USERS MANUAL / GEBRUIKERSHANDLEIDING
BETRIEBSANLEITUNG / MANUEL D'UTILISATION
MANUAL DE UTILIZACION / INSTRUZIONI PER L'USO
Digital DC 10x10A
MASTERVOLT
Snijdersbergweg 93,
1105 AN Amsterdam
The Netherlands
Tel.: +31-20-3422100
Fax.: +31-20-6971006
www.Mastervolt.com
MasterBus DC Switching Device
ENGLISH:
NEDERLANDS:
DEUTSCH:
FRANÇAIS:
CASTELLANO
ITALIANO
Copyright © 2010 Mastervolt, v 1.6 October 2010
PAGE 1
PAGINA 29
SEITE 57
PAGINA 85
PÁGINA 113
PÁGINA 141
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Mastervolt Digital DC 10x10A
Summary of Contents for Mastervolt Digital DC 10x10A
- Page 1 MasterBus DC Switching Device ENGLISH: PAGE 1 MASTERVOLT NEDERLANDS: PAGINA 29 Snijdersbergweg 93, DEUTSCH: SEITE 57 1105 AN Amsterdam FRANÇAIS: PAGINA 85 The Netherlands CASTELLANO PÁGINA 113 Tel.: +31-20-3422100 ITALIANO PÁGINA 141 Fax.: +31-20-6971006 www.Mastervolt.com Copyright © 2010 Mastervolt, v 1.6 October 2010...
-
Page 2: Quick Review
QUICK REVIEW QUICK REVIEW It provides the MasterBus network (see chapter 4) The Digital DC 10x10A is a MasterBus based input with information about the state of the fuses and and output module. It controls maximum 10 fused devices. A MasterBus display enables you to view DC channels with currents up to 10A or maximum this information, see section 3.3. -
Page 3: Table Of Contents
System example 1: Camper ......................22 System example 2: Motor ship ......................23 ORDERING INFORMATION......................... 24 TROUBLE SHOOTING ..........................25 SPECIFICATIONS ............................26 10.1 Technical specifications........................26 10.2 Dimensions ............................26 EC DECLARATION OF CONFORMITY ....................... 27 EN / Digital DC 10x10A / October 2010... -
Page 4: General Information
Digital DC versions of the Digital DC 10x10A delivered by 10x10A, called Digital DC further in this manual. Mastervolt. This manual is valid for the following model:... -
Page 5: Safety Guidelines And Measures
Do not work on the Digital DC 10x10A or system against rain, moist, dust and condensation; if it is still connected to a current source. Only observing the instructions in the users manual. -
Page 6: Operation
CONTROL MASTERBUS DISPLAYS Mastervolt offers several ways of displaying your Control of the Digital DC 10x10A is largely MasterBus data. Shown is the MasterView System MasterBus based. This means you need a display like shown in section 3.3 for controlling this switching device. -
Page 7: Masterbus
CAN-bus based between the MasterBus network and a product communication network has proven itself as a which is not from Mastervolt, the Modbus interface is reliable bus-system in automotive applications. recommended. MasterBus is used as power management system for all connected devices, such as the inverter,... -
Page 8: How To Set Up A Masterbus Network
Figure 7: No ring networks Do not make T-connections in the network. Terminating Terminating device device Figure 5: Two Terminators Figure 8: No T-connections October 2010 / Digital DC 10x10A / EN... -
Page 9: Masterbus Functions
Option to lock configuration of this channel. Unlocked Unlocked, Locked locked Mode Select the way channel X should act. Conven- See section 5.2 8 different modes are available, Disabled being the simplest tional and Manual the most sophisticated. EN / Digital DC 10x10A / October 2010... -
Page 10: Channel Modes
Application: cooling fan or toilet pump. 5.2.7 Bilge pump float Function for bilge pump with floating switch. The bilge pump includes a float switch enabling the pump when soaked, with option Always On. October 2010 / Digital DC 10x10A / EN... - Page 11 Its configuration Application: radio memory, refrigerator. mode applies to all channels linked. For joining cables correctly, refer to ISO 10133. Figure 12: 4 channels linked EN / Digital DC 10x10A / October 2010...
-
Page 12: Channel Mode Options
Not set Not set, 50 mA, 100 mA, 200 mA, current MasterBus alarm should be sent out. 300 mA, 500 mA, 700 mA, 1 A, 2 A, 3 A, 5 A, 7 A. October 2010 / Digital DC 10x10A / EN... -
Page 13: Wire Check
After configuring the Minimum Current, a MasterBus are the Switch Input 3 or 4 with LED buttons. The alarm will be generated when the wiring is in failure. Digital DC is able to illuminate a button LED when EN / Digital DC 10x10A / October 2010... -
Page 14: Event Configuration
Toggle changes the status at the first signal and back at the second signal. It is used in combination with a pulse switch. Figure 13: Event data October 2010 / Digital DC 10x10A / EN... -
Page 15: Masterbus Logical Blocks
Only if Channel 1 AND 3 are enabled, Logical Block 1 is TRUE. Logical Channel 8 False Only if Logical Block 1 is TRUE OR Block 1 channel 8 is enabled, Logical Block 2 is TRUE. EN / Digital DC 10x10A / October 2010... - Page 16 Figure 16: Sliding roof channel 3 as Drive, softstart saves the installation. Channel 4 is linked to supply an extra 10 A for the drive. See figure 17. Figure 17: Sliding roof configuration (MasterAdjust software) October 2010 / Digital DC 10x10A / EN...
- Page 17 On the roof drive. When the roof has reached the end switch, Roof is closed becomes FALSE (0) and the drive is switched Off. Event Source Target Command Data Roof is closed DSD Logic Drive Copy EN / Digital DC 10x10A / October 2010...
-
Page 18: Dimming
Event configuration example 2, configuration of Switch 2 Event Source Target Command Data Switch 2 DSD Saloon Rear light Switch 2 DSD Bedroom Port light Switch 2 DSD Bedroom Starboard light Switch 2 DSD Kitchen Anchor light Toggle October 2010 / Digital DC 10x10A / EN... -
Page 19: Installation
; 10+2 fuses 15A included (see figure 1) ; MasterBus cable ; Terminator for MasterBus ; One translucent end/ mid piece The DC input cabling must have a cross section large enough to supply the total output current. EN / Digital DC 10x10A / October 2010... -
Page 20: Installation Step By Step
17. 5. MasterBus cables 6. DC Output 6-10 7. End cap, section 1 cut. Figure 20: Installation of the Digital DC 10x10A Connecting the cables 1 Push screwdriver firmly into upper slot. 2 Place cable into opening and pull back screwdriver. -
Page 21: Commissioning
DC connectors directly by pushing them together and bolt them. See figure 23. Figure 23: Digital DC 10x10A (right) connected with DC Distribution and MasterShunt. The end cap stays uncut. EN / Digital DC 10x10A / October 2010... -
Page 22: System Examples
5 MasterBus Terminator 9 Digital DC10x10A (Salon) 2 Switch input 4 6 Electrical switches 10 DC Distribution 3 GPRS module 7 Digital DC 10x10A (Front) 11 MasterShunt 4 Digital Input 8 Digital DC10x10A (Kitchen) October 2010 / Digital DC 10x10A / EN... -
Page 23: System Example 2: Motor Ship
Always On outputs. These outputs (see also section Command Disable Disable 3.2) will stay active even when the Digital DC is Data Copy invert Copy invert disabled, useful for a radio memory or refrigerator. In EN / Digital DC 10x10A / October 2010... -
Page 24: Ordering Information
* These parts are standard included within the delivery of the Digital DC 10x10A ** 12 Mini Blade fuses 15 A are standard included within the delivery of the Digital DC 10x10A Mastervolt offers a wide range of products for your electrical installation, including AGM batteries, GEL batteries, Digital DC 10x10A kits, battery switches, battery cables, battery terminals and Mastervision switchboards. -
Page 25: Trouble Shooting
TROUBLE SHOOTING 9 TROUBLE SHOOTING Please contact your local Mastervolt Service Centre if you cannot correct a problem with the aid of the malfunction table below. See www.Mastervolt.com for an extended list of Mastervolt Service Centres. Failure Possible cause What to do No display function. -
Page 26: Specifications
DC input Maximum current 100 A Supply voltage 8-30V DC Connections MasterConnect or cable lug maximum 95 mm 10.2 DIMENSIONS [9,00] [8,44] [7,87] Figure 26: Dimensions in mm (inches) and MasterBus connections October 2010 / Digital DC 10x10A / EN... -
Page 27: Ec Declaration Of Conformity
The following harmonised standards have been applied: Generic emission standard: EN 50081-1:1992 Generic Immunity standard: EN 50082-1:1997 Low voltage directive: 2006/95/EC, with standard: Low voltage standard: EN 60950: 2000 Amsterdam, P.F. Kenninck, General Manager MASTERVOLT EN / Digital DC 10x10A / October 2010... - Page 28 Snijdersbergweg 93, 1105 AN Amsterdam, The Netherlands Tel : + 31-20-3422100 Fax : + 31-20-6971006 Email : info@Mastervolt.com...
