MadgeTech TCTemp2000 Quick Reference Card

Product Quick Reference Card
Device Maintenance
Battery Replacement
Materials:
3/32" HEX Driver (Allen Key)
Replacement Battery (U9VL-J)
- Remove the cover from the device by unscrewing the four
screws.
- Remove the battery from its compartment and unsnap it
from the connector.
- Snap the new battery into the terminals and verify it is secure.
- Replace the cover taking care not to pinch the wires. Screw
the enclosure back together securely.
Note: Be sure not to over tighten the screws or strip the threads.
Battery Warning
WARNING: FIRE, EXPLOSION, AND SEVERE BURN HAZARD. DO NOT
SHORT CIRCUIT, CHARGE, FORCE OVER DISCHARGE, DISASSEMBLE,
CRUSH, PENETRATE OR INCINERATE. BATTERY MAY LEAK OR
EXPLODE IF HEATED ABOVE 60°C (140°F).
Recalibration
The TCTemp2000 standard calibration is one point at 25°C for the
internal channel and 0mV for the thermocouple channel.
Pricing:
Recalibration traceable to NIST $60.00
Recalibration $40.00
Additional:
As Found Data $15.00
Additional Points $15.00 per point
Channel (1st) $30.00 at 25°C
$45.00 at custom point
Additional Channels $3.00 at 25°C
$4.50 at custom point
To send the devices back, visit www.madgetech.com, select Services
then RMA Process.
Part Number TCTemp2000
Temperature Sensor Semiconductor
Temperature Range -20 to +60°C
Temperature Resolution 0.1°C
Remote Channel Temperature Sensor
*See Table for Details
Range, Resolution & Accuracy
Cold Jct. Compensation Automatic
Memory 131,071/channel
Sample Rate 2 second up to 24 hours
Channels 1 Internal & 1 Remote
Required Interface Package IFC110 or IFC200
Baud Rate 115,200
Typical Battery Life 1 year with display off, 30 days with
continuous LCD and no backlight
Operating Environment -20 to +60°C 0 to 95%RH
Material Black Anodized Aluminum
Dimensions 4.8" x 3.3" x 1.25" (122mm x 84mm x 32mm)
Approval CE
* Remote Channel Range, Resolution & Accuracy
Thermocouple Range (°C) Resolution
J -210 to +760 0.1°C
K -260 to +1370 0.1°C
T -260 to +400 0.1°C
E -260 to +980 0.1°C
R -50 to +1760 0.5°C
S -50 to +1760 0.5°C
B +60 to +1820 0.5°C
N -260 to +1300 0.1°C
Specifications subject to change.
See MadgeTech's terms and conditions at www.madgetech.com
MadgeTech, Inc.
PO Box 50 Warner, NH 03278
l
Phone 603.456.2011 Fax 603.456.2012
l
www.madgetech.com info@madgetech.com
l
Product Information Card
Accuracy
+0.5°C
+0.5°C TCTemp2000
+0.5°C
Thermocouple Temperature Recorder with LCD Display
+0.5°C
+2.0°C
+2.0°C
+2.0°C
+0.5°C
REV A 2008.07.08
