Cura1 iBeam 2721 Quick Start Manual

2721 .
The 2721 iBeam has a narrow detection beam which detects
movement up to 6m* away, and a wireless range of approx.
30m*. Use in bedrooms, doorways, near stairs etc.
The narrow beam is especially useful if you have other people
in the same room who do not require movement detection or
where only a very specific area requires monitoring.

Optional Accessories (Sold Seperately)

2723 EzyStand, 3501 ActiveCare Pager, 3508 LED Pager,
2700 Six Channel Cordless Falls Monitor, 3500 ActiveCare
Console, 2544 Cordless Multiport Expander, 2549 Cordless
Multiport Expander Bracket Mount, 2404 Plug Pack
*The range of wireless devices and detection distance may vary and
be dependent on your specific environmental conditions.
cura¹ products are designed to augment well designed care programs
& practices, cura¹ does not claim that any of its products are suitable
as a substitute, or as a total solution for individuals that require care
and constant supervision & are at risk.
Adjustable tilt can
be used when the
iBeam is located on
the ground or up
high.
Side View
iBeam curtain window
Status LED flashes
red every 5 seconds
when motion detected.
Mode Selection
Switch - LOCAL, OFF
or SEND
PAUSE / RESET
Press this to pause
Front View
detection for 15 seconds or
to reset the device after a
detection.
Detaching the iBeam from it's mounting bracket
If you use screws to fix the iBeam bracket to a permanent
position, you will need to separate the iBeam and bracket
before you screw the bracket to a fixture.
To easily separate the iBeam from it's bracket:
1. Rotate the
iBeam in it's
bracket 90 degrees
so that it is facing
the ceiling.
Antenna.
Extend fully
when in use.
Mounting hardware
Mounting tape and screws
are supplied if you wish to
permanently mount the
iBeam to a fixture.
2. Apply gentle
pressure to one
arm of the
bracket so that
the iBeam can
easily pop out.
Optional 2723 EzyStand
2721 iBeam
Magnet
Cable Clips
Tightening Nut
Height
Adjustment
Lock
2404 AC Adapter
(Optional)
Rear View
Screws
(supplied)
iBeam Bracket
Double
sided tape
(supplied)
UM-028d
