Dynojet Power Commander V Installation Instructions page 3

FIG.A
FIG.B
Unplug
FIG.C
10-003
PCV Harness
www.powercommander.com
1 Remove the seats.
2 Prop the front of the fuel tank up.
3 Lay the PCV in the tail section and route the PCV wiring harness forward along
the right side of the frame and towards the engine.
4 Attach the PCV ground wire with the small ring lug to the negative (-) terminal
of the bike's battery (Fig. A).
5 Unplug the stock wiring harness from the rear fuel injector (Fig. B).
This connection is on the left side of the throttle body.
6 Plug the pair of PCV leads with YELLOW colored wires in-line of the stock
wiring harness and the rear fuel injector (Fig. C).
2004-2009 Aprilia RSV Mille - PCV - 3
