Connecting Devices - Patton SmartNode 41 Series Manual

4. Now, connect the analogue devices to the activated ports on the Patton ATA (FXS*).
5. Then connect the Patton ATA to your network using the respective connection cable.
6. Now as a last step, connect the mains unit / power supply to the Patton ATA.
*) FXS (Foreign Exchange Station) is an interface used to connect analogue devices (also referred to
as "POTS":Plain Old Telephone Service).
It can take a few minutes until the Patton ATA is ready for use, given that the
configuration must be downloaded first. This can take up to 15 minutes.
4
