Summary of Contents for AVT MAGIC ACip3
- Page 1 MAGIC ACip3 MAGIC ACip3 2M High-quality IP and E1 Audio Codec Hardware Manual...
- Page 2 Nordostpark 91 90411 Nuernberg Germany Phone +49-911-5271-0 Telefax +49-911-5271-100 © AVT Audio Video Technologies GmbH All Rights reserved. Reproduction in whole or in parts is prohibited without the written consent of AVT GmbH. Subject to changes. Release date: January 2019...
-
Page 3: Table Of Contents
Front status LEDs ..................11 Wiring ......................12 Proper disposal ................... 12 Interfaces ......................13 LAN interfaces .................... 14 E1 interface (only MAGIC ACip3 2M) ............14 TTL/Relay interface ..................15 RS232 interfaces ..................16 Audio interfaces ..................17 3.5.1 Headphone interface ................. -
Page 4: Introduction
INTRODUCTION The MAGIC ACip3 is a pure IP Audio Code and provides three Ethernet interfaces which can be used for Audio over IP transmissions, to control the system with the Windows PC software or to integrate it into a network management system via SNMP. -
Page 5: Conventions
Conventions In this manual the following conventions are used as text markers: The TIP symbol marks information which facilitates the operation of the system in its daily use. The Note symbol marks general notes to observe. The Attention symbol marks very important advice that is absolutely to observe. In case of non-observance malfunctions and even system errors are possible. -
Page 6: General Safety Requirements
General safety requirements To keep the technically unavoidable residual risk to a minimum, it is absolutely necessary to observe the following rules: • Transport, storage and operation of the unit must be under the permissible conditions only. • Installation, configuration and disassembly must be carried out only by trained personal based on the respective manual. -
Page 7: Construction
Construction MAGIC ACip3 and MAGIC ACip3 2M can be controlled via the front keypad and the graphic display. Five LEDs give information about the status and connections. A headphone interface is also on the front. The other interfaces of the system (3 LAN interfaces, Audio interfaces, RS232 and GPIO interfaces as well as power supply connections, SD card slot and for the 2M version E1 interface) are on the rear side. -
Page 8: Functionality
IP line interface (and E1 line interface with MAGIC ACip3 2M). In addition, you can key in PAD data, which is applied to one of the RS232 interfaces, into the encoded audio signal. -
Page 9: Putting Magic Acip3 Into Operation
With its dimensions of (width x height x depth) 434 mm x 44.5 mm (1 U) x 260 mm the MAGIC ACip3 system can either be used as desktop device or mounted into a 19-inch rack. Corresponding 19“mounting brackets are included in delivery. When mounting the unit please keep in mind that the bending radius of the connected cables is always greater than the minimum allowed value. -
Page 10: Connection To The Mains Voltage
Connection to the mains voltage MAGIC ACip3 must be earthed. The earthing can be carried out via the earthing screw on the back side of the unit. MAGIC ACip3 may only be used with the included power cable. The power cable must not be replaced by an inadequately dimensioned power cable. -
Page 11: Operational Elements At The Front Side
Operational elements at the front side The system has an illuminated graphical display with a resolution of 160 x 32 pixel and 19 operating buttons. On the right next to the display there are two softkeys whose current functions are indicated on the display. -
Page 12: Wiring
Wiring The figure below shows the systems’ wiring. The system offers three LAN interfaces, which can be used for Audio transmission. The example applications show a unidirectional Audio transmission, a bidirectional transmission as leased line connection between two devices and an IP dial-up connection. -
Page 13: Interfaces
GPIO interfaces as well as power supply connections, SD card slot)are on the rear side. MAGIC ACip3 Front View MAGIC ACip3 Rear View MAGIC ACip3 2M provides an additional E1 interface at the rear side. MAGIC ACip3 2M Front View MAGIC ACip3 2M Rear View... -
Page 14: Lan Interfaces
Data in - not used not used E1 interface (only MAGIC ACip3 2M) A symmetrical E1 interface is optionally available for classic audio feed via 2 Mbit networks. The pin assignment is shown below. Pin assignment: E1 Interface... -
Page 15: Ttl/Relay Interface
TTL/Relay interface The TTL/relay interface is realised as a 25-pin socket. It provides six TTL inputs/outputs as well as six relay contacts, which offer the NC and the NO function. Pin assignment: TTL/Relay interface Socket: SUB-D 25-pin Signal Electrical characteristics TTL interface: TTL 1 input/output... -
Page 16: Rs232 Interfaces
Protocol: 1 Start bit 8 Data bits not used 1/2 Stop bit not used Parity adjustable not used not used a = ATTENTION: on this pin the MAGIC ACip3 sends data b = ATTENTION: on this pin the MAGIC ACip3 receives data... -
Page 17: Audio Interfaces
6.3 mm jack. 3.5.2 Analogue Audio interfaces The MAGIC ACip3 incorporates an analogue stereo input and output (Audio 1, Audio 2). Two XLR sockets are available for the input and two XLR plugs for the output. The pin configuration of socket and plug are displayed below. -
Page 18: Digital Aes Audio Interfaces
3.5.3 Digital AES Audio interfaces The MAGIC ACip3 provides two digital stereo AES inputs and outputs. A 15-pin SUB-D socket contains the digital AES interfaces. The pin configuration of the 15-pin SUB-D socket can be seen below. Pin assignment: Digital Audio interface AES... -
Page 19: Power Supply
Power supply 3.6.1 AC power supply interface 100 V – 230 V AC, 50/60 Hz, auto adjusting, max. 30 W 3.6.2 Additional DC power supply connection A DC voltage of +12V can be fed to the additional power supply input. Pin assignment: Additional power supply Socket: KYCON KPJ-S3 Signal... -
Page 20: Technical Data
• MPEG4 HE-AACv1/v2 • Enhanced apt-X 16/24 Bit Line interfaces: • 3 x Ethernet 10/100 Mbit/s 1 x E1 (only MAGIC ACip3 2M) • Control interfaces: • 3 x Ethernet 10/100 Mbit/s • 6 x Relays 6 x TTL Input/Output... - Page 21 Audio interfaces: • Analogue Stereo Audio IN • Analogue Stereo Audio OUT Electronic symmetrical input XLR socket Electronic symmetrical output XLR plug Impedance Input: > 25kOhm Output: 52 Ohm Frequency response G.711 50 Hz ... 3400 Hz G.722 50 Hz ... 7000 Hz ...
- Page 22 SD Card Slot: • 1 x SD/SDHC for max. 32 GByte card Display: • Graphical, resolution 160 x 32 pixels Lighted (can be switched off) • Power supply: • Integrated power supply: 100 V – 230 V Power max. 30 W •...
-
Page 23: General
470080 AES/EBU/CLK Adapter Cable 490171 Scope of delivery • MAGIC ACip3 & MAGIC ACip3 2M Audio Codec 1 x power cable 4 x Self-adhesive feet 19’’ Mounting brackets (integrated in front panel) Declaration of conformity The declaration of conformity you will find at the end of this manual. -
Page 24: Service Information
If you bought the system via your local dealer, please contact him first. Repairs If, contrary to expectations, your unit is defective please fill in the attached Service Request and send the unit to the following address: AVT Audio Video Technologies GmbH - Repairs - Nordostpark 91 D-90411 Nuernberg Germany Or download from: http://avt-nbg.de/downloads/Info/Service%20Request%20AVT.pdf... - Page 25 Produkt declares, that the product Produktname(n): MAGIC ACip3 Audio Codec 803200 Product name(s): MAGIC ACip3 2M Audio Codec 803220 mit den Vorschriften folgender Europäischer Richtlinien übereinstimmt: conforms to the standards of the following European directives: Elektromagnetische Verträglichkeit (EMV) 2014/30/EU...
