ASSEMBLY AND CARE INSTRUCTIONS
VERSION: 8920101 (Revised 10/17)
Canada and International
135 Forestview Road, Oro-Medonte
Ontario, Canada L3V 0R4
Toll-Free:
Telephone: (705) 325-2274
Fax:
service.ca@spiethamerica.com
JUST FOR KIDS CANTILEVER BARS
SALES AND SERVICE
spiethamerica.com
(800) 563-6479
(705) 325-1485
365A
3327 Ranger Road
Toll-Free:
Telephone: (517) 999-8230
Fax:
service.usa@spiethamerica.com
USA
Lansing, MI 48906
(800) 331-8068
(517) 999-8245
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for SPIETH 365A
Summary of Contents for SPIETH 365A
- Page 1 ASSEMBLY AND CARE INSTRUCTIONS JUST FOR KIDS CANTILEVER BARS 365A VERSION: 8920101 (Revised 10/17) SALES AND SERVICE spiethamerica.com Canada and International 135 Forestview Road, Oro-Medonte 3327 Ranger Road Ontario, Canada L3V 0R4 Lansing, MI 48906 Toll-Free: (800) 563-6479 Toll-Free: (800) 331-8068...
- Page 2 365A JFK CANTILEVER BARS Assembly Instructions Thank you for purchasing a SPIETH America Cantilever Bars from our Just For Kids line of Gymnastics equipment. We appreciate your business and value you as a customer. The Just For Kids Cantilever Bars come complete with cable tie-down and Threaded Socket Adapters (Hardwood floor sockets are also available but must be purchased separately).
-
Page 3: Apparatus Description
365A JFK CANTILEVER BARS Assembly Instructions 1. Apparatus description The SPIETH America 365A Just for Kids Cantilever Bars includes the following items: Just for Kids Bases (#355-01): 1 Pair Cantilever Bars Short Upright bases (#355-620): 2 Pieces o Assembled complete with clamps ... - Page 4 365A JFK CANTILEVER BARS Assembly Instructions 2. Set-up, Assembly and Adjustment a. Cantilever Bars Uprights and Frames Assembly (#355-610) THERE IS A TOP & LEFT / RIGHT SIDE TO THIS ASSEMBLY, so ensure that the Locking Devices and Adjustment Holes in the Uprights face the same direction as shown in Figure 2 below.
- Page 5 365A JFK CANTILEVER BARS Assembly Instructions b. Cantilever Bars Short Upright bases Assembly (#355-620) This step must be done first, before any further Assembly of your Apparatus! Ensure the screws are tightened securely! 1. Locate the two Cantilever Bars Short Upright bases (#355-620), one Just for Kids Cross Tube (#355-360) and the 7/32”...
- Page 6 365A JFK CANTILEVER BARS Assembly Instructions c. Cantilever Bars Short Upright Bases Assembly to JFK Bases (#355- The following procedures will require at least two (2) qualified persons. At no time should children or other unqualified persons undertake any part of this procedure.
- Page 7 365A JFK CANTILEVER BARS Assembly Instructions d. Cantilever Bars Uprights and Rails Assembly 1. Insert each Cantilever Bars Uprights and Frames assembly all the way into the Uprights Bases as shown in Figure 4 below, until they bottom out. Ensure the Cable Connection links point away from center and the Low Frames face in the same direction when inserting the Assembled Cantilever Bar Uprights into the Upright Bases as shown in Figure 4.
- Page 8 365A JFK CANTILEVER BARS Assembly Instructions e. Installing Concrete Anchors To determine anchor locations, please refer to the following section for your specific equipment to be anchored. Tools Required (customer supplied): Tape measure Anchor setting tool or punch with a 5/16” diameter & 1.5” long end ...
- Page 9 Use the Diagonal Measurement (11’ 7”) to ensure the 4 anchors are square to each other. Drill and install floor anchors into concrete (See previous page for instructions on anchors supplied by SPIETH America or follow the manufacturer’s instructions if anchors are purchased elsewhere.
- Page 10 365A JFK CANTILEVER BARS Assembly Instructions 4. Attach one turnbuckle chain end to each Threaded Socket Adaptors (Fig. 8). Tighten Quick Links using an adjustable wrench. 5. Open the turnbuckles and attach each turnbuckle hook end to the corresponding tie-down cable (Fig.
- Page 11 365A JFK CANTILEVER BARS Assembly Instructions g. Rail Height and Width Adjustment To adjust the height or width of either the Low or High Rail, first loosen the turnbuckles. When adjustment is done, ALWAYS RETIGHTEN THE 4 TURNBUCKLES EQUALLY, so that the apparatus Uprights remain perpendicular to the floor.
-
Page 12: Spare Parts
365A JFK CANTILEVER BARS Assembly Instructions 3. Spare parts Description Part Number 1 Piece – Just for Kids Spin-Snap Lock P355-254A (Combination of Locking Handle and Snap Lock) 1 Piece – Just for Kids Clamp P355-248A 1 Piece - Just for Kids Veneered Fiberglass Rail 355-65A 1 Pair –... - Page 13 365A JFK CANTILEVER BARS Assembly Instructions 4. SAFETY WARNING Any activity involving motion or height creates the possibility of serious injury including permanent paralysis and even death from landing or falling on the neck, head or other parts of the body.
