Cura1 iBeam 2721 Quick Start Manual

Adjustable tilt can
be used when the
iBeam is located on
the ground or up
high.
Side View
iBeam curtain
window.
ON OFF Switch
LED illuminates
green when
motion detected.
Front View
Detatching the iBeam from it's mounting bracket
If you use screws to fix the iBeam bracket to a permanent
position, you will need to separate the iBeam and bracket
before you screw the bracket to a fixture.
To easily separate the iBeam from it's bracket:
1. Rotate the
iBeam in it's
bracket 90 degrees
so that it is facing
the ceiling.
Antenna.
Extend fully
when in use.
Mounting hardware
Mounting tape and
screws are supplied if
you wish to
permanently mount
the iBeam to a fixture.
2. Apply gentle
pressure to one
arm of the
bracket so that
the iBeam can
easily pop out.
Optional 2723 EzyStand
2721 iBeam
Magnet
Cable Clips
Tightening Nut
Height
Adjustment
Lock
2404 AC Adapter
(Optional)
Back View
Screws
(supplied)
iBeam Bracket
The 2721 iBeam has a narrow detection beam
which detects movement up to 3m away, and a
wireless range of approx. 30m*. Use in
bedrooms, doorways, near stairs etc.
The narrow beam is especially useful if you
have other people in the same room who do
not require movement detection or where only
a very specific area requires monitoring.
*The range of wireless devices may vary and be dependent on your
specific environmental conditions.

Optional Accessories (Sold Seperately)

2723 EzyStand, 3501 ActiveCare Pager,
2700 Six Channel Cordless Falls Monitor, 3500
Double
sided tape ActiveCare Console, 2544 Cordless Multiport Expander,
(supplied)
2544 Cordless Multiport Expander Bracket Mount,
2721 .
2404 Plug Pack
UM-028c
