- Page 1 OPERATION AND INSTALLATION AUTOMATIC HAND DRYER » GALAXY » GALAXY ™ ™ » GALAXY » GALAXY ™ ™ Certified to ANSI/UL Std. 499 Conforms to CAN/CSA Std. 22.2 No. 36...
-
Page 2: Table Of Contents
Stiebel eltron, Inc. Will not be liable for any damages because of failure to comply with the installation and operating instructions outlined in this manual or because of improper use. -
Page 3: Safety Instructions
GENERAL INFORMATION NOTE: Read these instructions carefully before using the appliance and keep them for future reference. Pass on the instructions to a new user if required. Safety instructions 1.1.1 Structure of safety instructions KEYWORD: Type of risk Here, possible consequences are listed that may result from failure to observe the safety instructions. -
Page 4: Safety
SAFETY Safety Intended use The appliance is intended for drying hands. This appliance is intended for domestic use. It can be used safely by untrained persons. The appliance can also be used in a non-domestic environment, e.g. in a commercial setting, as long as it is used in the same way. Any other use beyond that described shall be deemed inappropriate. - Page 5 SAFETY WARNING: Injury Where children or persons with limited physical, sensory or mental capabilities are allowed to control this appliance, ensure that this will only happen under supervision or after appropriate instructions by a person responsible for their safety. Children must be supervised to ensure that they never play with the appliance.
-
Page 6: Register Your Product
Before beginning the registration process, we suggest that you gather the necessary information which will be as follows: Type, Example: Galaxy 1 (from the white label that is on the side of the unit) Number listed after “Nr.” Place of Purchase Purchase Date First &... -
Page 7: Cleaning, Care And Maintenance
CLEANING, CARE AND MAINTENANCE Cleaning, care and maintenance MATERIAL LOSSES: ™ The Galaxy hand dryer does not contain any parts serviceable by non- licensed people. In case of malfuntion please contact a licensed electrician. To clean the case use a soft cloth with a mild detergent if necessary. Never use any abrasive cleaners since they will scratch the finish of the unit. - Page 8 MINIMUM CLEARANCES Danger zone: do not install unit in bathtubs showers, or wash basins. Danger zone: do not install directly above bathtubs or showers. Danger zone: do not install within 24˝ (600 mm) of bathtubs or showers Safe area: unit must be installed in this area, outside of danger zones 2, 1 and Before mounting the unit to the wall, ensure all minimum distances are met for safety and performance considerations.
-
Page 9: Preparation
PREPARATION min 4 (102 mm) 48 (1219 mm) Mount the hand dryer at least 48˝ (1219 mm) above the floor. Preparation ™ The Galaxy hand dryer must have its own independent circuit using 3 wire cable of the appropriate size protected by a correctly rated double-pole circuit breaker. ™... -
Page 10: Wall Mounting
WALL MOUNTING Pull down the locking slide and remove the front cover. Cut a hole in the back housing and install a ½˝ strain relief connector for the electric cable. Tighten the strain connector onto the cable. Wall mounting Drill the mounting holes in the wall. Use anchors for securing into drywall or tile. -
Page 11: Electrical Installation
ELECTRICAL INSTALLATION 10. Electrical installation Connect the wires to the terminal block connections. 208—240V/60Hz 110—120V/60Hz N/L L Fan motor Heating element Sensor Reinstall the front cover. Push up the locking slide and reinstall the three screws that were removed. ™ WWW.STIEBEL-ELTRON-USA.COM GALAXY AUTOMATIC HAND DRYERS |... -
Page 12: Specification
SPECIFICATION 11. Specification 11.1 Dimensions ™ ™ Galaxy 1 & Galaxy ™ ™ Galaxy M1 & Galaxy electronic ™ | GALAXY AUTOMATIC HAND DRYERS WWW.STIEBEL-ELTRON-USA.COM... -
Page 13: Technical Data
SPECIFICATION 11.2 Technical data Galaxy ™ Galaxy ™ Part number 073009 073724 Electrical data Phase 60/50 Hz - single Voltage 120 V Wattage 1850 W 1850 W Amperage 15.42 A 15.42 A Required circuit breaker 20 A Required wire size 12 AWG Other Height... -
Page 14: Warranty
Should the part(s) prove to be defective under normal use during this period, stiebel eltron, inc. will be responsible for replacement of the defective part(s) only. Stiebel Eltron, Inc. is not responsible for labor charges to remove and/or replace the defective part(s), or any incidential or consequential expenses. - Page 15 NOTES ™ WWW.STIEBEL-ELTRON-USA.COM GALAXY AUTOMATIC HAND DRYERS |...
- Page 16 7 ¼ 3 ¾ lat may not rint at before ½ 6 ½...
- Page 17 United States of America STIEBEL ELTRON, Inc. 17 West Street | West Hatfield MA 01088 Tel. (413)247-3380 | Fax (413)247-3369 info@stiebel-eltron-usa.com www.stiebel-eltron-usa.com...
