Cura1 2701 Manual

2701 - Falls Monitor with SafeTime

Included Accessories

2642 Caregiver Reset Key
Optional Accessories (Sold Seperately)
3516 Premium Under Mattress Bed Pad, 2626
Premium Bed Pad 1 Year, 2628 Premium Chair Pad 1
Year, 2633 Premium Heavy Duty Floor Mat 1 Year,
2623 SafeTime Bed Pad - 1 Year, 2622 SafeTime Bed
Pad - 90 days, 2621 SafeTime Wheelchair / Chair Pad -
1 Year, 3504 ActiveCare Mounting Bracket, 2620
SafeTime Wheelchair / Chair Pad - 90 days, 2406 Plug
Pack 6V Power Adaptor, 2642 Caregiver Reset Key,
2636 Easy Release Seatbelt, 2643 Nurse Call Cable,
2646 Nurse Call Cable 6.35 Mono - 3m, 2460 Nurse
Call Cable 6.35 Stereo Plug - 2m, 2461 Nurse Call
Cable 6.35 Mono to Stereo - 2m, 2493 Nurse Call
Cable 6.35 Mono to 3.5 Mono - 2m
Do NOT fold Pads or
Mats when in transit
or storage.
Keep Pads & Mats
flat at all times.
Do not immerse or wash Pads or
Mats under running water. Use a
damp cloth (1/1000 bleach solution)
& wipe clean. Dry all spills on mats
immediately.
All our products are supplied with a
full warranty and are guaranteed to
be free from defects in material and
workmanship.
Pause
Input
Lost
Reset
Low
Battery
Change
Pad
,
Caregiver Reset Key
option select (Disables
Alarm Reset button
when on.)
Optional 6Vdc
power supply.
Pad light will blink
when pad is in use.
Pad
Wetness
Change Pad light will
illuminate & Monitor
will beep when SafeTime
Bed or Chair Pad expires.
Caregiver Reset Key
application point.
Caregiver Reset Key
(Resets the Monitor
after an alarm.)
NO / NC
(Normally Open /
Normally Closed)
selector for
Nurse Call
Systems.
Alarm
Reset
Button
Optional Nurse
Adjust alarm tone,
volume & delay settings.
Tone Volume
Scale HI LO Decrease / Increase
Monitor auto-mutes
when connected to
a Nurse Call System
and volume is set to
minimum.
Call Cable.
UM-035d
