Denjoy DY-GP Plus User Manual

Cordless gp obturation system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Enlarged version
Rev. 02/01/18
VER SMS-DYGP-PLUS-FREEFILL20170828-EN
USER'S MANUAL
DY-GP Plus
Cordless GP Obturation System
*The unit must be installed by a qualified engineer.
*Only for user by dental professionals.
*Read this operation manual carefully before installation or operation.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DY-GP Plus and is the answer not in the manual?

Questions and answers

Related Manuals for Denjoy DY-GP Plus

Summary of Contents for Denjoy DY-GP Plus

  • Page 1 Rev. 02/01/18 VER SMS-DYGP-PLUS-FREEFILL20170828-EN USER’S MANUAL DY-GP Plus Cordless GP Obturation System *The unit must be installed by a qualified engineer. *Only for user by dental professionals. *Read this operation manual carefully before installation or operation.

  • Page 2: Table Of Contents

    The whole operation process should follow user’s manual strictly. SECTION 5: INSTALLATION AND SETTING DENJOY DENTAL CO., LTD has right to improve shape and structure of the SECTION 6: INSTRUCTION OF OPERATION device, change any information and technical specification of this manual all SECTION 7: APPLICATION OF ROOT CANNAL FILLING the time, and no need to notice the user in advance.

  • Page 3: Section 1: General Introduction

    Rev. 02/01/18 VER SMS-DYGP-PLUS-FREEFILL20170828-EN SECTION 1: GENERAL INTRODUCTION SECTION 2: MAIN TECHNICAL INDEX DY-GP Plus cordless gutta percha obturation system is a newly developed Model Name DY-GP Plus system which is composed of FreeFill pen, FreeFill gun and charging system. It...

  • Page 4: Section 3: Symbol

    Rev. 02/01/18 VER SMS-DYGP-PLUS-FREEFILL20170828-EN Rev. 02/01/18 VER SMS-DYGP-PLUS-FREEFILL20170828-EN Batteries can not be placed near fire, recharged, put in backwards, mixed CE Mark: conforms to essential requirements of the with used or other battery type to avoid explosion and electricity lead that will Medical Device Directive 93/42/EEC.
  • Page 5 Rev. 02/01/18 VER SMS-DYGP-PLUS-FREEFILL20170828-EN Rev. 02/01/18 VER SMS-DYGP-PLUS-FREEFILL20170828-EN Injection Device/FreeFill Obturation Gun The accessories include heat insulator, brush, accessory tool, injection needles and heating tips. FreeFill Gun（Injection device） Working voltage：3.7V～4.2V Injection Device：≤10W Heating Pen：≤10W For backfilling the melted gutta-percha Structure as blow： Plugger Pushing gutta-percha outside of the needle Status Description of the Plugger...

  • Page 6: Section 5: Installation And Setting

    Rev. 02/01/18 VER SMS-DYGP-PLUS-FREEFILL20170828-EN Rev. 02/01/18 VER SMS-DYGP-PLUS-FREEFILL20170828-EN SECTION 5: INSTALLATION AND SETTING Power status： -------Low battery -------Full power Setting temperature for heating needle.150℃、 180℃、 200℃、 220℃ -----Cleaning status, constant temperature is 100℃,quit cleaning function by press any button. POWER Extended press (2-3 seconds) for switching on/off the device, -----Energy-saving status, constant temperature is 120℃，...
  • Page 7 Rev. 02/01/18 VER SMS-DYGP-PLUS-FREEFILL20170828-EN Rev. 02/01/18 VER SMS-DYGP-PLUS-FREEFILL20170828-EN 3)Place the injection device onto the charging base with the trigger inward Heat Insulator （match well the charging electrode）,the charging lamp is red and bright Cut off the heat to avoid scalding the patient's 4)The power is full when the charging lamp is green.

  • Page 8: Section 6: Instruction Of Operation

    Rev. 02/01/18 VER SMS-DYGP-PLUS-FREEFILL20170828-EN Rev. 02/01/18 VER SMS-DYGP-PLUS-FREEFILL20170828-EN Remarks The charging base is not waterproof, the liquid contact electrode is forbidden, and the conductor is forbidden to contact the charging When“ ”changed to “E1”means heating malfunction， please check your thimble. heating needle.
  • Page 9 Rev. 02/01/18 VER SMS-DYGP-PLUS-FREEFILL20170828-EN Rev. 02/01/18 VER SMS-DYGP-PLUS-FREEFILL20170828-EN The dentists had better not change angle of needle often, otherwise the needle of the canal. is easily broken! They had better confirm two kinds of angle of needle: one is for upper teeth, 1.
  • Page 10 Rev. 02/01/18 VER SMS-DYGP-PLUS-FREEFILL20170828-EN Rev. 02/01/18 VER SMS-DYGP-PLUS-FREEFILL20170828-EN Remarks B. FreeFill Obturation Pen The pen is designed for vertical condensation or down packing with warmed ※ To avoid cross infection, we recommend that you change new or gutta percha in the canal. Besides, it can be used to cut off excessive gutta sterilized injection needle and heat insulator every time you use them.

  • Page 11: Section 7: Application Of Root Cannal Filling

    Rev. 02/01/18 VER SMS-DYGP-PLUS-FREEFILL20170828-EN Rev. 02/01/18 VER SMS-DYGP-PLUS-FREEFILL20170828-EN 7. After use, extended press POWER button for switch off, if necessary. SECTION 7: APPLICATION OF ROOT CANNAL FILLING 8. Remove the heat tips, clean the device and related accessories for next use. First-Phase Preparation 1) Gutta percha point (Master cone) Remarks...

  • Page 12: Section 9: Toubleshooting

    Rev. 02/01/18 VER SMS-DYGP-PLUS-FREEFILL20170828-EN Rev. 02/01/18 VER SMS-DYGP-PLUS-FREEFILL20170828-EN B. Backfilling SECTION 9. TROUBLE SHOOTING 1. Put the gutta percha bar inside the heating chamber and then forwarding the plunger to the front until no move can be felt. Then warm the gutta percha TROUBLES CHECK bar to the setting value.

  • Page 13: Section 10: Environmental Requirements

    Rev. 02/01/18 VER SMS-DYGP-PLUS-FREEFILL20170828-EN Rev. 02/01/18 VER SMS-DYGP-PLUS-FREEFILL20170828-EN disassembling the units by unauthorized person. If there are any questions or suggestions, please feel free to contact sales The device is maintained free of charge and doesn't require any routine representative. maintenance within warranty period.
  • Page 14 The [DY-GP Plus] is intended for use in the electromagnetic environment that it is used in such an environment specified below. The customer or the user of the [DY-GP Plus] should assure that it is used in such an environment...
  • Page 15 The [DY-GP Plus] is intended for use in the electromagnetic environment the following symbol: specified below. The customer or the user of the [DY-GP Plus] should assure that it is used in such an environment Immunity...
  • Page 16 Recommended separation distances between portable and mobile RF communications equipment and the [DY-GP Plus] Item Name: The [DY-GP Plus] is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of Model Name:...
