ABS -Lock X Series Installation Manual page 12

Hide thumbs

Advertisement

12
Nm
24
T25
T25
15/16"
16x
ABS-Lock® X-H-16
min.
100 mm
„
3,95
LX-H-XXX-16
min.
OSB/2
min.
22 mm
„
0.87
