- Page 1 ® Everything in its place. OWNER’S MANUAL TRINITY 72” x 19” / 72” x 24” Wood Top Work Table Model # TLS-7202 / TLS-7202C / TLS-7203 / TLS-7203C...
-
Page 2: Parts List
PARTS LIST Your TRINITY 72” Wood Top Work Table should include the following parts. Please inspect box contents to ensure you have received all components. If you are missing any parts, need assistance with assembly or have questions, please contact TRINITY Customer Service: 800.985.5506 or customerservice@trinityii.com. - Page 3 Repeat these steps to attach the other TOP CROSS BEAM (B) to the other side of SIDE FRAMES (D+E). Only hand tighten LARGE BOLTS (F). Do not fully tighten with WRENCH (J) until after WOOD TOP (A) is fully secured after Step 4. © 2017 TRINITY - 800.985.5506...
- Page 4 Insert (20) SMALL SCREWS (H) and SMALL WASHERS (I) and partially tighten by hand to secure the frame to the WOOD TOP (A). Once all (20) SMALL SCREWS (H) have been inserted, fully tighten all SCREWS (H). © 2017 TRINITY - 800.985.5506...
- Page 5 Table leg. Height adjusts from 34” to 40” in 2” increments”. 3. Insert and tighten (2) LARGE BOLTS (F) and LARGE WASHERS (G). 4. Adjust Feet Levelers to ensure that Table is level. © 2017 TRINITY - 800.985.5506...
- Page 6 ASSEMBLY INSTRUCTIONS MOBILE OPTION (TLS-7202C AND TLS-7203C ONLY) K (2) L (2) J (1) INSTALL CASTERS 1. With the Table upside down, unscrew feet levelers and remove from Table legs. 2. Screw on CASTERS (K+L) and tighten with the large end of the WRENCH (J).
- Page 7 SERVICE PARTS LIST – TLS-7202 / TLS-7202C / TLS-7203 / TLS-7203C TRINITY Customer Service provides the following replacement parts: Part Number Description Part Number Description LNA-06-002-7219 Wood Top-72”x19” ZSV-99-008-4010 Locking Caster LNA-06-002-7224 Wood Top-72”x24” ZBK-01-001-0820 Large Bolt PBK-13-002-6750 Top Cross Beam...
-
Page 8: Care And Maintenance
Wood top can be cleaned with damp cloth and wiped dry immediately with dry cloth. If needed, solvent-based wood furniture cleaner can be used. • Clean up any spills immediately to prevent stains from forming on the wood top. © 2017 TRINITY - 800.985.5506... -
Page 9: Product Registration
PRODUCT REGISTRATION Thank you for purchasing a TRINITY 72” Wood Top Work Table. In order to register your product and receive streamlined customer service, please fill out the following Product Registration Form and (1) fax the form to 310.347.4134 (2) complete the Product Registration Form online at www.trinityii.com or (3) scan and email the form to customerservice@trinityii.com. - Page 10 © 2017 TRINITY - 800.985.5506...
-
Page 11: Year Limited Warranty
Product which shall not be greater than the amount of the purchase price of the Product, at the option of Trinity, during the warranty period. All replaced parts and Products become the property of Trinity and must be returned to Trinity. - Page 12 WE ARE HERE TO HELP! Please feel free to contact us. There are no questions too small, or any problems too big. We’re committed to providing our customers with the highest level of service. TRINITY Customer Service TEL: 800.985.5506 FAX: 310.347.4134 EMAIL: customerservice@trinityii.com Monday through Friday 8:00 AM –...
