- Page 1 Instruction Guide 4A82L Kargo Master Rancho Cordova, CA 95742 800-343-7486 CustomerService@KargoMaster.com DATE: ______________...
-
Page 2: Table Of Contents
Instructions – 4A82L *PLEASE READ ALL INSTRUCTIONS AND WARNINGS PRIOR TO ASSEMBLING, INSTALLING, AND USING THIS PRODUCT* Warning Always check for wires, fuel tanks and lines, brake lines and other important vehicle functionality items prior to drilling and installing all products. - Page 3 Instructions – 4A82L Parts For Technical Support Call: 800-343-7486 Monday-Friday 7AM - 4 PM (PST) Page 2...
-
Page 4: Parts List
Instructions – 4A82L Hardware (18-4A82L) For Technical Support Call: 800-343-7486 Monday-Friday 7AM - 4 PM (PST) Page 3... -
Page 5: Assembly Hardware
Instructions – 4A82L Hardware (18-4A82L) Continued For Technical Support Call: 800-343-7486 Monday-Friday 7AM - 4 PM (PST) Page 4... -
Page 6: Step 1 - Ladder Stops
Instructions – 4A82L Step 1 – Ladder Stops • Bolt ladder hooks to one end of each bow. • Use a 5/16” carriage bolt, 5/16” washers and a 5/16” nylock. • TIGHTEN. Skip installing ladder stops if adding 4A81L. Step 2 – Assemble Side Tube •... -
Page 7: Step 3 - Mount Side Tube
Instructions – 4A82L Step 3 – Mount Side Tube • Place side tube assembly on top of installed bows. • Have the bend towards the front and to the outside of the vehicle as shown. • Mount rotation bar plate to the rear of the tube as shown. -
Page 8: Step 4 - Mount Clamp Tube
Instructions – 4A82L Step 4 – Mount Clamp Tube • Place clamp and lock L bracket on top of installed bows. • Insert plastic bushings into the clamp and lock L bracket and the rotation bar plate installed in Step 3, with flange towards each other and to the inside as shown. -
Page 9: Step 5 - Mount Handle
Instructions – 4A82L • Bolt clamp and lock L bracket to bows using 3/8” x 1” carriage bolt, 3/8” flat washer and a 3/8” nyloc as shown. • TIGHTEN Step 5 – Mount Handle • Bolt handle to clamp tube using a 5/16” x 2-3/4” hex head, two 5/16” flat washers, 5/16”... -
Page 10: Step 6 - Mount Latch Assembly
Instructions – 4A82L Step 6 – Mount Latch Assembly • Bolt latch to the rear of the mount tube that was installed in Step 5 using 5/16” x 2” carriage bolt, 5/16” curved washer and a 5/16” nyloc. • TIGHTEN Step 7 –... - Page 11 Instructions – 4A82L Step 8 – Install Extra Pad • Adjust clamp on bracket to fit firmly against your ladder. • If ladder rests on cross bow, place extra rubber bumper to avoid scratching. For Technical Support Call: 800-343-7486 Monday-Friday 7AM - 4 PM (PST)
- Page 12 Instructions – 4A82L GO BACK AND ENSURE ALL HARDWARE IS TIGHT Your installation is now complete. BE SURE LADDER IS SECURE PRIOR TO TRANSPORTATON For Technical Support Call: 800-343-7486 Monday-Friday 7AM - 4 PM (PST) Page 11...
