A-R630/A-R650
Effective : November 2010
INTEGRATED STEREO AMPLIFIER
CONTENTS
1. SPECIFICATIONS ......................................................... 2
2. BRIEF OVERVIEW OF LSI ............................................. 3
3. EXPLODED VIEWS AND PARTS LISTS ........................... 5
4. PC BOARDS ............................................................... 8
5. INCLUDED ACCESSORIES .......................................... 15
PC boards shown are viewed from parts side.
The parts with no reference number or no parts number in the
exploded views are not supplied.
As regards the resistors and capacitors, refer to the circuit
diagrams supplied pripor to this manual.
Parts marked with this sign are safety critical components.
They must be replaced with designated components.
Destination of product is expressed by [ ] mark and ensure
exact replacement:
[ EUR ] : EUROPE; [ JPN ] : JAPAN; [ UK ] : U.K
NOTES
G-01017A
Advertisement
Chapters
Table of Contents
Related Manuals for Teac A-R630
Summary of Contents for Teac A-R630
-
Page 1: Table Of Contents
A-R630/A-R650 INTEGRATED STEREO AMPLIFIER CONTENTS 1. SPECIFICATIONS ………………………………………………… 2 2. BRIEF OVERVIEW OF LSI ……………………………………… 3 3. EXPLODED VIEWS AND PARTS LISTS ……………………… 5 4. PC BOARDS ……………………………………………………… 8 5. INCLUDED ACCESSORIES …………………………………… 15 NOTES PC boards shown are viewed from parts side. -
Page 2: Specifications
A-R630/A-R650 1. SPECIFICATIONS A-R630 A-R650 Amplifier Section Amplifier Section Continuous Power Output Continuous Power Output 90W RMS (1 kHz, 4 ohms, 0.5%) 120 W+120 W RMS (1 kHz, 4 ohms, 0.5%) 60W (1 kHz, 8 ohms, 0.5%) 90 W+90 W (1 kHz, 8 ohms, 0.5%) -
Page 3: Brief Overview Of Lsi
A-R630/A-R650 2. BRIEF OVERVIEW OF LSI Access line, advanced ARM-based 32-bit MCU with Flash memory, six 16-bit timers, ADC and seven communication interfaces STM32F101R8T6, FRONT PCBA IC21 Pin Configuration (Top View) 64 63 62 61 60 59 58 57 56 55 54 53 52 51 50 49... - Page 4 A-R630/A-R650 Pin Definitions Pins Pin name Type Signal name Pins Pin name Type Signal name VBAT VBAT PB12 FUNC_STB PC13-TAMPER-RTC TUNER UTE PB13 FUNC_CLK PC14-OSC32_IN -20DB MUTE PB14 TAPE_MUTE PC15-OSC32_OUT PWR MUTE PB15 FUNC_DATA OSC_IN OSC IN OSC_OUT OSC OUT...
-
Page 5: Exploded Views And Parts Lists
A-R630 & A-R650 3. EXPLODED VIEWS AND PARTS LISTS A-R630 only A-R650 only – 5 –... -
Page 6: Exploded View
A-R630SJPN PREAMP PCB ASSY POWER SW PCB ASSY …………………………… United on FRONT PCBA, see page 11 COP12281B FRONT PCB ASSY A-R650 [EUR], [UK] COP12281C FRONT PCB ASSY A-R630 [EUR], [UK] COP12346B FRONT PCB ASSY A-R630S [JPN] CKC3A085B25 CABINET, TOP [EUR], [UK] CKC3A085G51... - Page 7 A-R630 & A-R650 EXPLODED VIEW REF. NO. PARTS NO. DESCRIPTION REMARKS CGP3A016 FAN FRAME CDD1A013 CLT5U044ZE TRANS, POWER A-R630 [EUR], [UK] CLT5U044ZJ TRANS, POWER A-R630S [JPN] CLT5V056ZE TRANS, POWER A-R650 [EUR], [UK] CUA5A148 BOTTOM CHASSIS CKL2A042H11 FOOT, FRONT KHG1A050 FOOT CUSHION...
-
Page 8: Pc Boards
A-R630 & A-R650 4. PC BOARDS AND PARTS LISTS MAIN PCB – 8 –... - Page 9 A-R630 & A-R650 MAIN PCB ASSY REF. NO. PARTS NO. DESCRIPTION REMARKS COP12282B MAIN PCB ASSY A-R650 COP12282C MAIN PCB ASSY A-R630 [EUR], [UK] COP12282D MAIN PCB ASSY A-R630S [JPN] ┗CUP12282Z PCB,MAIN A-R650 (330X247, FR1/1) BK51 CMD1A576 SHIELD, PLATE BN51...
- Page 10 R544,634 CRG2ANJ4R7H RES, METAL OXIDE FILM 4.7 OHM 2 W R567,568 KRG1SANJ271RT RES, METAL OXIDE FILM 270 OHM 1 W A-R630 KRG1SANJ391RT RES, METAL OXIDE FILM 390 OHM 1 W A-R650 R607,713 CRG2SANJ100RT RES, METAL OXIDE FILM 10 OHM 1 W...
- Page 11 A-R630 & A-R650 FRONT PCB AMP POWER SUPPLY PCB MIC PCB POWER SW PCB SUB TRANS PCB LOUDNESS PCB H/P PCB FRONT PCB – 11 –...
- Page 12 A-R630 & A-R650 PREAMP PCB PREAMP PCB PREAMP PCB Side A Side B REMOTE PCB REMOTE PCB – 12 –...
- Page 13 CMC1A111 PLATE, EARTH F901 KJCFC5S HOLDER, FUSE ┗KBA2C3150TLEY FUSE, T 3.15 A L 250 V A-R630 [EUR], [UK] KBA2C4000TLEZ FUSE, T 4 A L 250 V A-R650 KBA2C5000TLEY FUSE, T 5 A L 250 V A-R630S [JPN] ...
- Page 14 REF. NO. PARTS NO. DESCRIPTION REMARKS COP12283B PREAMP PCB ASSY A-R650 COP12283C PREAMP PCB ASSY A-R630 [EUR], [UK] COP12283D PREAMP PCB ASSY A-R630S [JPN] ┗CUP12283Z PCB, iPOD A-R650 (253X160, FR4/2) BN41 CWB1C90512058002 WIRE ASSY 5 P SHIELD 2.0 MM 120 MM...
-
Page 15: Included Accessories
REF. NO. PARTS NO. DESCRIPTION REMARKS CQX1A1523Z OWNER'S MAMUAL (EFSGIN) A-R650 [EUR], [UK] CQX1A1569Z OWNER'S MAMUAL (EFSGIN) A-R630 [EUR], [UK] CQX1A1570Z OWNER'S MAMUAL (J) A-R630S [JPN] CJA2B054Z CORD, POWER NON CAPTIVE 2 WIRE [EUR] A-R650 only CJA2E077Z CORD, POWER NON CAPTIVE 10A/125V [UK]... -
Page 16: Schematic Diagrams
SCHEMATIC DIAGRAMS CONTENTS WIRING DIAGRAM‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥ 2 BLOCK DIAGRAM ‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥ 3 MAIN PCB ‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥ 4 FRONT PCB & Others‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥ 5 PREAMP PCB, REMOTE PCB ‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥ 6 A-R630/A-R650 Integrated Stereo Amplifier 1st Issue; November 2010... -
Page 17: Wiring Diagram
CN46 AC IN (7p) (7p) BN42 (7p) (7p) CN91 (2p) AC OUTLET BN91 CN92 (2p) (2p) A-R630 [EUR], [UK] only AC IN CN41 (9p) CN21 (9p) AC OUTLET BN21 CN42 (7p) (7p) REMOTE PCB A-R650 FRONT PCB CN93 (2p) AC INLET... -
Page 18: Block Diagram
D702~D-705 AC OUTLET A-R630 [EUR], [UK] only AC IN EUR/UK : 230V 50Hz F901 AC OUTLET RL91 A-R630 [EUR], [UK] T3.15A L 250V RELAY A-R630 [JPN] T5A L 250V A-R650 T4A L 250V A-R650 AC INLET EUR/UK : 230V 50Hz T901 SUB TRANS... -
Page 19: Main Pcb
L301 1000P(M) 10 (2W) 1SS133 Q509 R516 R518 R550 A1267Y Q510 Q515 A1267Y Q524 JK34 Q529 D524 C3423O D525 Q514 A-R630: 2SC2837 C3198Y C3198Y Q528 R551 R563 1SS133 1SS133 R561 D2058Y C3198Y Q521 R515 C508 R514 D502 C3198Y 6.8K D518... -
Page 20: Front Pcb & Others
1SS133 TO MAIN B'D BN72 BN71 Q224 C3198Y CN25 D701 MIC BOARD A-R630: GBJ-1006 10A/600V A-R650: GBJ-1506 15A/600V C706, C707 A-R630: 6800uF/ 63V A-R650: 10000uF/ 75V D701 ** IMPORTANT SAFETY NOTICE COMPONENTS IDENTIFIED BY MARK HAVE SPECIAL CHARACTERISTICS. IMPORTANT FOR SAFETY.WHEN REPLACING ANY OF THESE COMPONENTS... -
Page 21: Preamp Pcb, Remote Pcb
A-R630/A-R650 PREAMP PCB, REMOTE PCB SCHEMATIC DIAGRAM REMOTE BOARD PREAMP BOARD A-R630/A-R650 Integrated Stereo Amplifier – 6 – 1st Issue; November 2010... - Page 22 CBT1A603 KNOB, TACT A-R600EUR 9 ..3 CBT1A604 KNOB, POWER A-R600EUR 10 ..3 CBT1A605 KNOB, DIRECT A-R600EUR 11 ..3 CGB1A165H8 BADGE, TEAC 12 ..3 CGL1A109 INDICATOR, FUNCTION A-R600EUR 13 ..3 CGL1A162 INDICATOR, FUNCTION A-R600EUR 14 ..3 CGR2A154 ORNAMENT, REMOTE A-R600EUR 15 ..3...
- Page 23 116 ..5 CCBS1H104ZFT CAP, CERAMIC 0.1UF 50V Z C276 CH UP050 F104Z- 117 ..5 CCEA1HH100T CAP, ELECT 10UF 50V C277 00107-1045 118 ..5 CCBS1H104ZFT CAP, CERAMIC 0.1UF 50V Z C278 CH UP050 F104Z- 119 ..5 CCEA1EH101T CAP, ELECT 100UF 25V C279 120 ..5 CCEA1EH101T...
- Page 24 237 ..5 CRD20TJ103T RES, CARBON (10 KOHM, 5%, 1/5W) 10 KOHM 1/5W J R244 238 ..5 CRD20TJ103T RES, CARBON (10 KOHM, 5%, 1/5W) 10 KOHM 1/5W J R245 239 ..5 CRD20TJ103T RES, CARBON (10 KOHM, 5%, 1/5W) 10 KOHM 1/5W J R246 240 ..5 CRD20TJ103T...
- Page 25 358 ..6 CCUS1H104KC CAP, CHIP (1608, 50V/0.1uF) 0.1UF 50V K C322 359 ..6 CCUS1H101JA CAP, CHIP (1608, 50V/100 PF) 100 PF 50V J C324 360 ..6 CCUS1H101JA CAP, CHIP (1608, 50V/100 PF) 100 PF 50V J C325 361 ..6 CCUS1H104KC CAP, CHIP (1608, 50V/0.1uF) 0.1UF 50V K C326...
- Page 26 479 ..5 CCEA1HH100T CAP, ELECT 10UF 50V C308 00107-1045 480 ..5 CCEA1HH100T CAP, ELECT 10UF 50V C309 00107-1045 481 ..5 HCQI1H102JZT CAP, MYLAR 1000 PF 50V J C310 HPE102J2AP050T 482 ..5 CCEA1EH470T CAP, ELECT 47UF 25V C311 25V 47UF 5*11 483 ..5 HCQI1H562JZT CAP, MYLAR...
- Page 27 600 ..5 CVD1SS133MT DIODE, SWITCHING 1SS133 D524 ISS133(T/B) 601 ..5 CVD1SS133MT DIODE, SWITCHING 1SS133 D525 ISS133(T/B) 602 ..5 CVD1SS355T DIODE, CHIP, SWITCHING D526 1SS355(T/B) 603 ..5 CVDZJ13BT DIODE, ZENER 13V ZJ13B 1/2W D527 ZJ13BT(26MM T/B 604 ..5 CVDZJ6.2BT DIODE, ZENER 6.2V ZJ6.2B 1/2W D601 ZJ6.2BT(26MM T/...
- Page 28 721 ..5 CRD20TJ471T RES, CARBON (470 OHM, 5%, 1/5W) 470 OHM 1/5W J R529 722 ..5 CRD20TJ821T RES, CARBON (820 OHM, 5%, 1/5W) 820 OHM 1/5W J R530 723 ..5 CRD20TJ361T RES, CARBON (360 OHM, 5%, 1/5W) 360 OHM 1/5W J R531 360 OHM 1/5W J 724 ..5...
- Page 29 842 ...4 CLU9S006Z COIL, TOROIDAL L302 843 ...4 CLEY0R5KAK COIL, SPEAKER 0.5UH L501 0.5UH 844 ...4 CLEY0R5KAK COIL, SPEAKER 0.5UH L601 0.5UH 845 ...4 HVT2SA1209S 2SA1209S Q511 2SA1209S/T 846 ...4 HVT2SC2911S 2SC2911S Q512 2SC2911S 847 ...4 HVT2SC2911S 2SC2911S Q513 2SC2911S 848 ...4 HVT2SC3423O 2SC3423O...
- Page 30 963 ..5 CRD20TJ273T RES, CARBON (27 KOHM, 5%, 1/5W) 27 KOHM 1/5W J R465 964 ..5 CRD20TJ223T RES, CARBON (22 KOHM, 5%, 1/5W) 22 KOHM 1/5W J R466 965 ..5 CRD20TJ911T RES, CARBON (910 OHM, 5%, 1/5W) 910 OHM 1/5W J R467 966 ..5 CRD20TJ121T...
