． Measurements 5-1 Real time measurement 1. Turn on Power SW ① and confirm an indication of LCD. Display of a measuring mode ｢H｣Broad Leaf Tree and ｢LLL｣ Turning on Power while inserting the probe to the object indicates ｢LLL｣ once on the display and then displays a measuring value in 2 to 3 seconds.
- Page 9 5-2 Measurement of Average Value Indication (Temporary Memory) 1. A long press (approx. 1 sec.) of a Hold・Average Key ② performs temporary Memory Measurement to display Average Value Indications. ( A max. measurement point capable for Temporary Memory is 20) 2.
- Page 10 Power SW key ① and Hold・Average key ② can only be used during a measurement in process of Average Value Indication. During a measurement of Average Value Indication, a setting function of Upper Limit Values turns ineffective. When actuating Average Value Indication measurement during a use of a setting function of Upper Limit Value, the setting function of an Upper Limit Value turn ineffective.
- Page 11 ●Refer to the table below for compensate the temperature and kind of wood of electric resistance type wood moisture meter. Moisture（％） ４ to １１ １２ to ２０ above or ２１ Temperature（℃） below ０ ＋２．０ ＋２．５ ＋３．０ ０ to １ ＋２．０ ＋２．５...
-
Page 12: Dry Batteries
8． Remarks on measurements Measuring values may disperse according to measuring circumstances. Electric Resistor Type Moisture meters use the applications of sensitively electric characteristics of measuring objects against the moisture contents and the corresponding relations never be a perfectly correlative one- to- one. In case of measuring wood barks, grains, faces, knots ,albeit the same material , or woods with changes in quality, salty, contamination, and furthermore with special processing, chemical treatments, it may be necessary to avert measuring such unfavorable objects, and compensate or average measured values. - Page 13 11． Others 11-1 How to use moisture reading checker (option) Touch the electrode to the checker illustrated below when Power is ON. It is a good condition if indicated values are as per listed on the checker. If indicated values deviate, contact a store or our sales office to get it corrected. (subject to pay) ＊ ...
- Page 14 11-3 Replacement of needle electrodes The needle electrode can be replaced loosing a Hexagon socket set screw for needle fixing with a furnished accessory Hexagon wrench. Make sure that the hexagon socket set screw is set and screwed to strike a notch face of the needle electrode, otherwise it may cause the electrode to loose and drop off the body.
