Impianto 1 Porta Video Serie Powercom; Installation Avec 1 Porte Vidéo Série Powercom; Installatie Met 1 Video-Entreepaneel Van De Powercomserie; Anlage Mit 1 Video-Türstation Der Serie Powercom - Comelit Simplebus 2 FT SB2 15 Technical Sheet

Impianto 1 porta video Serie Powercom.

IT
System with 1 Powercom series video port.
EN
Installation avec 1 porte vidéo Série Powercom.
FR

Installatie met 1 video-entreepaneel van de Powercomserie.

NL
*Pulsante comando apriporta locale
*Local door-opener button
*Bouton commande ouvre-porte local
v*Bedieningsknop lokale deuropener
*Lokale Türöffnertaste
*Pulsador abrepuertas local
*Botão de comando abertura da porta local
SB2V/01G
Anlage mit 1 Video-Türstation der Serie Powercom.
DE
Instalación con 1 puerta vídeo de la serie Powercom.
ES
Instalação 1 porta vídeo Série Powercom.
PT
Comelit Art. 4577 1 mm 2 (Ø 1,2 mm AWG 17)
Comelit Art. 4576-4578 0,5 mm (Ø 0,8 mm AWG 20)
2
UTP5 cat. 5 0,2 mm (Ø 0,5 mm AWG 24)
2
0,28 mm (Ø 0,6 mm AWG 23)
2
0,5 mm 2 (Ø 0,8 mm AWG 20)
1 mm 2 (Ø 1,2 mm AWG 17)
1 mm (Ø 1,2 mm AWG 17)
2
1,5 mm (Ø 1,4 mm AWG 15)
2
FT SB2 15
1214/2
5701
4888
A B F
200 m 200 m
(650 feet) (650 feet)
200 m 10 m
(650 feet) (35 feet)
80 m 150 m
(260 feet) (495 feet)
100 m 150 m 4 m
(325 feet) (495 feet) (15 feet)
120 m 100 m 10 m
(390 feet) (325 feet) (35 feet)
120 m 150 m 20 m
(390 feet) (495 feet) (65 feet)
120 m 80 m 20 m
(390 feet) (260 feet) (65 feet)
150 m 100 m 30 m
(495 feet) (325 feet) (95 feet)
27 FT SB2 15
5801
4888
H
60 m
(195 feet)
40 m
(130 feet)
40 m
(130 feet)
40 m
(130 feet)
40 m
(130 feet)
30 m
(95 feet)
40 m
(130 feet)
