Summary of Contents for WingHome 290C
-
Page 2: Table Of Contents
Contents 1. Introduction........................... 1 1.1 Fully Functionality Introduction................... 1 1.2 Application..........................1 1.3 Power Supply........................1 1.4 SD Card Selection......................... 2 1.5 USB Connection........................3 1.6 Attention..........................3 1.7 Key Features..........................3 2. Whole View and Details of Camera.....................4 2.1 Figure 1: Front View of Camera;..................4 2.2 Figure 1: Function Keys &... -
Page 3: Introduction
1. Introduction Thank you for choosing one of our easy operation highly qualified products. You now may enjoy the excellence reflected on this series product. This 24MP HD digital camera was totally R&D by our diligent and smart engineers based on feedback and requirements from customers globally. -
Page 4: Sd Card Selection
12AA Alkaline Batteries Photos shot per day Working time Video clips shot per day Working time IR LEDs On IR LEDs On 12MP 100 photos 64 days 10 sec 10 clips 59 days 16MP 100 photos 61 days 10 sec 10 clips 57 days 24MP... -
Page 5: Usb Connection
00:02:04 00:03:53 00:08:31 00:17:48 00:36:20 01:13:21 1.5 USB Connection When camera is connected via USB cable; screen display “MSDC”, press “Menu” once, “MSDC” turns to “PC Cam”, camera now can be used as a PC camera; press “Menu” again, camera exits PC camera mode. 1.6 Attention 1. -
Page 6: Whole View And Details Of Camera
per trigger), programmable delay between motions, Time Lapse, Timer, stamp of (camera ID, date/time, temperature, moon phase) on every single photo; 9. Available operation temperature: -25℃ to 60℃; 10. Built-in 2.0" TFT color screen. 2. Whole View and Details of Camera 2.1 Figure 1: Front View of Camera;... -
Page 7: Figure 1: Function Keys & Other Details
Internal View Note: 1. IR LEDs (Top: 20pcs, Bottom: 22pcs; 42pcs in total) 10. Menu Button 2. Built-in Microphone 11. Navigation Buttons 3. Indicator LED 12. Mode Switch (Power Switch) 4. PIR Sensor 13. Battery Compartment (A) 5. Lens For first group of 6pcs of AA batteries. 6. - Page 8 01. Menu Button: When the camera is set at the setup mode, the color LCD screen will light up. When the color LCD is activated, press the Menu button to enter the camera menu. When under the camera menu, the Menu button is used as Exit button.
-
Page 9: Quick Start
3. Quick Start 3.1 How to Start the Camera? Switch ON “Power Switch” Note: Camera comes pre-programmed with factory default settings. So for test purpose, user only needs to insert a SD card and batteries to start test by powering on. 3.2 How to Set the Functions? Switch to “Setup”, camera LCD screen is lightened, camera enter Test Mode. -
Page 10: Camera Default Settings In Red Letter
3.3 Camera Default Settings in Red Letter Setup Auto Language English… Date/Time YYYY/MM/D Hunting HH:MM ON/OFF Password Camera Name OFF/ON OFF/ON Camera Mode Picture/Video/PIC+Video Image Size Multi-Sho Image Security 12MP/16MP/24M ON/OFF 1P-7P Video Size Video Frame Video FHD/HD/VGA 30FPS/15FPS Video Length /SS 05-60s PIR Sensitivity High/Middle/Low... -
Page 11: Operation List
4. Operation List 4.1 Video/Photo Playback Switch to “Setup”, camera LCD screen is lightened, camera enter Test Mode; press arrow button “↑” to enter Playback; press “←” and “→” for selection, “OK” to play photo/video. 1) Press button “↑” again to exit. 2) In Playback Mode, press “Menu”... - Page 12 Auto Modes Settings Programmable Options Hunting Camera default settings are: multi-shot 3P, 12M photo size, 5sec Delay Security Camera default settings are: photo + video, 12M photo size, multi-shot 5P, 1080P video size, 10sec video length Setup Settings Programmable Options Language English…...
- Page 13 Multi-shot Programmable 1~7 photos per trigger Video Setup Video Size FHD(1920*1080),HD( 1280*720),VGA( 640*480) Video Frame 30FPS,15FPS Video length 05~60 Secs Sensitivity High, Middle, Low Higher sensitivity is 1) more sensitive to movements by smaller subjects; 2) longer detection distance; 3) easier for sensor to detect difference between body heat and outdoor temperature;...
-
Page 14: Specification
5. Specification Effective Pixels 2560x1920 Day/Night Mode IR range IR Setting Top: 20 LED, Foot: 22 LED Memory SD Card (8MB – 32GB) Operating keys Lens F=3.0; FOV=52°; Auto IR-Cut-Remove (at night) LCD Screen 2” TFT, RGB, 262k PIR distance PIR Angle 60 degree 12MP/16MP/24MP =... -
Page 15: Trouble Shooting
Operation Humidity 5%-90% Waterproof spec IP66 Dimensions 144.3*117.5*78.4 mm Weight 359 g Certification CE FCC RoHs 6. Trouble Shooting 6.1 Photos Do Not Capture Subject of Interest 1. Check the “Sensor Level” (PIR sensitivity) parameter setting. For warm environmental conditions, set the Sensor Level to “High” and for cold weather use, set the sensor for “Low”. 2. -
Page 16: Photos Do Not Capture Subject Of Interest
6.4 Photos Do Not Capture Subject of Interest 1. Check the “Sensor Level” (PIR sensitivity) parameter setting. For warm environmental conditions, set the Sensor Level to “High” and for cold weather use, set the sensor for “Low”. 2. Try to set your camera up in an area where there is not a heat source in the camera’s line of sight. - Page 17 the product under this warranty (with a written description of the problem and print samples) for repairing or exchanging.
