„Willi" the Ghost Soldering Kit
Preparation:
Carefully release wooden parts from the board
and set out all parts.
You will also need:
Soldering iron, solder, tweezers, wire strippers
Recommendation for children
and teenagers: Assembly and
soldering should be supervised
by an adult.
Safety notes:
Keep this manual for future reference! It contains important information.
When the battery is drained, always replace it with a new battery with the same rating.
The soldering iron, solder and the parts being soldered become very hot. Be very careful!
Always use a mat when soldering! This prevents parts from slipping.
We recommend using a soldering iron holder to set the soldering iron down safely during use.
This kit is intended for battery operation only.
!
ATTENTION: Never connect the kit to 230 V mains voltage! Acute danger to life!
Soldering kit "Willi the Ghoulish Ghost"
Generally: This soldering kit is intended to introduce to the basics of soldering. It is excellent for instructor-led courses at schools
and workshops. Willi the Ghost can also be used at holiday programmes, school camps and other events related to soldering.
Dimension ghost "Willi": 105 x 82 x 28 mm (H x W x D).
Functionality
The completed kit can be used as a night light. The battery can be replaced with a battery of the same type.
Environmental notes:
Generally: Please return the electronics to a certified provider at the end of their useful life. These will then ensure the parts are
disposed of in compliance with directives. This is good for the environment and an important part of actively protecting the
environment.
Battery ordinance:
You have purchased a battery-powered product. The battery has a limited life and must therefore be replaced regularly. Do not
dispose of used batteries in the household waste. Consumers are required by law to return batteries to a suitable collection point.
Used batteries contain valuable raw materials which are recyclable. You can also send your used batteries to us: SOL-EXPERT
group, Mehlisstrasse 19, 88225 Baindt.
8 mm
0 0
Not suitable for children under 3 years! -
Ne convient pas pour les enfants de moins
Adres bewaren - Niet
8 cm
1 2 3 4
10+
Return the device to a
certified provider at the
end of its useful life!
Cable and LED template for step
B
5 6 7 8
SOL-EXPERT
group
group
4 037373 763320
QR Codes:
Anleitung (DT) Manual (EN)
https://www.sol-expert- https://www.sol-expert-
group.de/76332_Anleitung_Ge group.de/76332_Anleitung_Ge
spenst%20Willi-DT(4).pdf spenst%20%20Willi-EN(2).pdf
Instructions (FR) Instructies (NL)
https://www.sol-expert- https://www.sol-expert-
group.de/76332_Anleitung_Ge group.de/76332_Anleitung_Ge
spenst%20Willi-FR(2).pdf spenst%20Willi-NL(2).pdf
H
and .
No. 76332
