3.8 Printer
Connect a printer using the USB port on the side of the machine.
Select driver: enables the driver selection for
1
the installation of a new printer Before installing
a new printer, press "Select driver" and a new
window opens. Search the hard disk or an
external support for the driver of the printer to be
installed and follow the installation procedure.
3
2 Default Printer: Selection of default printer when several printers
are connected
Printer Settings: Access to the settings of the printer and printing
3
parameters.
Install Printer: Adding of a printer with the use of the printer
4
driver.
1
2
4
3.9 DICOM
In order to be used, the Dicom store and Dicom print must be
correctly configurated with the information obtained from the
Dicom administrator in the premises (clinic/hospital).
Enable DICOM store to send images and clips to the server during
and at the end of an exam. Connection parameters must be
entered correctly otherwise images and clips will be stored locally.
When Dicom Print is activated, images are printed through the
printer server.
3.10 Tools
3
1 Follicle Tool: Enables the automatic follicle measurement
tool. After activation, a shortcut will appear in bottom right of
screen to deactivate follicle calculation.
Live: When enabled, follicle measurement can be done when
2
live scanning. If disabled, Follicle measurement can only be
done freeze mode
Time Integration: Select Long for slow scanning movement
3
Two Scan: enables the automatic measurement of two follicles
4
at the same time on the B Image
Auto Focus: If activated, focus and frequency will change
5
automatically upon depth adjustments
Keep annotations in Freeze: When enabled, annotations will
6
re-appear in "Freeze". Annotation will disappear when the
imaging mode changes, when deleted or when this function is
disabled.
Instruction manual
1
2
3
4
5
6
Select Short for fast scanning movement
(measurement less precise)
