ALAT UJI MS6612 User Manual

Multi-functional light meter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Multi-functional Light Meter
Office: Jl. Radin Inten II No. 62 Duren Sawit, Jakarta 13440 - Indonesia
Workshop: Jl. Pahlawan Revolusi No. 22B, Jakarta 13430 - Indonesia
Phone: 021-8690 6777 (Hunting)
MS6612
USER MANUAL
Mobile: +62 816 1740 8925
Fax: 021-8690 6771
Fax: 021-8690 6777
i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MS6612 and is the answer not in the manual?

Questions and answers

Related Manuals for ALAT UJI MS6612

Summary of Contents for ALAT UJI MS6612

  • Page 1 MS6612 Multi-functional Light Meter USER MANUAL Mobile: +62 816 1740 8925 Office: Jl. Radin Inten II No. 62 Duren Sawit, Jakarta 13440 - Indonesia Workshop: Jl. Pahlawan Revolusi No. 22B, Jakarta 13430 - Indonesia Fax: 021-8690 6777 Fax: 021-8690 6771...

  • Page 2: Table Of Contents

    MS6612 Multi-functional Light Meter Table of Contents TABLE OF CONTENTS ..................1 INTRODUCTION ....................3 LIMITED WARRANTY, RIGHTS AND RESPONSIBILITIES ......4 OPEN-PACKAGE INSPECTION ................ 4 SAFETY INFORMATION ................... 6 1 INTRODUCTION .................... 11 ........................11 RODUCT DESCRIPTION MS6612 ........12...

  • Page 3: Introduction

    Introduction 2.2.1 Concepts of illuminance scales ..................... 22 2.2.2 Unit conversion for illuminance scales ................. 22 2.2.3 Conversion formula for illuminance and light intensity ............22 ......................24 YPICAL PRACTICE CASES 3 SPECIFIC APPLICATION ................28 ........28 PPLICATION OF MANUAL SWITCHOVER OF RANGE MEASUREMENT MODE ............

  • Page 4: Limited Warranty, Rights And Responsibilities

    Limited Warranty, Rights and Responsibilities Limited Warranty, Rights and Responsibilities The product is guaranteed for one year from date of purchase against defects in material or workmanship. This warranty does not extend to damage caused by fire (fusing), disposable battery (exhausted), accidents, negligence, misuse, modification, pollution and abnormal operation.
  • Page 5 MS6612 Multi-functional Light Meter...

  • Page 6: Safety Information

    Do not use the light meter in the environment full of dusts or having gas substances and flammable steam substances! Safety mark description This manual contains basic information for MS6612 safety operation and maintenance. Please read carefully following safety information before use.
  • Page 7 MS6612 Multi-functional Light Meter Table 2: Warning message It indicates that incorrect operation will lead to serious injury or even fatal accidents Warning It indicates that incorrect operation or negligence will lead to meter damage or wrong measurement results, etc.
  • Page 8 Safety information 2: Placement Operational temperature -10～50℃ (14～122° F) and humidity range <80%RH (non-condensed) Storage temperature and -10～+50℃ (14～122° F) humidity range <70%RH (non-condensed) To avoid faults, please DO NOT place the light meter in following environments: Direct sunlight Corrosive High temperature explosive gas Intensive...
  • Page 9 MS6612 Multi-functional Light Meter 3: Use Notice 1: The operation temperature range for the light meter is -10-50℃ (14-122° F). 2: In order to avoid damage, especially falling accidents, handling and use should be avoided during severe mechanical vibration. 3: The light meter can only be calibrated and repaired by professional personnel.
  • Page 10 Safety information Tips 1: The sensibility of the optical detector will be lessened due to operation conditions or time. It is recommended to make periodic calibration to maintain the basic accuracy. 2: Please keep original package for future mailing (such as for light meter calibration).

  • Page 11: Introduction

    So, a professional and convenient light meter can provide you with a reference regarding illuminance. The MS6612 multi-functional light meter has a friendly human-machine interface and can be activated...

  • Page 12: Outstanding Features Of Ms6612 Multi - Function Light Meter

    MS6612 multi-function light meter Outstanding features of the  Automatic and manual range switching;...

  • Page 13: Lcd Display Interface

    MS6612 Multi-functional Light Meter 200000Lux (or 20.00Fc  200.0Fc  ① Opto-sensor protection cover 2000Fc  20000Fc) circulation; Long ② Opto-sensor press for 1 second to exit manual range ③ LCD display screen switching mode. ④ Compound key for main power and touch tone: Power on/off: Short press the key to activate the machine and long press for 1 second to shut it down.
  • Page 14 MS6612 Multi-functional Light Meter ① Prompt for manual range switching mode ② Prompt for data hold mode ③ The analog bar shows the current measurement value information. ④ The digit shows the current measurement value information. ⑤ Lux unit ⑥ FC unit ⑦...

  • Page 15: Measurement Methods

    MS6612 Multi-functional Light Meter 2 Measurement methods 2.1 Notices prior to measurement Warning 1: Do not use the light meter in environments full of dusts or having gas substances and flammable steam substances! 2: Do not use the light meter for measurement in the place with high temperature and high humidity.

  • Page 16: Action Principles

    Measurement methods under the color temperature of 2854° K; the provided reading number may be different for the spectrum of other lamps. 3: The reference level of light source test is at the top of the spherical surface illuminated. 4: The optical detector should expose to light for 2 minutes before measurement. 5: Influence of tester's shadow and other factors on the optical detector should be avoided.

  • Page 17: Typical Practice Cases

    MS6612 multi-functional light meter sensor and place it at right angle to the light source, as shown in figure 2-1. Press and hold the MS6612 power key ④ for a short time to power on the light meter. The LCD screen will illuminate（about 5 seconds）with the buzzer beeping twice, and “AUTO” will appear on the middle of LCD display.
  • Page 18 LCD interface will disappear, and the mode will exit. Press and hold the data hold/zero calibration key ⑦ of the MS6612 for a short time to enter the data hold mode, which will be indicated by the apparition of “HOLD” on the top left position of the LCD interface; press and hold the key for a short time once again, “HOLD”...
  • Page 19 Measurement methods Figure 2-1 Tips 1: The reference position of light source test is at top of sphere surface under light. 2: In various measurement modes, analog bar in the middle of the LCD screen will change with figures of Nixie tubes. 3: When reading, existing data can be locked by pressing and holding “HOLD/ZERO”...
  • Page 20 MS6612 Multi-functional Light Meter 5: After completing the test, the sensor protection cover should be put back to protect light filter and sensor.

  • Page 21: Specific Application

    Specific Application 3 Specific Application 3.1 Application of manual switchover of range measurement mode  Press and hold the RAN key (range manual switchover key) for a short time, “MANU” will appear on the top left position of the LCD interface, and the meter will enter the manual switchover measurement mode (as shown in figure 3-1-1);...
  • Page 22 MS6612 Multi-functional Light Meter 20.00Lux interface 200.0Lux interface 2000Lux interface 20000Lux interface 200000Lux interface Tips 1: Only in peak value measurement mode, relative value measurement mode and max/min value inquiry mode, it will be effective to press RAN key for a short time.

  • Page 23: Application Of Relative/Peak Value Measurement Mode

    Specific Application this time. 3.2 Application of relative/peak value measurement mode  Press and hold REL/PEAK key for a short time (composite key for relative/peak value measurement), “REL” will appear on the top left position of the LCD interface (as shown in figure 3-1-2A), and the device will enter the relative value measurement mode;...

  • Page 24: Application Of Maximum/Minimum Value Inquiry Mode

    MS6612 Multi-functional Light Meter Figure 3-1-2A Figure 3-1-2B Figure 3-1-2C Tips 1: Only in auto measurement mode, peak value measurement mode, max/min value inquiry mode and data hold mode, it will be effective to press and hold REL/PEAK key for a short time.

  • Page 25: Application Of Data Hold And Zero Calibration Mode

    Specific Application  Press and hold “MAX/MIN” for one second, “MAX/MIN” on top LCD interface will disappear, and the max/min value inquiry mode will exit. Figure 3-1-3 Tips In non-zero calibration mode, press and hold “MAX/MIN” key for a short time to use the max/min value inquiry functions;...
  • Page 26 MS6612 Multi-functional Light Meter Figure 3-1-4A Figure 3-1-4B Notice Before zero calibration, the opto-sensor must be covered with the opto-sensor visor. Tips 1: In non-zero calibration mode, press and hold “HOLD/ZERO” key for a short time to enter the data hold mode.

  • Page 27: Other Functions

    MS6612 Multi-functional Light Meter 4 Other Functions 4.1 Auto power-off If there is no action on keys of the MS6612 for a long time, the meter will automatically power off about 10 minutes later.

  • Page 28: Technical Data

    Technical Data 5 Technical Data  Temperature range: Operation:-10～50 C, max 80 % HR（Non-Condensed） Storage:-10～50 C，max 80 % HR (Non-Condensed) (removing batteries)  Sampling rate: ≥2 times/s。  Display: 3½ digits, max reading of 1999, with analog bar display;  Sensor: silicon photoelectric diode ...
  • Page 29 MS6612 Multi-functional Light Meter ± 6% other visible light source Cosine angle deviation characteristics Cosine angle Deviations 30° ± 2% 60° ± 6% Tips: cosine angle is corrected in accordance with JIS C 1609:1993 and CNS 5119 Grade A General Specification.

  • Page 30: Maintenance And Service

    Maintenance and Service 6 Maintenance and Service 6.1 Service Notice When the meter seemingly fails during operation, following steps should be followed to check the fault problem: 1: Check up batteries. If “ ” appears on the LCD display, batteries should be replaced. 2: Refer to the operation instructions to check if operation steps are wrong.

  • Page 31: Battery Replacement

    MS6612 Multi-functional Light Meter Notice 1: Please make sure the light meter is turned off before cleaning. 2: Do not use benzene, alcohol, acetone, ethyl ether, ketones, thinners and gasoline, etc. in cleaning, because they will transform or fade the light meter.

  • Page 32: Calibration Interval

    Maintenance and Service 2: Neither connects one polarity of the battery to the other one with wire, nor throws batteries into fire, or it will cause explosion. 3: Do not attempt to discompose the battery! The battery’s intensively alkaline electrolyte is corrosive and endangers the user.

  • Page 33: Reference Table For Illumination Standard Of Various Locations

    MS6612 Multi-functional Light Meter 7 Reference Table for Illumination Standard of Various Locations Fc illuminance value can be got from Lux illumination value divided by 10.6. Schools: Iluminance Locations (Lux) 1500~300 Drafting classroom, sewing classroom, computer classroom Classroom, , laboratory, practice workshop, research room, reading room, stack...
  • Page 34 Reference Table for Illumination Standard of Various Locations Stack room, entertainment room, dining room, lounge, guard room, elevator 300~150 (passway), washroom, toilet 150~75 Tea room, changing room, warehouse, nightwatchmen office (entrance) 75~30 Fire escape Factories: Iluminance Locations (Lux) 3000~1500 Ultra-precision operation, design, drafting, precision inspection 1500~750 Design office, analysis, assemble line, coating 750~300...
  • Page 35 MS6612 Multi-functional Light Meter dissection room, pathological bacteria room, emergency rooms, maternity ward, dean’s office, offices, nursing room, conference room 300~150 Ward, medicine room, bed reading, medicine changing, plaster bandage for fractures, infant room, record room, waiting room, consulting room, outpatient...
  • Page 36 Reference Table for Illumination Standard of Various Locations gardens, changing room 75~30 Fire escape Shop, department store: Iluminance Locations (Lux) Indoor display, decorative window display, demonstration area, checkout counter, 3000~750 packaging table 750~300 Elevator lobby, escalators 300~150 Discussion room, dressing room, toilet, stairs, walkways 150~75 Lounge, general lighting in store House:...
