Johansson 9650 Instruction Manual

Features
- designed to combine amplified SAT with terrestrial signals (DTT compatible)
- separate adjustment for gain and slope
- high isolation to avoid interferences between SAT and terrestrial signals
- LNB power : 0 -13V-18V/ 0-22 kHz for H-V polarity and Low-High band selection

Technical specifications

Input
Frequency range
Adjustable gain
Adjustable slope
Max. input level
Noise figure
Max. output level (-35 dB/ IM3)
Selectivity
Input / Output return loss
Remote LNB power
Consumption
Power adapter
Test output
Connectors
Dimensions

Safety Instructions

Read carefully these instructions before connecting the unit.
The operating voltage is indicated on the power adapter.
To prevent fire, short circuit, shock hazard:
Do not expose the unit to rain or moisture.
Install the unit in a dry location without infiltration or condensation of water.
Do not expose it to dripping or splashing.
Do not place objects filled with liquids, such as vases, on the apparatus.
If any liquid should accidentally fall into the cabinet, disconnect the power plug.
Refer to qualified technician before it's further operation.
To avoid any risk of overheating:
Install the unit in a well aery location and keep a minimum distance of 15 cm around the apparatus for sufficient ventilation.
Do not place any items such as newspapers, table-cloths, curtains ... on the unit that might cover the ventilation holes.
The unit must not be exposed to any source of heat (sun, heater,...).
Do not place any naked flame sources, such as lighted candles, on the apparatus.
Do not install the product in a dusty place.
Pull out power plug to make the different connections of cables.
To avoid electrical shock, do not open the housing of adapter.
Cleaning: Only use a dry soft cloth to clean the cabinet. Do not use solvent.
Servicing: For repairing and servicing refer to qualified personnel.
SAT-IF amplifier with terrestrial bypass
Instruction Manual
SAT
950-2300 MHz
20-40 dB
0-15 dB @ 950 MHz
75 dBµV
9 dB
115 dBµV
Terr. / SAT > 40 dB
> 10 dB
0-13-18 V / 0-22 kHz
(300 mA max)
150 mA @ 20 VDC
( without LNB powering)
230-240 VAC / 50 Hz / 30 VA
- 30 dB ( 47-2300 MHz)
Terrestrial
47-862 MHz
Bypass – 2 dB max
-
-
-
-
SAT / Terr. > 25 dB
> 10 dB
-
20 VDC /1.0 A
"F"
158x102x51 mm
Ref.: 9650
